- Page 1 CARLO GAVAZZI A u t o m a t i o n C o m p o n e n t s T2000 SERIES PID TEMPERATURE CONTROLLER C G I T e m p w a r e S o f t w a r e M a n u a l...
-
Page 2: Table Of Contents
INDEX KEY TO PROGRAM ICONS OVERVIEW INSTALLATION/CABLING RS232 RS485 Termination resistors Bias resistors RS232/RS485 features INSTRUMENT COMMS SETTINGS CONFIGURING INSTRUMENT COMMS SETTINGS 10-11 INSTALLING SOFTWARE 12-13 GETTING STARTED INSTRUMENT SCREENS PC COM PORT SETTINGS 16-17 INSTRUMENT PARAMETER CONFIGURATION SOFTWARE ALARMS SETPOINT ADJUSTMENT INSTRUMENT CLONING SAVING SETTINGS TO FILE... -
Page 3: Key To Program Icons
Key to Program Icons Change comms settings & Print chart recorder Create new file start monitoring Toggle Modbus comms Open existing file Scroll chart up 100% de-bug window Add new instrument Export file in text format Scroll chart up 10% Find chart zero Add new instrument Select units to record... -
Page 4: Overview
OVERVIEW CGI Tempware is a graphic WINDOWS based software PC Requirements package designed for PC supervision of Model T20321 / T20161 and Model T20162 controllers. It offers the To gain the full benefit of CGI Tempware software, it is capability of remote adjustment, instrument configuration, recommend that the PC is fitted with a Pentium processor cloning, saving and retrieving instrument settings to files and is running WINDOWS 95 or Windows NT programs. -
Page 5: Installation/Cabling
Installation/Cabling RS232 Connections 10 11 12 13 14 15 PC Com 1 Port 3300/9300 COM port rear terminal DB-9 Pin RS-232 Is the standard most widely used for interfacing peripherals to PC's and is designed for serial communications with single instrument up to a distances of 15 metres, in a low electrical noise environment. -
Page 6: Rs485
Installation/Cabling RS485 Connections RS-485 Is a half duplex serial communications link and is the standard most commonly used for industrial applications due to it's high noise immunity and multi-drop capability. It enables a PC to communicate with up to 128 instruments over distances up to 1200 metres, and requires the addition of an RS-485 interface card, or a separate RS-232/485 converter. -
Page 7: Termination Resistors
Installation/Cabling Each RS485 interface has specific connection and termination biasing requirements which will be detailed in their installation instructions. The general principles are as follows. Terminations Because each wire is a transmission line, it must be properly terminated to prevent reflections. Where multiple instruments are daisy-chained together, a 120 ohm terminating resistor should be fitted at the connection to the PC and to the last instrument in the chain. -
Page 8: Bias Resistors
Installation/Cabling Bias resistors When transmission lines are not transmitting, they remain in an indeterminate state which can allow receivers to receive invalid data bits due to electrical noise on the cable. To prevent this, the the lines should be forced Bias resistors Instrument 1 Instrument 2... -
Page 9: Rs232/Rs485 Features
Installation/Cabling For a continually updated list of recommended RS-485 interface cards, contact Carlo Gavazzi. Feature RS232 RS485 Type of transmission lines Unbalanced Differential Maximum number of drivers Maximum number of receivers Maximum cable length 1200M Maximum data rate 19.2Kb/sec 19.2Kb/sec... -
Page 10: Instrument Comms Settings
Instrument Comms Settings Immediately after power-up, both instrument, and PC comms (Debug). Commissioning and DBUG settings need to be made compatible before communication troubleshooting aid. Display shows between them is possible. Instrument defaults are shown when the instrument is transmitting or below together with the available options. -
Page 11: Configuring Instrument Comms Settings
Configuring Instrument Comms Settings This should also be done immediately after power-up, and Note: Level C is only visible when the comms interface is only possible from the instrument front panel. board is fitted to the unit On power-up the controller will display the self test To set up Instrument comms address sequence followed by Alternating and nonE... - Page 12 Configuring Instrument Comms Settings To enter settings into memory Press and hold for 3 seconds display alternates and nonE INPT To check settings; repeat the above procedure The unit is now ready to be configured from the PC. Note: Where more than one instrument is connected to the system, it is useful at this point to list them by location, title and comms address.
- Page 13 2. Click the Control Panel icon then double click on the Type in Command line panel using syntax Add/Remove Programs icon. exactly as shown: 3. Click on the Install button and follow the screen "c:\Program Files\Carlo Gavazzi\ prompts. CGI Tempware\CGI Tempware.exe" Click Next In Select name for shortcut panel the text will appear;...
-
Page 14: Installing Software
Installing Comms Software (continued) To delete a shortcut, Click on the desktop icon then press the delete key... -
Page 15: Getting Started
Getting Started Start the program running from either; ADDING INSTRUMENTS Windows Start menu Click the appropriate Add New Instrument icon to Shortcut icon (if created during call up the type and number of instruments that CGI Tempware installation) are to be shown on the screen. Each click This will open the CGI Tempware window. -
Page 16: Instrument Screens
CGI Tempware Instrument Screens... -
Page 17: Pc Com Port Settings
PC Com Port Settings When the instruments are positioned on the screen, they are will automatically configure the com port settings. Where an automatically numbered in sequence Inst.1, Inst.2 etc. Each RS485 PC card is being used, refer to the manufacturers one can be individually named in it's own title bar, and must installation instructions. - Page 18 PC Com Port Settings (continued) Wait!! For update to be fully completed by observing the Uploading bar turning from red to green in the CGI Tempware Instrument screen. This may take several seconds. Check Virtual instrument display readings against real instrument readings. If the check is satisfactory, proceed with Instrument Parameter Configuration...
