HVAC Control Made Simple
CoolPlug CooLinkHUB
HVAC Bridge
Quick Installation Guide
Version 2.2
11/07/19
Document Number: 2.2
Contact information:
info@coolautomation.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CoolPlug and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cool Automation CoolPlug

Summary of Contents for Cool Automation CoolPlug

  • Page 1 HVAC Control Made Simple CoolPlug CooLinkHUB HVAC Bridge Quick Installation Guide Version 2.2 11/07/19 Document Number: 2.2 Contact information: info@coolautomation.com...

  • Page 2: Table Of Contents

    14. CoolPlug Operation ..................... 23 14.1 CoolPlug Indicators ..................23 14.2 CoolPlug Normal Operation ................23 15. Wireless CoolPlug & CooLinkHUB – Installation Guidelines ........25 15.1 Rebuilding the wireless mesh network .............. 26 16. Mounting the CoolPlug ....................27 QIG Version 2.2...
  • Page 3 CoolAutomation for support. Unauthorized modifications or repairs may result in electric shock or fire. Do not expose the CoolPlug or CooLinkHUB to moisture. Water can damage the CoolPlug or CooLinkHUB resulting in an electrical components failure, electric shock or fire.
  • Page 4 CoolPlug CooLinkHUB HVAC Bridge CooLinkHUB + CoolPlug Do not use flammable materials (e.g. hairspray or insecticide) near the CoolPlug or CooLinkHUB. Do not clean the CoolPlug or CooLinkHUB with organic solvents such as paint thinner. Use only a dry cloth to wipe if necessary. The maximum voltage that can be directly applied to the CooLinkHUB is 24V DC.

  • Page 5: Coolinkhub + Coolplug

    CooLinkHUB + CoolPlug System Overview The CooLinkHUB + CoolPlug is a solution for complete integration of Multi-Split and Mini- Split HVAC units. The CoolPlug - HVAC designated adapter, connects directly to the HVAC indoor unit on one side, and to the CooLinkHUB on the other, via a PBUS Network.

  • Page 6: What's In The Box

    ▪ Power supply (Universal or EU – according to SN) 1.4.2 CoolPlug ▪ CoolPlug Unit ▪ CoolPlug back plate for adding two magnets ▪ CoolPlug back plate for adding two stamps ▪ Two stamps ▪ Two magnets ▪ Optional: Terminal cable (according to the specific plug model as indicated on the above table.

  • Page 7: Connecting Coolplug

    S21 on Control Board. 2 Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of the PBUS cable between CoolPlug terminals [-], [1] and [2], and CooLinkHUB terminals [VDC-], [1] and [2], respectively. * See page 5 for system overview, no point-to-point connectivity required.

  • Page 8: Connecting Coolplug Dk (Daikin)

    Connecting CoolPlug DK (Daikin) DK (Daikin) – P1 P2 1 Connecting the CoolPlug to the Daikin unit Connect the CoolPlug’s [P1], [P2] terminals to the [P1], [P2] terminals on the indoor unit.* 2 Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of the PBUS cable coming from the [VDC-], [1] and [2] terminals on the CooLinkHUB to the corresponding [-], [1] and [2] terminals on the CoolPlug, respectively.

  • Page 9: Connecting Coolplug Dks

    DK (Daikin) – Siesta Series Connecting the CoolPlug HVAC Line to the Daikin Siesta Indoor Unit Connect the cable, supplied with the CoolPlug, to the port labeled “Indoor” on CoolPlug and the corresponding connector on the indoor unit. 2 Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of the PBUS cable, using [VDC-], [1] and [2] terminals on the CooLinkHUB, to the corresponding [-], [1] and [2] terminals on the CoolPlug.

  • Page 10: Connecting Coolplug Pn/Sa/To

    Panasonic | Sanyo | Toshiba Connecting the CoolPlug HVAC Line to the PN/SA/TO Indoor Unit Connect the CoolPlug’s [A], [B] terminals to [A], [B] terminals on indoor unit. * To connect to Panasonic indoor unit, use R1 R2 terminals. Connecting the CoolPlug to the CooLinkHUB...

  • Page 11: Connecting Coolplug Fj

    2 Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of the PBUS cable, using the [VDC-], [1] and [2] terminals on the CooLinkHUB, to the corresponding [-], [1] and [2] terminals on the CoolPlug. Optional: Connect the Wired Remote Controller (W.R.C.) * For indoors that work with APG000 or compatible W.R.C.

  • Page 12: Fj (Fujitsu/General) - Option 2

    Connect the CoolPlug’s [W1], [B1], [R1] terminals to indoor unit. Consult HVAC manufacturer’s Installation Manual for instructions. Optional: Connect the CoolPlug’s [W2], [B2], [R2] terminals to the Fujitsu Wired Remote Controller (W.R.C.) * For indoors that work with EZ-099 or compatible type wired remote controllers.
  • Page 13 FJ (Fujitsu/General) - Option 3* Connecting the CoolPlug HVAC Line to the Fujitsu Indoor Unit Connect the CoolPlug’s [W1], [B1], [R1] terminals to the corresponding terminals on the indoor unit, keeping the wire colors consistent. Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of the PBUS cable, using the [VDC-], [1] and [2] terminals on the CooLinkHUB, to the corresponding [-], [1] and [2] terminals on the CoolPlug.

