tacwise Master Nailer 191EL PRO Instruction Manual

Distributed by
J W Ross
A superb electric nailing/stapling gun which fires 180 nails from 15-35mm and 91 staples from
SUITABLE APPLICATIONS: Softwood & hardwood applications, MDF, Hobby/Crafts. Fine decorative trim, beading
and mouldings. Tongue & Groove panelling. Cabinet and plywood assembly, garden furniture and trellis work,
door/window assembly, hardwood flooring, panelling and trims. Plasterboard, picture/mirror frames. Sub-flooring
and many more...
NAILS 15mm-35mm
15mm/20mm/25mm
/30mm/32mm/35mm
STAPLES 15mm-30mm
15mm/20mm
/25mm/30mm
to nail into tight corners/grooves
PRODUCT SPECIFICATIONS
Input Voltage
Max. Firing speed
Max. Length of nail
Max. Length of staple
Max. Magazine Capacity
Nail/Staple Type (IMPORTANT)
Approvals
DIRECTIONS FOR USE
Step one: Loading your Master Nailer
1. Unplug from power source.
2. Only use Tacwise 180 Type Nails and Tacwise 91 Type
Staples which are designed especially for this machine.
3. Slide the pusher backwards from position B to position A by
releasing the catch (1).
4. Nails & Staples - tilt the gun at 45˚ angle and place the
nails/staples so that the top of the nail/crown of the staple is
in the uppermost of the magazine.
5. Push feeder back until release catch clicks.
MASTER NAILER
15-30mm quickly and neatly.
Professional driver
blade system
Long protruding nose
Rubber protector
for soft surfaces
: 220-240 volts 50 Hz
: 4-Nails/Staples-per second
: Up to 35mm long (fires six lengths)
: Up to 30mm long (fires four lengths)
: Holds up to 100 nails or staples
: Use Tacwise Nails Type 180 and Tacwise Staples Type 91 only
:
TM Pro 191EL
TM
TM 191EL PRO
Rubberised Soft rubber
safety handle grip
trigger
All metal professional
nose safety system
Position A
Long
powercord
On/off
switch
Professional
quick release
reload catch
Position B
Magazine
Track
Catch
45º
