Summary of Contents for Bauhn ATV58UHD-0719
- Page 1 58" 4K Ultra HD TV MODEL: ATV58UHD-0719 User Manual...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new Bauhn product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome On-Screen Set Up Specifications Compliance and Responsible Disposal 41 Unpack and Prepare TV Setting Menus Warranty Information What's in the box Picture Repair and Refurbished Sound Important Tips Goods or Parts Notice TV (DTV and ATV) Attaching the stand Lock Wall-mounting the TV System... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the box Before installing your new TV, check you have everything needed. See the inside flap of the box for how to handle the TV without damaging it! In the box you will find: A. Ultra HD TV B. -
Page 5: Important Tips
Important Tips • Place the TV on a level surface. • Place the TV away from any source that may generate heat or vibrations. • Make sure there is enough space around vents for airflow. • The remote control works up to 5 metres away from the TV. •... -
Page 6: Attaching The Stand
Attaching the stand • This TV is heavy! We recommend asking someone to help you lift it. • Unplug the TV from the power outlet before installing or removing the stand. • Only touch the frame, not the screen. • It is highly recommended to use safety straps for securing the TV. -
Page 7: Wall-Mounting The Tv
Wall-mounting the TV • Unplug the TV from the power outlet before wall-mounting. • Contact a professional for assistance with wall-mounting the TV. Required 400mm • VESA Mounting Bracket • 4 x M6*12mm screws (or longer as required) The TV comes with holes on the back panel for use with wall-mounting brackets (bracket not included). -
Page 8: Connect To Power
Connect to power Don't forget to plug in the TV to the power outlet. Leave the power switched off until installation is finished. Make sure the TV is switched off at the power outlet until you have finished connecting your cables. Connect your antenna Free-to-air TV in HD (High Definition) High Definition (HD) channels... -
Page 9: Controls And Connections
Controls and Connections Get to know your TV On/Standby light and Remote sensor Buttons on the TV 1. VOL + : Increase the volume level or move left. VOL+ VOL- 2. VOL - : Decrease the volume level or move right. 3. -
Page 10: Ports On The Tv
Ports on the TV HDMI 3 HDMI 4 ANTENNA IN HDMI All-digital connection between the TV and any HDMI device. Use a high-speed Supports Ultra HD. Requires a High Speed HDMI cable (not HDMI cable for best picture and included). sound quality. - Page 11 CVBS/Y DIGITAL AUDIO HDMI 1 LINE OUT HDMI 2 OUT (OPTICAL) (ARC) AUDIO IN AV / COMPONENT IN Digtal Audio Connect an external digital audio device. Use an Optical cable (not included) to connect the unit with an amplifier, soundbar or Out (Optical) other audio decoding device for digital audio signal output.
-
Page 12: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into AAA size place. batteries included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 13: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor at the front of the TV. The remote will not operate if its path is blocked. The remote has a range of up to about 5 metres from Remote Hints and Tips the TV at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 14: Standard Remote
Standard Remote POWER: Switch the TV to On or Standby. GOTO: Jump to a different chapter of the DVD.* TV/RADIO / EJECT: Switch between TV or radio in DTV mode / Eject a disc (DVD). ANGLE: View DVD playback from different angles, if the DVD has this feature.* A-B: Repeat selected DVD scenes.* FAV: Press to display your favourite program in... - Page 15 SOURCE: Switch the input source. MUTE: Mute the sound. Press again or press V+ to restore the sound. GUIDE: Launch the TV Guide (DTV). VOL +/-: Turn the volume up/down. CH +/-: Change to the next or previous channel. DISPLAY: Display information of the current program.
-
Page 16: Easy Remote
Easy Remote POWER: Switch the TV to On or Standby. (SOURCE): Switch the input source. : Press the UP/ DOWN/LEFT/RIGHT buttons to OK: Confirm your selection. navigate. Display the channels list (DTV). : Turn the volume up or : Go to the next or down. -
Page 17: On-Screen Set Up
On-Screen Set Up Make sure equipment is properly connected (as shown on pages 10-11) before connecting the TV to power. Make sure the TV is plugged in at the power socket and switched on. Press the (ON) button to turn on the TV. On/Standby light is WHITE in standby mode. -
Page 18: Tv Setting Menus
TV Setting Menus Menu Navigation Buttons Press the MENU button to display the TV settings menu. See the guide below for all the other buttons you'll need Once you have programmed any settings, the unit will retain them in to use to adjust and change your settings. its memory until you change them, even after turning the TV off. - Page 19 Sound System • Sound Mode • System Language • Treble • Audio Language • Bass • Subtitle Language • Balance • Hearing Impaired • Auto Volume Level (AVL) • PVR File System • S/PDIF Mode • HDMI CEC • Audio Delay •...
-
Page 20: Picture
Picture Original Picture Mode Images are for reference only. Home (default): Basic picture suitable for home use, with reduced power consumption. Bright Room: Enhanced picture brightness for bright home environments. Dynamic: Enhanced brightness with lower contrast, colour depth and edges for standing out in very Brightness bright places such as storefronts. - Page 21 Picture Settings Option Description Adjust the on-screen colour temperature. Colour Temp Normal Warm Cold Reduces noise to improve picture quality. Noise Reduction Medium High Adjust the video size. Sizes may differ between input sources. Aspect Ratio Auto Just Scan 16:9 Zoom1 Zoom2 Adjusts HDMI input mode to best suit your device.
