Becker BDP-90 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BDP-90
digital piano
owner's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BDP-90 and is the answer not in the manual?

Questions and answers

Related Manuals for Becker BDP-90

Summary of Contents for Becker BDP-90

  • Page 1 BDP-90 digital piano owner’s manual...
  • Page 3 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK OR INJURY: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated or “dangerous voltage”...
  • Page 4 Take Care of Your Piano This digital piano will supply you with years of musical enjoyment if you follow the simple rules listed below. For Veneer Style Wood finish a standard polish WARNING is “pledge” is acceptable. When using electrical products, basic safety •...

  • Page 5: Table Of Contents

    CONTENTS TABLE PORT ...............................8 CONTROL PANEL ..........................9 START PLAY ............................11  MASTER VOLUME ........................11  BALANCE.............................11  DEMO............................11  SONG ............................11 VOICE & RELEVANT .........................13  VOICE ............................13  LAYER VOICE ..........................13  SPLIT LOWER..........................13 STYLE & RELEVANT.........................15  RHYTHM ............................15 ...
  • Page 6 INSTALLATION ①: Screw M6*20 (4pcs) ②: Screw M4*12 (4pcs) ③: Tape Screw 4*16 (4pcs) ④: Hand Screw (4pcs) ⑤: Tape screw 4*12 (2pcs) ⑥: Headphone Holder (1pcs) Step1: Install the pedal cross bar to the side board with the screw ① Put screw ①...
  • Page 7 Step3: Install the piano body There is location stud in the bottom of piano body and bracket with notch in the top of the side board. Put piano on the assembled stand, behind the front edge about 2 inches. Move piano body towards to make stud insert to the notch Step4: Install the stand assembly to the piano body with the screw ④...
  • Page 8 Step5: Put screw ② in and tighten up Put screw ④ in and tighten up Step6: Install the headphone holder ⑥ to the piano with the screw ⑤ Holder ⑥ Put screw ⑤ in and tighten up NOTES: Unplug the piano during lightning storm or when unused for long periods of time. Avoid plugging the AC adaptor into the same AC outlet as appliances with high power consumption, such as electric heaters or ovens...

  • Page 9: Port

    PORT The following socket board is located on the back of the piano. 1. USB — This USB port is for communicating with a computer through a USB cable. 2. LINE OUT — This interface provides stereo audio output to an external amplifier (such as speaker).

  • Page 10: Control Panel

    CONTROL PANEL 1. MASTER VOLUME — Rotate knob to the right can increase the main volume; rotate knob, reduce the main volume to the left. 2. BALANCE — Rotate knob to the right can make the volume of Accomp/Song/ Lower Voice increases;...
  • Page 11 10. RHYTHM — The drum style will start as soon as you press the RHYTHM button. 11. METRONOME — With the metronome function to help cultivate a good rhythm sensation when playing. 12. EFFECT — The effect of Reverb and Chorus can be set with this function. 13.

  • Page 12: Start Play

    START PLAYING MASTER VOLUME The main volume can be adjusted according to your need. Rotate knob to the right can increase the main volume; rotate knob to the left, reduce the main volume. BALANCE The volume of Layer/Lower voice/Style/Song can be adjusted with this knob. Rotate knob to the right to increase volume;...
  • Page 13  EXIT SONG MODE In song mode, press the SONG button again to exit song mode.  PARCTICE THE SONG LEFT HAND: Press the LEFT button to reduce the volume of the song’s left part, the light will put out, at this time, you can practice the left hand part while the right hand melody playing.

  • Page 14: Voice & Relevant

    VOICE & RELEVANT FUNCTIONS VOICE This piano has total of 195 voices which can be selected by 8 voice shortcut buttons and +/- buttons. The screen will display the voice number and name. You can select the upper or lower voice of each shortcut； According to the voice shortcuts, select the upper voice when the indicator light on or the lower voice with the indicator flashing.
  • Page 15  SPLIT LOWER VOICE SELECTION There are 13 split lower voices in the piano. You can select it with +/- buttons. The screen will display the voice number and name. Split lower voice list: NAME NAME NAME Bass & Ride Pizzicato New Age Fretless Bass...

  • Page 16: Style & Relevant

    STYLE & RELEVANT FUNCTIONS RHYTHM  START/STOP A RHYTHM STYLE Press the RHYTHM button with the indicator light on, the rhythm begins. Press the RHYTHM button again, the indicator turn off, the rhythm will be stopped and exit the rhythm mode. Also you can press the START/STOP button to control the style when playing. It won’t exit the rhythm mode.
  • Page 17 CHORD LIST: CHORD TYPE CHORD NAME CHORD NOTE DISPLAY 1-(3)-(5) Major [M] 1-(3)-5-6 Major sixth [6] 1-(3)-(5)-7 Major seventh [M7] CM7#11 1-(2)-3-#4-(5)-7 CM7#11 Major seventh sharp Eleventh [M7#11] Cmadd9 1-2-3-5 CM (9) Major add ninth [Madd9] 1-2-3-(5)-7 CM7 (9) Major ninth [M9] C6 9 1-2-3-(5)-6 C6 (9)

  • Page 18: Panel Controls

    PANEL CONTROLS TEMPO  TEMPO & BEAT When styles, songs or demos are playing, the indicator of TEMPO will hint the beat or tempo.  TEMPO ADJUST Press the TEMPO button and change the tempo value with +/- buttons, the screen will display the value of tempo.

