Summary of Contents for Cosmos SDM-72
- Page 1 SDM-72 Portable Grease Steel Dust Meter Model SDM-72 Instruction Manual Please keep this instruction manual available for quick reference when needed. Before use, carefully read this instruction manual and fully understand the content. Instruction Manual No.: SDM-72CEET...
-
Page 2: Table Of Contents
- TABLE OF CONTENTS - Introduction Features Safe Operation Component Names and Functions 4-1. Exterior View 4-2. Component Names and Functions Operation Procedures 5-1. Installing Batteries 5-2. Battery Check 5-3. Measurement 5-4. Collection of Grease Sample 5-5. How to Fill the Sampling Container Troubleshooting Specifications Handling &... -
Page 3: Introduction
1. Introduction We thank you for purchasing the Portable Grease Steel Dust Meter Model SDM-72 for the measuring of steel dust in the lubricating grease. The Portable Grease Steel Dust Meter employs a magnetic balance type electromagnet induction method as the measuring principle, and is a useful simplified diagnosis tool for the inspecting the abrasion status of the bearings and gears. -
Page 4: Features
2. Features ♦ The employed magnetic balance type electromagnetic induction method is a highly sensitive for the detection of the abrasion in the initial stage. ♦ Suitable for diagnose of irregularity in the ultra slow speed revolution range where diagnosis by vibration method is difficult. ♦... -
Page 5: Exterior View
4. Component Names and Functions 4-1. Exterior View... -
Page 6: Component Names And Functions
4-2. Component Names and Functions Name Functions Rotate the switch to “MEAS” position to commence measurement, with the Change-over sampling container removed from the selector switch instrument. To check the voltage level of the batteries, rotate the switch to “BATT” position. Insert port for sampled grease. -
Page 7: Operation Procedures
5. Operation Procedures 5-1. Installing Batteries Open the battery compartment cover located on the lower right side of the instrument, press and slide off the cover, secure a fresh set of 4 AA size (LR6) alkaline dry batteries, and carefully observe the battery polarity illustration inside the battery compartment to make sure that the batteries are installed correctly. -
Page 8: Battery Check
5-2. Battery Check Rotate the selector which from the “OFF” position to the “BATT” position, the LCD display will indicate - - - - for a period of 2-3 seconds, then the voltage of the battery will be displayed. Examples of battery voltage display. (Battery voltage = 5.6V) 5. -
Page 9: Measurement
5-3. Measurement Rotate the selector switch to “MEAS” and shift to the measurement mode. Check to see that the display indicates 0. 000 , then insert the sampling container containing the sample grease into the sample port. (Refer to 5-4. regarding procedures for the collection of sample grease.) * The sampling container must be inserted with the collected grease facing upward (same direction as the front surface of the... - Page 10 When the sampling container with the holder is removed from the sample port, the display will return to zero 0.000 by the auto zeroing adjustment function. After the measurement has been completed, make sure to return the selector switch to “OFF” position. Caution When the reading exceeds the upper limit of the numeral display reading (approximately 6.5%Wt), the display will indicate...
-
Page 11: Collection Of Grease Sample
Caution • This instrument employs the electromagnetic induction method as the measuring principle, and should not be operated in the vicinity where a strong electromagnetic wave is generated. (Example: inverter controlled motor, welding machine, electric spark machine) It is recommended to conduct measurement in a location not effected by such electrical equipment. -
Page 12: How To Fill The Sampling Container
5-5. How to Fill the Sampling Container The sample container has a Grease quantitative groove to accommodate the waste grease sample, use the spatula and fill this groove with a sufficient amount of waste grease. Spatula Scrape off the excessive grease Use the edge of the spatula and scrape off the excessive waste grease to obtain a quantitative... -
Page 13: Troubleshooting
6. Troubleshooting Problems, which may be experienced during the use of the Grease Steel Dust Meter SDM-72, are listed in the table below, together with indications of probable causes and recommendations for corrective actions. Contact our authorized distributor if your problem is not listed or when the remedy fails to correct the problem. -
Page 14: Specifications
7. Specifications Items Specifications Remarks Model SDM-72 Measuring Magnetic balance type electromagnetic principle induction method. Concentration of iron particles in the waste To measure grease. Measurement %Wt = 0 – 5.000 %Wt range weight ratio% Display 4 digit liquid crystal display Minimum 0.001 %Wt... -
Page 15: Handling & Storage
8. Handling & Storage CAUTION • This instrument is not explosion-proof. It must be used in a safe location. • Remove the batteries and store the instrument if it is not be used for a long time. • Do not disassemble or modify the instrument or change the structure or electric circuits. -
Page 16: Warranty
The remedies set forth herein are exclusive. New Cosmos warrants to the original purchaser and no other person or entity (customer) that gas detection product supplied by New Cosmos shall be free from defects in materials and workmanship for a period of one (1) year from the date of purchase. -
Page 17: Appendix
Appendix Reference Materials 1. Measuring Principle The measuring principle of the magnetic balance electromagnetic induction method is shown in the illustration below, the magnetic circuit sensor is composed of an exciter coil connected to the both sides of the detection coil, the magnetic field generated by both exciter coils are blanketed in the vicinity of the center detection coil. -
Page 18: Metal Materials Measurable
2. Metal Materials Measurable Table 1 of Metal Materials that can be Measured (○:Measurable, ×:Not measurable) Metal and Materials Magnetism Measurable Remarks Iron, nickel, cobalt Ferromagnetism ○ Aluminum, chrome, manganese, titan, Para magnetism × stainless steel (SUS-304, SUS-316) Copper, silver, lead, Diamagnetic ×... -
Page 19: Practical Use
3. Practical Use 3-1. Management and Simplified Diagnosis of Grease Lubricated Bearings & Gears ♦ To be used to diagnose the steel dust contents in the grease applied for lubrication of low speed rotation to high speed rotation machinery. Most useful for the diagnosis of the abrasion of the bearing and gears used at low speed rotation and difficult to diagnose with the vibration method, and to improve the accuracy of diagnosis when jointly used with the vibration method for medium and high speed... -
Page 20: Correlation Between The Abrasion Of The Bearing And Steel Dust Concentration In The Grease
3-2. Correlation between the Abrasion of the Bearing and Steel Dust Concentration in the Grease. Table 2 shows the inspection results of correlation between the abrasion of the bearing and steel dust concentration by disassembling and inspecting the bearing of various rotating machinery such as motors, pumps and blowers. -
Page 21: Cycle Of Measurement
3-4. Cycle of Measurement The cycle of measurement of the grease steel dust concentration is related to collection of extracted grease at the cycle of lubrication of fresh grease to the rotating machinery. The cycle of grease application would differ with the kind and the specifications of the rotating machinery used, and must be determined with the condition of operation, the table below show an example of the cycle of measurement. - Page 22 The management trend is possible by obtaining the increase trend of steel dust concentration in the early stage of abrasion, by conducting an appropriate lubrication countermeasure at the early stage of abrasion, for the life extension of the bearing. The graph below shows the management trend of the steel dust concentration at the stage of insufficient lubrication of the bearing used in an agitator.
- Page 23 Edition No. Date Change SDM-72 CEET June, 2008 Additional copies of this operation manual are available. Contact the following address for ordering information. Distributor: Manufacturer: New Cosmos Electric Co., Ltd. 2-5-4 Mitsuiya-naka, Yodogawa-ku, Osaka 532-0036, Japan TEL: +81-6-6309-1505 FAX: +81-6-6308-8129 http://www.new-cosmos.co.jp/en/index.html...
