Page 1
For your safety, please read before initial operation of the device the information through carefully. You get important Advice for proper operation and maintenance of your new device. VentomaxxInternational is not liable if the following instructions are not followed. Z-WRG RONDO IQ Montageanleitung Bedienungsanleitung WRG-System...
› Z-WRG RONDO IQ safety instructions Mounting instruction Page 3 General installation prerequisites Page 4 Mounting template for preparing the wall opening Page 5 Mounting the roughconstruction ring module set, Mounting Type LAW, straight through the wall Page 6 Mounting the roughconstruction ring module set, Mounting Type...
Page 3
Z-WRG RONDO IQ The Z-WRG RONDO IQ is designed for the ventilation of dry indoor rooms. Please make sure that the air outlet is not covered by any objects. A liability for other uses can not be accepted. To avoid moisture damage or injury to health, pay due attention to sufficient ventilation.
Page 4
› Preparation wall opening and electrical connection Z-WRG RONDO IQ Preparing for installation: The ventilation units of this series (max. 6 stations) be operated via a central control unit and a JY (ST) -Y 2x2x0.6 supplied with 12 volt low voltage.
Page 5
› MOUNTENING INSTRUCTION / Wiringplan Device Series: Z-WRG IQ Wiringplan Control Type: ZS-IQ Cross-Connector Type: CCA-IQ CCA-IQ Fan 6 CCA-IQ Fan 5 CCA-IQ Fan 4 CCA-IQ Fan 3 CCA-IQ Fan 2 CCA-IQ Fan 1...
Page 6
Façade close required (e.g. aluminum adhesive tape; sealing adhesive provided fixing points of the RS-LAW or attached Ventomaxx VX-FK sealing adhesive);at the top of the hood and sides of a Gasket on to the Façade to the wall is necessary.
Page 7
Bauphase keinen Schaden nimmt, Device unit The illustration shows a sollte diese bis zur Endmontage an einem Z-WRG RONDO IQ Sectional view of Z-WRG RONDO IQ geschützten Ort zwischengelagert werden. in mounted version LAL, Rough construction für die verdeckte Integration 8.
Page 8
› INSTALLATION INSTRUCTIONS / ELECTRICAL INSTALLATION Connection preparation ZS-IQ 1. Room side devices cabling Remove room-side plaster cover and Low voltage Connection further Low-voltage cable J-Y (ST) -Y strip the Z-WRG-units possible Extra- low voltage insulation.. (total max. 6) b) The wires shown beside Connection diagram on the cross-connector apply (short depression of Latch on the Clamp)
Page 9
› INSTALLATION INSTRUCTIONS / ELECTRICAL INSTALLATION Z-WRG RONDO IQ Circuit diagram of ZS-IQ control Functions ext Hygrostat active (Prog.0) ext Hygrostat active (Prog.1) SPEED STAGES 3/5 SPEED STAGES 2/4 SPEED STAGES 1/3 SPEED SELECTION Programming interface pot. ON LED: operating status on/ off green...
› MOUNTING INSTRUCTION Final assembly room side Low-voltage line at the station Remove plaster cover Low voltage power cable 2x2x0.6 in slot of the ring module bend upward, shorten to about 15 cm and removal of isolation; Low-voltage line connect Strip the wires b) Wires according to the diagram apply on the cross Connector...
Page 11
› OPERATION MANUAL Z-WRG RONDO IQ User condition a) left rocker: Device ON / OFF switching b) On the right rocker Should the desired speed selection take place LOW = small stage HIGH = big stage 2. Filter-Reset after filter change...
› TECHNICAL DATA TECHNICAL DATA Z-WRG-RONDO IQ Series / device version Z-WRG Rondo IQ / LAW Regulation / control ZS-IQ / via light switch program Power levels selectable 1|3 2|4 3|5 17 m /h Air power level 1 22 m /h...
Page 13
› TECHNICAL DATA TECHNICAL DATA Z-WRG-RONDO IQ Series / device version Z-WRG Rondo IQ / LAL Regulation / control ZS-IQ / via light switch program Power levels selectable 1|3 2|4 3|5 17 m /h Air power level 1 22 m /h...
