- Page 1 S W A N 1 0 0 0 S E R I E S ELECTRONIC LAVATORY FAUCETS installation & maintenance guide S W A N 1 0 0 0 S W A N 1 0 0 0 B SWAN 1000 BM S W A N 1 0 0 0 E SWAN 1000 EM S T E R N E N G I N E E R I N G L T D.
- Page 2 d e x TECHNICAL DATA PACK CONTENTS Swan 1000 Swan 1000 B and Swan 1000 BM Swan 1000 E and Swan 1000 EM PRE INSTALLATION INFORMATION FAUCET INSTALLATION RANGE ADJUSTMENT Adjusting the sensor range Adjusting the sensor range with a remote control - optional 9-10 BATTERY REPLACEMENT INSTRUCTIONS To replace the battery at Swan 1000 model...
- Page 3 c h n i c a l d a t a SWAN 1000-1000 B-1000 E SWAN 1000 BM-1000 EM Electronic faucet with mixer Electronic faucet with mixer to adjust the temperature to adjust the temperature and with override handle for alternative manual operation Power supply: 9V battery or 9V transformer Recommended water pressure:...
- Page 4 c k c o n t e n t s Familiarize yourself with the part names and confirm that the parts are included. 1. Swan 1000 1. 1x Tap and attachments 2. 2x Allen key 3. 2x Filters 4. 2x Back-checks and filter adapters 2.
- Page 5 c k c o n t e n t s 3. Swan 1000 E and Swan 1000 EM 1. 1x Tap and attachments 2. 2x Filters 3. 2x Back-checks and filter adapters 4. 1x Transformer...
-
Page 6: Preparation For Installation
e - i n s t a l l a t i o n i n f o r m a t i o n Check contents Separate all parts from the packaging and check each part with the pack contents section. Pay attention to the different models variations. - Page 7 u c e t i n s t a l l a t i o n Step 1 - Remove all mounting hardware 1. Shut off water supply and remove the hexagonal nut, the disk and the gasket. Do not remove the O-ring from the base of the faucet.
- Page 8 u c e t i n s t a l l a t i o n Step 3 - Connecting the water supply 1. Connect the red flexible pipe to the hot water supply and the blue flexible pipe to the cold water supply.
- Page 9 n g e a d j u s t m e n t The sensor range is the range an object can be away from the sensor in order to activate the faucet. The sensor is factory preset. If necessary, it can be adjusted as follows: Disconnect power supply Adjusting the sensor range: E or EM...
- Page 10 n g e a d j u s t m e n t 5. When the sensor enters into adjusting mode and your hand is in front of the sensor, a slow flashing of the red light at the front of the sensor will occur. 6.
- Page 11 t t e r y r e p l a c e m e n t i n s t r u c t i o n s Battery models only When the battery weakens, the red indicator light will blink at a constant rate when the user's hands come within the sensor's range.
- Page 12 t t e r y r e p l a c e m e n t i n s t r u c t i o n s Electronic unit 13. Reassemble the axis-assembly O-ring and tighten the Allen screw. 14.
- Page 13 i n t e n a n c e / s p a r e p a r t s Filter cleaning instructions This mixer is provided with a stainless steel filter preventing foreign particles to enter the lines. If the water flow has decreased, this may be because the filter is clogged.
- Page 14 o u b l e s h o o t i n g Problem Indicator Cause Solution No water comes out 1.Sensor flashes Low battery. Replace battery. of the tap: continuously when user’s hands are within the sensor’s range. 2. Red light in the 1.
-
Page 15: Warranty
r r a n t y L I M I T E D W A R R A N T Y This product is covered by a limited warranty of two years from date of purchase. During this period, STERN undertakes, at its option, to repair or replace any faults caused by defective materials or manufacturer defaults that may arise (see Stern Warranty). - Page 16 S T E R N E N G I N E E R I N G L T D. 15 gan rave Blvd. 81222 gan rave Y a v n e , i s r a e l tel: 9 7 2 – 8 – 9 3 2 6 0 0 0 fax: 9 7 2 –...