  • Page 19: Effect

    EFFECT REVERB  REVERB ON/OFF The reverb effect is open by default, and the indicator light is on. You can press the REVERB button to exit reverb effect, and indicator turns off.  REVERB LEVEL SELECTION Press the REVERB button with the indicator light on，the screen displays the level of reverb, you can change the level value with +/- buttons and press +/- buttons at the same time to recover the default value 6.
  • Page 20  MICROPHONE LEVEL Press the FUNCTION button to enter “MIC.IN.LEVEL” mode, the range is 0—127, if you press +/- buttons at the same time, the piano will recover the default value “100”.  MICROPHONE REVERB Press the FUNCTION button to enter “MIC.REVERB” mode, the range is 0—127, if you press +/- buttons at the same time, the piano will recover the default value “2”.
  • Page 21  MICROPHONE COMPRESSOR Press the FUNCTION button to enter “MIC. COMPRESSOR” mode, there are 9 types of compressor to select: VALUE NO. TYPE Compressor1 Compressor 2 Compressor 3 Compressor 4 Compressor +Extender5 Compressor +Extender 6 Limiter1 Limiter 2 Limiter 3 If you press +/- buttons at the same time, the piano will recover the default value “0”...

  • Page 22: Record

     VOCAL GRADE There are vocal scores for practicing each song. Press the FUNCTION button to enter “VOCAL GRADE” mode, Press the + button to open the VOCAL GRADE or the – button to close the VOCAL GRADE.  FACTORY RESET You can restore the system of piano to the default setting directly with this function (this also deletes recording data).

  • Page 23: Pedal

    PEDAL 1. SOFT PEDAL When the left pedal is pressed, the piano volume is reduced and the sound slightly softened on the notes played. 2. SOSTENUTO PEDAL The function of it is similar to the sustain pedal. When playing notes then middle pedal is pressed, the notes will be sustained.

  • Page 24: Appendix

    APPENDIX ACCOMP LIST： STYLE STYLE BEAT & BALLAD ROCK 4/4 Ballad Easy Rock 16 Beat Folk Rock Love Ballad Hard Rock Pop Beat 1 70sRock&Roll Pop Beat 2 Heavy Meatl Pop Beat 3 Slow Rock Easy Pop Blues 8 Beat Slow Blues 50’s Ballad Boogie...
  • Page 25 STYLE STYLE Country1 Tango Country2 Reggae CountryBlues New Reggae TRADITIONAL Dixieland Ragtime 6/8 March Twist March Foxtrot Polka1 LATIN Polka2 Pop Bossa Mexico Polka Cool Bossa Kids1 Fast Bossa Kids2 Bossanova German Waltz New Cha Cha Vienna Waltz Cha Cha Laendler New Rhumba Waltz...
  • Page 26 VOICE LIST: NAME DISPLAY NAME DISPLAY PIANO Fretless Bass Fretless Acoustic Grand Piano Gr.Piano Slap Bass 1 SlapBas1 Bright Acoustic Piano Br.Piano Slap Bass 2 SlapBas2 Electric Grand Piano 1 E.GPiano1 Synth Bass 1 SynBass1 Honky-Tonk Piano Hky.Tonk Synth Bass 2 SynBass2 Electric Piano 1 E.Piano1...
  • Page 27 Clarinet Clarinet Fiddle Fiddle PIPE Shanai Shanai Piccolo Piccolo PERCUSSIVE Flute 1 Flute 1 Tinkle Bell TnklBell Recorder Recorder Agogo Agogo Pan Flute 1 PanFlute1 Steel Drums Stl Drum Bottle Blow Bottle Woodblock WoodBlok Shakuhachi Shakhchi Taiko Drum TaikoDrm Whistle Whistle Melodic Tom MelodTom...
  • Page 28 Gu Qin Guqin HumanOh-Ah HumanOh-Ah Gu Zheng 1 Guzheng1 E.Grdpno 2 E.Grdpno 2 Gu Zheng 2 Guzheng2 E.Piano 3 E.Piano 3 Di Zi + Gu Zheng DiziZheng Dyno Dyno Suo Na 1 Suona1 Bassoon 2 Bassoon Suo Na 2 Suona2 Clari.

  • Page 29: Specifications

    SPECIFICATIONS 88 Key. Graded hammer action. Velocity Sensitive KEYBOARD POLYPHONY There are a total of 195 voices which can be selected by 8 voice shortcut buttons VOICE Main Voice, Layer, Split, Twin Piano VOICE MODE EFFECT Reverb, Chorus ACCOMP RHYTHM DISPLAY LCD with 16 Notes DEMO...