  • Page 14: Connecting Coolplug Me (Mitsubishi Electric)

    Option 1 – CN-105 Connecting the CoolPlug HVAC Line to the Mitsubishi Indoor Unit Connect the ME CN-105 cable, supplied with the CoolPlug, between the CoolPlug RJ- 11 connector and the CN-105 port on the indoor unit’s Control Board. Consult the HVAC manufacturer’s installation manual for the location of the CN-105 port on the Control...

  • Page 15: Connecting Coolplug Mh (Mitsubishi Heavy)

    Option 2 – [1] [2] Connecting the CoolPlug HVAC Line to the Mitsubishi Indoor Unit Connect the CoolPlug’s HVAC [1], HVAC [2] terminals to the [1], [2] terminals on the indoor unit. Consult the HVAC manufacturer’s installation manual for the location of the [1] and [2] terminals.

  • Page 16: Connecting Coolplug Ht (Hitachi)

    Connecting CoolPlug HT (Hitachi) Connecting CoolPlug HT (Hitachi) 1 Connecting the CoolPlug to the Hitachi unit Connect the CoolPlug’s HVAC [1], [2] terminals to the [1], [2] terminals on the indoor unit. 2 Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of the PBUS cable coming from the [VDC-], [1] and [2] terminals on the CooLinkHUB to the corresponding [-], [1] and [2] terminals on the CoolPlug.

  • Page 17: Connecting Coolplug Lg (Lg)

    2 Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of the PBUS cable between CoolPlug terminals [-], [1] and [2], and CooLinkHUB terminals [VDC-], [1] and [2], respectively. Optional: Connect the Wired Remote Controller (W.R.C.) in parallel mode.

  • Page 18: Connecting Coolplug Gree (Grts)

    W.R.C. cable to the CoolPlug’s W.R.C. port. 3 Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of PBUS cable between the CoolPlug terminals [-], [1] and [2], and the CooLinkHUB terminals [VDC-], [1] and [2], respectively. QIG Version 2.2...

  • Page 19: Gree Option 2

    CoolPlug. Then connect the CoolPlug adapter to the CoolPlug W.R.C. port. 3 Connecting the CoolPlug to the CooLinkHUB Connect the signal wires of the PBUS network cable between CoolPlug terminals [-], [1] and [2], and CooLinkHUB terminals [VDC-], [1] and [2], respectively.

  • Page 20: Gree Option 3 (H1,H2)

    11.3 Gree Option 3 (H1, H2) Connecting the CoolPlug HVAC line to the Gree Indoor Unit Connect the CoolPlug’s H1, H2 terminals to terminals H1 and H2 on the indoor unit. Consult HVAC manufacturer’s Installation manual for location of terminals H1 and H2.

  • Page 21: Connecting Home Automation, Bms & Coolremote

    CoolPlug CooLinkHUB HVAC Bridge Connecting Home Automation, BMS & CoolRemote 12. Connecting Home Automation, BMS & CoolRemote QIG Version 2.2 CoolPlug CooLinkHUB...

  • Page 22: Coolremote App

    CoolPlug CooLinkHUB HVAC Bridge CoolRemote App 13. CoolRemote App Connect the device to the Internet for registration and setup. Option A – Automatic Scan the QR code from the type label to auto fill-in all the CooLinkHUB details for the CoolRemote App.

  • Page 23: Coolplug Operation

    14. CoolPlug Operation 14.1 CoolPlug Indicators The three LEDs that surround the CoolPlug’s push-button provide information about the CoolPlug configuration and status. After applying power to the CoolPlug the Firmware version is displayed by flashing LEDs followed by the operational state of the system.
  • Page 24 CoolPlug CooLinkHUB HVAC Bridge CoolPlug Operation Determining the CoolPlug UID The CoolPlug UID is flashed after one ‘Short’ press on the CoolPlug push- button. Toggling the HVAC ON/OFF Toggle the HVAC state ON/OFF with one ‘Long’ press on the CoolPlug push-button.

  • Page 25: Wireless Coolplug & Coolinkhub - Installation Guidelines

    To successfully pair the CooLinkHUB to the CoolPlug they must be in line-of-sight proximity one to the other (no more than three meters). The CoolPlug is powered from the HVAC terminal. It can also be powered via USB during the setup process (either from a PC or the CooLinkHUB).

  • Page 26: Rebuilding The Wireless Mesh Network

    Upon successful reconnection, the expected number of CPs is displayed on the screen in L5 GXXX (as in the image below). Note: To reconnect devices, no actions need to be performed on the CoolPlug devices. QIG Version 2.2 CoolPlug CooLinkHUB...

  • Page 27: Mounting The Coolplug

    On the Wall Attach the CoolPlug back plate to the wall using screws as shown. The wires can be fed through the hole in the center of the cover or from the side as shown.
  • Page 28 CoolPlug CooLinkHUB HVAC Bridge Mounting the CoolPlug Need more help? Visit us: https://coolautomation.com/support HVAC Control Made Simple QIG Version 2.2 CoolPlug CooLinkHUB...