-
Page 19: Instrument Parameter Configuration
Instrument Parameter Configuration The instrument(s) will not be operational until configured Check The Enable Display Mimics box if you with the following basic settings. want the virtual instrument to mimic all * Sensor type actual instrument displays as well as * Units of measurement reading setpoint and process values. -
Page 20: Setpoint Adjustment
Instrument Parameter Configuration (continued) the main manual.Autotune routines can be found on page 7. To set Software Alarms (in User Level) Adjust Spin buttons in Low Alarm/ High Alarm SETPOINT ADJUSTMENT boxes to set the required high/low level Check The Enabled boxes. During normal use, instrument setpoints can be adjusted from the CGI Tempware instrument screen, by using the TO ENTER THE ABOVE INSTRUMENT PARAMETER SETTINGS... -
Page 21: Instrument Cloning
Instrument Cloning When a satisfactory instrument configuration has been Cloning Settings to another instrument on the bus. achieved, either from the initial configuration with the basic parameter settings, following Autotune or other further Right Click in the display window of the instrument adjustments, these settings can be cloned to other that settings are to be cloned from. -
Page 22: Saving Settings To File
Saving/Retrieving Instrument/Application Settings Saving the settings of a single instrument Opening an Existing Application File Click Save in the menu bar of the Internal Click File in the menu bar, then Open Parameters for Inst.n screen Application from menu Type Your filename in the File name box Click File name to select application from the... -
Page 23: Security Lockouts
Security Lockouts When the instrument parameters have been established you may wish to password protect the settings against accidental or unauthorised adjustment. It is possible to make individual protection for each instrument function at each level, and for each instrument on the network Please study the lock hierarchy diagram below before implementing your security strategy. - Page 24 Lock button, and in the Lock User Level Parameter window, locked, it will still be possible to make adjustments from the PC. Check either the individual boxes of all the If you forget your password, please contact Carlo Gavazzi.
-
Page 25: Logging And Charting
Logging and Charting The CGI Tempware software is capable of logging readings From the CGI Tempware instrument screen. from up to 128 instruments which it stores in data files. The Click the add new chart recorder icon in the data can be exported into text files which will enable the menu bar, and in the Chart recorder data to be displayed in c.s.v. - Page 26 Logging and Charting (continued) using the Add to Custom Color feature. Click the OK box in the color screen. Click the transfer button to list them in the In the Sample Frequency panel, Instruments to record table. For each Click the spin buttons to set the log reading instrument to be charted from, double frequency.
- Page 27 Click the buttons in the deg C/F box to set up Click the buttons to move the chart up or a suitable temperature scale in the chart down by 10% Y axis. Click the buttons in the time/div box to set Click the buttons to move the chart up or down by 100%...
- Page 28 Click the make chart bigger or make chart option in the chart screen and the chart smaller icons to adjust the size of the option in the instruments screen. chart on your screen. Click the pause button to stop logging and Click in the chart recorder blue title band, and stop the chart recorder.
-
Page 29: Log On Change
Other Logging and Charting Options The chart will now only register out of LOG-ON-CHANGE (ONLY LOG/CHART OUT OF LIMITS READINGS) limits readings which will be separated This feature reduces the size of log and chart files by by grey vertical bands signifying periods ignoring readings that are within adjustable specified limits. - Page 30 Saving Charts The chart recorder screen will open with To stop recording the chart settings returned to default. If preferred, reset the chart to your Click Either the close button or from the original settings, then; menubar chose File then Exit. The file Click Append button to add the new readings will automatically be saved with the...
-
Page 31: Exporting Log Files
Options in the menu bar. This will open the Windows print screen. Click the properties C:\Program Files\Carlo Gavazzi\CGI Tempware\ button to select landscape setting. If changes in appearance are required, review the logging and charting section. -
Page 32: Trouble Shooting
Trouble Shooting Error Message Fault Suggested remedy Comms error Check that the comms address setting of the real and the virtual instruments are the same. _ _ _ _ Comms inactive Make sure that comms is open. Click Change comms settings and start monitoring icon. -
Page 33: Glossary Of Terms
Glossary of Terms The following definitions apply to terms as they are use in Comms Abbreviation of serial communications. this manual, and have been worded for ease of Daisy chain The method of connecting instruments understanding. They may differ in detail to definitions together. - Page 34 Glossary of Terms Glossary of Terms (continued) P.C. Personal computer, desktop or laptop. Protocol See Modbus. Radio button A PC "screen" switch shaped like a push button that can be clicked and off RS232/RS485 Sometimes EIA232/EIA485 defines the two standards for serial communication. More detail can be found under Installation/Cabling.
- Page 35 Over a Twisted Pair • Up to 6 Miles (10km) Send It Switch It CARLO GAVAZZI INC. A u t o m a t i o n C o m p o n e n t s 750 Hastings Lane, Buffalo Grove, IL 60089-6904 Phone 847.465.6100...
