Operating Instructions
ehb SMARTdisplay 101
Service personnel
Version 1.2
.
It is not permitted to pass on or copy this documentation or use or disclose its content unless expressly approved. Failure to comply with this shall
result in compensation for damages. All rights are reserved in the case of patent issue or utility model registration.
Advertisement
Table of Contents
Related Manuals for ehb electronics SMARTdisplay 101
Summary of Contents for ehb electronics SMARTdisplay 101
- Page 1 Operating Instructions ehb SMARTdisplay 101 Service personnel Version 1.2 It is not permitted to pass on or copy this documentation or use or disclose its content unless expressly approved. Failure to comply with this shall result in compensation for damages. All rights are reserved in the case of patent issue or utility model registration.
-
Page 2: Quick Guide
Operating Instructions ehb SMARTdisplay 101 Quick guide Overview Display / Touchscreen Functions of the Navigation Bar To open the navigation bar, double-click on a blank area of the screen. (Double-clicking the bottom near where the bar should be will not open it!) -
Page 3: Table Of Contents
SMARTdisplay 101 Operating Instructions Table of Contents Quick guide ........................... 2 Overview ..........................2 Functions of the Navigation Bar..................2 Table of Contents ......................... 3 General .......................... 4 Introduction ......................4 Target Group ......................4 Important Notes for the Use ..................5 Repair of Devices ..................... -
Page 4: General
1. General 1.1 Introduction The ehb SMARTdisplay 101 unit offers a wide range of functions for monitoring and controlling all motors and special machines that feature the CAN bus (SAE J1939). Using the special Workbench configuration program (a software product of ehb-electronics gmbh for Windows 7 or 8), the display can be set up individually and specific to your applications. -
Page 5: Important Notes For The Use
Do not operate the ehb SMARTdisplay 101 device within range of strong electro- magnetic fields. Observe the temperature specifications listed in Chapter 6. Storage ehb SMARTdisplay 101 devices that are not being used must be stored as de- scribed in the operating specifications. Shipping When shipping, equipment must always be shipped in the original packaging or in correspondingly sturdy packaging. -
Page 6: Repair Of Devices
Or use our online service for returning the unit: www.ehbservice.de NOTE! ehb electronics gmbh is only liable for proper performance of tasks as well as for the suita- ble condition of the materials used. Further claims such as compensation for lost profits or... -
Page 7: Operation
Operating Instructions 2. Operation 2.1 Connection The ehb SMARTdisplay 101 is mounted using the holders supplied and four plastic bolts. The electri- cal connection to the device is via a DEUTSCH plug, DT 06-12S. Figure 1: Wiring diagram and pin assignment Pin / Contacts Kl. -
Page 8: Switch On/Off
Operating Instructions ehb SMARTdisplay 101 2.2 Switch On/Off When terminal 30 is active, the device is activated via terminal 15 (input), e.g. from an external igni- tion switch. The initial start-up procedure takes about 15 seconds while the Windows Embedded Com- pact 7 operating system starts up. -
Page 9: Navigation Of
SMARTdisplay 101 Operating Instructions 2.3 Navigation of Pages A hierarchical structure of groups can be created using the configuration program on the PC. Each group contains one or more pages. A page group always receives at least one page - in the simplest case, a page group is exactly one page. -
Page 10: Change Of Settings
Operating Instructions ehb SMARTdisplay 101 The left/right buttons on the navigation bar allow you to browse the pages within a group. Click (browse forward) within e.g. group 2 to move from page 2 to page 3, from page 3 to page 4 and from page 4 back to page 2. -
Page 11: Setting Brightness, Contrast And Language
SMARTdisplay 101 Operating Instructions 3.1 Setting Brightness, Contrast and Language In Setup, select the symbol You can now adjust the sliders to make the screen display brighter/darker and to control the contrast. Note that ‘wrongly’ displayed greyscales (that appear greenish or with very rough transitions) usually do not mean that the display is faulty, but more probably indicate that the display parameters are wrongly set. -
Page 12: Network (Lan) Configuration
Operating Instructions ehb SMARTdisplay 101 From left to right, set the year, month, day, hour, minute and second. Clicking on one of these areas causes a numerical input field to appear. Type in the desired figure and press Enter to confirm. If a valid value has been entered, this is adopted straight away. -
Page 13: Error List
SMARTdisplay 101 Operating Instructions 4. Error List The list of errors stores errors that are received from control units via the CAN bus and can be viewed without a password. To open the list, click the list of errors symbol in the navigation bar. -
Page 14: Communication With The Pc
Operating Instructions ehb SMARTdisplay 101 after start-up, the last few entries of the data file previously used are copied into the start of the newly created file. This ensures that the list always contains the latest error data, even just after a restart. -
Page 15: Update Of A Project Via Usb
An update to Windows® Embedded Compact 7 can only be carried out by ehb electronics gmbh. No updates are required for supplied ehb SMARTdisplay 101 devices. -
Page 16: Wiring Diagram
Operating Instructions ehb SMARTdisplay 101 6. Wiring Diagram 16/19 Vers. 1.1 © ehb errors excepted... -
Page 17: Housing Dimensions
SMARTdisplay 101 Operating Instructions 7. Housing Dimensions © ehb Errors excepted Vers. 1.2... -
Page 18: Technical Specification
Operating Instructions ehb SMARTdisplay 101 8. Technical Specification Parameters Conditions Limiting Values Remarks Min. Typ. Max. Supply voltage range UB 12-24V Power consumption for Power consumption during operation de- UB 8-24V Ignition 0,7mA 0,4mA pends on the wiring, (UB=14V) (UB=28V) -
Page 19: Document Information, History
SMARTdisplay 101 Operating Instructions Robustness against wire transmitted disturbance induced by high frequency fields according to DIN EN 61000-4-6 Vibration according to DIN EN 60068-2-6 Document Information, History ehb SMARTdisplay 101 Project: Technical documentation Document type: Version: 05.07.2017 Created on:...
