- Page 1 Installation Guide buoy.ai...
- Page 2 Notes _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________...
- Page 3 Battery and Charger assembly 3/4” meter couplings (2) Rubber gaskets (6) Also included: • Buoy Quick Start Guide • Buoy sticker • Buoy Installation Guide • Buoy tape measure PROFESSIONAL INSTALLATION STRONGLY RECOMMENDED Contact a licensed plumber for professional installation of your Buoy...
-
Page 4: Prepare For Installation
NOT be installed on fire sprinkler water lines or fire suppression systems. Checklist prior to installation ‰ Before starting, take a photo of the main water line where the Buoy will be installed. This is a good reference for the installation process. - Page 5 Checklist prior to installation (continued) ‰ Identify a space for the Buoy. The device can be installed horizontally or vertically. Make sure the Buoy logo with LED light faces out. For vertical installations, be sure the outlet is above the inlet.
- Page 6 Option 1: Install In-Line In-line installation requires a minimum pipe gap length of 13” for the Buoy and 5” for the optional 3/4”union joints. Allow extra space for any additional adapters needed (not included). Outlet Outlet 13̎ (33cm) Inlet Inlet Install the optional couplings (included) using the thickest possible rubber washers (included).
- Page 7 Assemble waterhorn union fittings, copper FPT female adaptors and the waterhorn. Tighten all fittings. Teflon/plumber’s tape may be needed. Place the Buoy in the waterhorn with a black gasket on each side, and tighten the swivel adaptors (do not overtighten). Make sure the Buoy logo is facing outward and the LED is visible.
- Page 8 Option 3: Install with Flexible Line (not included) Attach the ¾” couplings with rubber gaskets (included) to each end of the Buoy. Attach flexible lines to each coupling. Use professional judgement to secure the Buoy to the wall with strapping, such as Unistrut or similar.
-
Page 9: Post-Installation
Post-Installation Be sure the blue end of Buoy faces the water INLET and the gray end of Buoy faces the water OUTLET. Outlet Inlet BLUE end = Inlet GRAY end = Outlet ‰ Verify the Buoy’s fit and check that the device is level and secure. - Page 10 Notes _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________...
- Page 11 _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________ buoy-installation-guide-091217...
- Page 12 © 2017 Buoy Labs, Inc.