-
Page 22: Sound
Sound Option Description Sound Mode Standard Music Movie Sports Personal Adjust the levels of higher pitched sounds (adjustable when in Personal Treble mode). Adjust the levels of lower pitched sounds (adjustable when in Personal Bass mode). Balance Adjust the audio output between the left and right speakers. Auto Volume Level Turn On to keep the volume level consistent. -
Page 23: Tv (Dtv And Atv)
TV (DTV and ATV) Option Description Automatically tune all available free-to-air TV channels. Adjust settings (default settings are set for Australia). Auto Tuning Press OK to start scanning. Manually select and tune analog TV channels. (Analog TV is no longer supported in Australia.) Current channel: Press the buttons to select the channel number to save the tuned signal. - Page 24 Programme Edit Use the buttons to highlight a channel. Option Description Move the channel location on the list. Press YELLOW to enter Move mode. Use the buttons to select a Move position and press YELLOW to confirm. Delete RED to delete the highlighted channel. Press Skip BLUE to skip the highlighted channel.
-
Page 25: Lock
Lock 0000 Factory Password: Enter the factory password '0000' using the number buttons on the remote and select 'OK' on-screen. If you changed your 4711 Master Password: password but forgot it, you can still use the master password. Option Description System Lock Enable/disable the lock on the system. -
Page 26: System
System Option Description System Language Select your preferred On Screen Display language. Audio Language Select your preferred audio language. (Available for digital channels, depending on the programme.) Subtitle Language Select the language for subtitles (available for digital channels, depending on the programme). Turn On or Off. - Page 27 PVR Settings To make changes to PVR (Personal Video Recording), ensure your USB drive is inserted into the TV. Check the troubleshooting section if you're having problems setting up your USB device. Option Description Select Disk Select the USB drive. Check PVR File System Check the health of the USB drive file system.
- Page 28 HDMI CEC Setup This feature allows for your TV and your connected HDMI device to be controlled by one remote. Press the SOURCE button on the unit or remote control to select the HDMI input source. Option Description HDMI CEC (Consumer Electronics Turn HDMI CEC On/Off.
-
Page 29: Time
Time Option Description Clock Displays time values from the TV broadcast signal. (Not user adjustable.) Time Zone Select your timezone. Select the desired Auto Sleep (Standby) duration. Sleep Timer Options: 15 min 30 min 45 min 60 min 90 min 120min 240min Set the amount of time to lapse before the TV enters Standby mode due to inactivity. -
Page 30: Tv Guide
TV Guide (Free to air TV) TV Guide Functions To access the TV Function Remote Button guide, press the GUIDE button on the Move between columns. remote. To activate the TV Select a channel or programme. Channels use the buttons to select View TV Guide for the next day. -
Page 31: Recording
Recording Important Tips: • Back-up your personal data before plugging in your USB to the TV. We do not assume liability for any loss of data due to misuse or malfunction. • You cannot change channels while in recording mode. •... -
Page 32: Recording Live Tv
Recording, scheduled recording and pause Before you can record with this TV (including time-shift recording), you must live TV functions only work in DTV mode insert your USB storage device into the (free-to-air). USB port. SOURCE Recording Live TV Instant Recording COMPONENT HDMI 1 Press... -
Page 33: Pause Live Tv (Time-Shift)
Pause Live TV (Time-shift) Recording, scheduled recording and pause live TV functions only work in DTV mode Temporarily pause the live TV signal, then resume (free-to-air). playback at your convenience. SOURCE Before you can record with this TV (including time-shift recording), you must COMPONENT insert your USB storage device into the HDMI 1... -
Page 34: Usb Mode
USB Mode You can only play Photos in the Photo category, Music in the Music category and so on. Make sure you select the correct category for the file you wish to play. Set up Function Remote Button Insert your USB into a USB port on the TV. Press the SOURCE button to select 'USB' mode or press Navigate media categories and file system the MEDIA button on the remote. - Page 35 Playback Functions Music Function Remote Button Playback of different media types have different controls. Navigate to a folder or file Photo Play a track Function Remote Button Navigate to a folder or file Fast forward or rewind the track Skip or restart the current track Display a photo Hide or display the on-screen Return to the file list...
- Page 36 Video Text Function Remote Button Function Remote Button Navigate to a folder or file Navigate to a folder or file Play a video Open the text file Pause the video Navigate to the next/previous page Resume playback Return to the file list Stop playback Fast forward or rewind the track Skip or restart the current track...
-
Page 37: Troubleshooting
Troubleshooting If you experience problems with your TV, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649. Problem Solution • Check the power outlet is turned on. • If using a multi-outlet, check if it is working properly. To check whether a power strip is working properly, No power plug the TV’s power plug directly to a wall outlet and make sure the white indicator light on the TV is lit. - Page 38 Problem Solution • Ensure that all equipment is connected properly. If you are using an external device, turn it off, then turn it on again. If it says there is no signal on the screen, choose the correct source input. •...
- Page 39 Problems relating to your USB media storage device Problem Solution • First, refer to the instructions describing how to use USB devices with this TV. • If the problem still occurs, your USB device may not be compatible. My TV does not •...
-
Page 40: Specifications
Specifications With stand: 1299 x 254 Active screen size 57.5"(146.1cm) (diagonal) x 821 mm Dimensions (W x D x H) Resolution Without stand: 1299 x 3840 x 2160 84 x 759 mm Display colours 16.7M 14.42kg Aspect ratio 16:9 Weight Gross 18.95kg Refresh rate... -
Page 41: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can National Television and Computer Recycling be a suffocation hazard for babies and young children, please ensure all packaging materials are out of Scheme reach and are safely disposed of. -
Page 42: Warranty Information
Warranty Information Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 43: Repair And Refurbished
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 44 Online support Visit www.bauhn.com.au for software updates to keep your TV up-to-date, as well as the latest Instruction Manual for information on the updated features. Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
