Summary of Contents for Acclaim Lighting Spectrum AL Cove DMX
- Page 1 AL Cove DMX User guide...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ............2 Welcome Safety Supplied items Optional extras INSTALLATION ............4 Mounting Mount adjustment Power cabling Interconnecting Maximum number of fixtures OPERATION .............6 Addressing fixtures DMX personality mode selection Testing emitter output FURTHER INFORMATION ........10 Specifications Limited product warranty www.acclaimlighting.com... -
Page 4: Introduction
INTRODUCTION WELCOME Welcome to the AL Cove DMX range from Acclaim Lighting. These compact, aluminum bodied, dry location (IP20) fixtures are available in 1’ and 4’ lengths, are designed specifically to graze surfaces in close proximity. AL Cove DMX fixtures benefit from internal auto-ranging power units and can be fed via AC voltage supplies in the range 100 to 277V. -
Page 5: Supplied Items
SUPPLIED ITEMS AL Cove DMX 1’ or 4’ with two swivel mount brackets OPTIONAL EXTRAS Feed cable + end cap 10’ (3m) [ACDFC10] Link cables 1’ (30cm) [ACDLC1] 5’ (1.5m) [ACDLC5] 10’ (3m) [ACDLC10] End cap [ACDEC] DMX/RDM tool plus male 5pin XLR lead [XMT350] www.acclaimlighting.com... -
Page 6: Installation
INSTALLATION When installing each AL Cove DMX fixture, ensure that the surface is level and that nothing is protruding to damage the mounting bracket(s). Suitable mounting surfaces include steel, aluminum, concrete or wood structures. MOUNTING Each mount bracket has two slots measuring 0.39” x 0.18” (10 x 4.5mm) and the base has a thickness of 0.08”... -
Page 7: Power Cabling
POWER CABLING AL Cove DMX fixtures use proprietary 3+5 pin connectors (mains plus DMX) for their inputs and outputs. The connector placements at each end of every fixture are such that abutted fixtures can be directly connected without need for extra link cables. The contacts of the required feed-in cable (available as a separate item) are arranged as follows: r t h... -
Page 8: Operation
Note: Each AL Cove DMX fixture is supplied with its DMX address set to 1 by default. Various third party DMX/RDM tools are available; we recommend the Acclaim Lighting XMT- 350 tool for this task. -
Page 9: Dmx Personality Mode Selection
Various third party DMX/RDM tools are available; we recommend the Acclaim Lighting XMT-350 tool for this task. The chosen mode will determine how many DMX channels are required to control the fixture. For instance, DMX 8RGBW mode on a 4’... - Page 10 DMX PERSONALITY entry: AL COVE AC DMX LABEL: AL COVE DMX MODEL: AL COVE AC DMX MAN: ACCLAIM LIGHTING DMX START ADDRESS: DMX PERSONALITY: DMX 4RGBW DMX SLOTS: 6 Press the button to view the personality options: AL COVE AC DMX...
-
Page 11: Testing Emitter Output
After you have addressed each AL Cove DMX fixture we recommend that you also test each one prior to installation. This can be achieved with your RDM (Remote Device Management) tool. Various third party DMX/RDM tools are available; we recommend the Acclaim Lighting XMT-350 tool for this task. -
Page 12: Further Information
FURTHER INFORMATION SPECIFICATIONS Color RGB, QW w/ Spectrum Technology (RGB + 3000K white) or Dynamic White (2700K - 5500K) Beam angle SO: 280 lm per foot Total Lumens EO: 140 lm per foot Lumen maintenance (L 150,000 hours (25 Control DMX/RDM Maximum lengths in series 100’... -
Page 13: Limited Product Warranty
If the requested repairs or service (including parts replacement) are within the terms of this warranty, Acclaim Lighting will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in its original package. - Page 14 www.acclaimlighting.com...
