2010A - 2020A
Hydraulic coolers are covered 24 months by warranty within the limits mentioned in our General Sales Conditions.
In case of a use other than that mentioned in the Instructions manual, and without preliminary agreement of MOUVEX,
warranty will be canceled.
Z.I. La Plaine des Isles - F 89000 AUXERRE - FRANCE
Tel. : +33 (0)3.86.49.86.30 - Fax : +33 (0)3.86.49.87.17
contact@mouvex.com - www.mouvex.com
HYDRIVE
WARRANTY :
INSTRUCTIONS 206-A00 e
Section
206
Effective
September 2018
Replaces
March 2018
Original instructions
INSTALLATION
OPERATION
MAINTENANCE
SAFETY
STORAGE
Your distributor :

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSG MOUVEX HYDRIVE 2010A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dover PSG MOUVEX HYDRIVE 2010A

  • Page 1 INSTRUCTIONS 206-A00 e Section Effective September 2018 Replaces March 2018 Original instructions HYDRIVE 2010A - 2020A INSTALLATION OPERATION MAINTENANCE SAFETY STORAGE WARRANTY : Hydraulic coolers are covered 24 months by warranty within the limits mentioned in our General Sales Conditions. In case of a use other than that mentioned in the Instructions manual, and without preliminary agreement of MOUVEX, warranty will be canceled.
  • Page 2: Table Of Contents

    HYDRAULIC COOLERS SAFETY, STORAGE, INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS MODELS : HYDRIVE 2010A & 2020A TABLE OF CONTENTS Page 1. OVERALL DIMENSIONS ......3 Definition of safety symbols 2.
  • Page 3: Overall Dimensions

    1. OVERALL DIMENSIONS DISCHARGE HYDRIVE 2010 SUCTION REVOLVING T 1”5/16 JIC M/F/M HYDRIVE 2020 DISCHARGE SUCTION NT 206-A00 09 18 Hydrive e 3/16...
  • Page 4: Technical Data

    2. TECHNICAL DATA HYDRIVE 2010A Oil Flow Rate 15 32 US GPM 55 120 l / min Circuit pressure 2 possible versions : RV set @ : RV set @ : 170 bar 2465 PSI 170 bar 270 bar 3916 PSI 270 bar Maximum pressure allowed 4061 PSI...
  • Page 5: Installation

    3. INSTALLATION 3.1 Hydraulic circuits Figure 1 shows the hydraulic circuit for a single motor Use a remote valve on hydraulic systems. drive system. If driving a motor in both directions, install a directional control valve in the circuit as shown. HYDRIVE 2010A &...
  • Page 6: Mounting

    3. INSTALLATION (continued) 3.2 Mounting Using the supplied washers contributes to the vibra- tion protect. 1. Position the HYDRIVE so that the filler plug and the gauge are accessible, and that the front of the radiator (where the air exits) is not obstructed. NOTE : For easy installation, the gauge can be mounted on either side of the tank.
  • Page 7 3. INSTALLATION (continued) 3.2.1 CONNECTING 6. Connect the low pressure return hose from the driven motor to the fitting on the control block marked 1. Connect the suction hose from the hydraulic block port "RETURN". The return hose must be rated for mini- marked "Pump"...
  • Page 8: Hydraulic Oil

    3. INSTALLATION (continued) Hydrive connections 3.3 Hydraulic oil The System must be filled with one of the following anti- Hydrive Hydrive foaming hydraulic oils, or an equivalent oil : 2010 2020 Normal ambient temperature* 1" 2" NPT 1. Pump inlet -9°C to 26°C 26°C and more 1"...
  • Page 9: Priming The System

    3. INSTALLATION (continued) 3.4 Priming the system 1. Depress the clutch and engage the PTO. Release the WARNING clutch slowly. After approximately 2 seconds depress the clutch and disengage the PTO. 2. To insure that all system components, hoses and fittings are completely filled with hydraulic oil, crack the return VEHICLE EMERGENCY...
  • Page 10: Adjusting The Relief Valve

    3. INSTALLATION (continued) 3.6 Adjusting the relief valve 1. Install test equipment in the high pressure line per the manufacturers recommendations. NOTE The use of quick connect fittings in the hydraulic motor line allows easier installation of test equipment. Fan speed control valve Pressure relief valve The HYDRIVE is equipped with a pressure relief valve that is factory set, the pressure value is stamped on the...
  • Page 11: Setting Fan Speed

    3. INSTALLATION (continued) 3.7 Setting fan speed 1. Operate hydraulic system at full load to properly set DANGER fan speed. NOTE Creating an artificial load of the factory relief valve setting, is the best way to set the fan speed. Refer FAN SPEEDS ABOVE 3000 RPM WILL CAUSE SERIOUS PERSONAL INJURY, to the §...
  • Page 12: Operation

    4. OPERATION 4.1 Pre-start up check list 4.2 Operation 1. Check the reservoir to make sure it is full of clean, 1. Set the tractor speed to idle RPM, depress the clutch uncontaminated oil, and that the level is no lower than and engage the PTO.
  • Page 13: Maintenance

    5. MAINTENANCE 5.2 Return filter replacement NOTICE HYDRIVE SERVICE SHALL BE PERFORMED BY QUALIFIED Check the return filter 19 at least every 3 months and TECHNICIANS ONLY. SERVICE SHALL CONFORM TO ALL replaced at least every 12 months. APPLICABLE LOCAL AND NATIONAL REGULATIONS AND SAFETY STANDARDS.
  • Page 14: Troubleshooting

    6. TROUBLESHOOTING CAUSE PROBLEM CORRECTIVE ACTION Insufficient oil getting to the pump. See “Cavitation”. Aeration of the oil Air entering the system. See “Air Entering the System”. (oil goes milky) Water entering the system. Tighten up all hose connections. Inspect suction pipe for splits. Replace as required.
  • Page 15: Storage Conditions

    7. STORAGE CONDITIONS The equipment must be systematically stored in an area shel- If installation is interrupted, put back in place the original pro- tered from bad weather. tective components or equivalent components. The equipment must bear its original protective components until it is installed in its final application.
  • Page 16: Certificate Of Conformity

    9. CERTIFICATE OF CONFORMITY NT 206-A00 09 18 Hydrive e 16/16...
