OWNER’S MANUAL AIR CONDITIONER Please read this manual carefully before operating your set and retain it for future reference. TYPE : WALL MOUNTED MODELS : S10INV-2 S13INV-2 www.lge.com P/NO : MFL66102309...
Air Conditioner Owner’s Manual TABLE OF CONTENTS FOR YOUR RECORDS A. Safety Precautions..........3 B. Electrical Safety............6 Write the model and serial numbers here: Temporary Use of an Adapter ......6 Model # Temporary Use of an Extension Cord ...6 Serial # Symbols used in this Manual......6 C.
Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. the following indications. This symbol indicates the possibility of death or serious injury. This symbol indicates the possibility of injury or damage. Meanings of symbols used in this manual are as shown below.
Page 4
Safety Precautions Indoor/outdoor wiring connections must Safely dispose o the packing materials. Make sure to check that the power cable be secured tightly and the cable should Like screws, nails, batteries, broken plug is not dirty, loose or broken and be routed properly so that there is no things etc after installation or svc and then only insert the plug completely.
Page 5
Safety Precautions Do not use the product for special purposes, Use a soft cloth to clean. Do not use such as preserving foods, works of art, etc. It harsh detergents, solvents or splashing is a consumer air conditioner, not a precision water etc .
Electrical Safety Electrical Safety • This appliance must be properly grounded. To minimize the risk of electric shock, you must always plug into a grounded oulet. • Do not cut or remove the grounding prong from the power plug. • Attaching the adapter ground terminal to the wall receptacle cover screw does not ground the appliance unless the cover screw is metal and not insulated, and the wall receptacle is grounded through the house wiring.
Product Introduction Product Introduction Here is a brief introduction of the indoor and outdoor units. Indoor Unit Air Inlet Plasma Filter Air Filter Front Grille ON/OFF Button Signal Receiver Triple Filter LED Display H1N1 Filter Ionizer Horizontal Vane Air Outlet Vertical Louver Operation Indication Lamps Power...
Operating Instructions Operating Instructions How to insert the Batteries How to insert the batteries 1. Remove the battery cover by pulling it according to the arrow direction. 2. Insert new batteries making sure that the (+) and (-) of battery are installed correctly.
Operating Instructions Wireless Remote Controller The controls will look like the following. Signal transmitter 1. START/STOP BUTTON Used to turn O /On the unit. 2. OPERATION MODE SELECTION BUTTON Used to select the operation mode. 3. ROOM TEMPERATURE SETTING BUTTONS Used to select the room temperature.
Operating Instructions Operation Mode Press the START/STOP BUTTON to turn the unit on. The unit will respond with a beep. Open the door of the remote controller and press the operation mode button. Each time the button is pressed, the operation mode is shifted in the direction of the arrow.
Operating Instructions Auto Operation In this operation mode the actual setting temperature and the fan speed are automatically set by the electronic control logic based on the current room temperature. If you feel hot or cold press the temperature setting NOTE : You cannot set the actual setting temperature and the indoor fan speed in this operation mode.
Check the indicator for A.M. and P.M. PLASMA Puri cation & Ion Generation Operation Plasma lter is a technology developed by LG to get rid of microscopic contaminants in the intake air by generating a plasma of high charge electrons.
Operating Instructions Display Luminosity The unit display Luminosity can be adjusted by using the remote controller. Open the cover of the remote controller and press the LED LUMINOSITY button. Display LED will be dark. Press the button again to set bright display. (The order of 100% 0% LUMINOSITY is repeated whenever you press the button.) If you press any button it will return to 100% LUMINOSITY.
Operating Instructions Vertical Air ow Direction Control NOTICE Always use the remote control to adjust the damage the air conditioner. direction louver will close the air outlet vent of the system. 1. Press the Start/Stop button to start the unit. 2.
Operating Instructions Forced Operation Forced operation is used when the remote controller can't be used. The operation will be started if the ON/OFF button is pressed. If you want to stop the operation, re-press the button. ON/OFF Button Cooling Model Operating mode Cooling Indoor FAN Speed...
Maintenance and Service Maintenance and Service Before performing any maintenance, turn o the main power to the system, disconnect the circuit breaker and unplug the power cord. Indoor Unit Clean the unit with a soft dry cloth. Do not use bleach or abrasives. Never use any of these •...
Page 17
Maintenance and Service Removal of Filters Open the front panel as shown. Then pull the lter tab slightly forward to remove the air lter. After removing the air lter, remove the Plasma, Triple lter and H1N1 lter by slightly pulling downwards. Plasma Filter Don’t touch this Plasma Filter within 10 seconds after opening the inlet grille, it may cause an electric shock.
Maintenance and Service Outdoor Unit The heat exchanger coils and panel vents of the outdoor unit should be checked regularly. If clogged with dirt or soot, the heat exchanger and panel vents may be professionally steam cleaned. NOTE Operation Tips! Do not overcool the room.
Maintenance and Service Troubleshooting Tips! Save time and money! The air conditioner may be operating abnormally when: Problem Possible Causes What To Do The air conditioner is • Make sure the air conditioner plug is unplugged. pushed completely into the outlet. The fuse is blown/circuit •...
Page 20
PT. LG ELECTRONICS INDONESIA Kawasan Industri MM2100 Blok G Cikarang Barat, Bekasi, Jawa Barat 17520 INDONESIA...
Page 21
Panduan Pengguna Silakan baca buku petunjuk ini dengan seksama sebelum operasi. Menetapkan dan mempertahankan Anda untuk referensi di masa mendatang. TYPE : AC Dinding Berlaku untuk model : S10INV-2 S13INV-2...
Page 22
Panduan Pengguna AC DAFTAR ISI UNTUK CATATAN ANDA A. Tindakan Pencegahan Keselamatan ....3 B. Keamanan Elektrik ..........6 Tulis nomor model dan seri di sini: Penggunaan Sementara Adaptor....6 Model # Penggunaan Sementara Kabel Ekstensi..6 Seri # Simbol yang digunakan di Panduan ini..6 Anda dapat melihatnya pada label yang ada di sisi C.
Tindakan Pencegahan Keselamatan Tindakan Pencegahan Keselamatan Untuk mencegah terjadi cedera pada pengguna atau orang lain dan kerusakan unit, instruksi berikut harus diikuti. Pengoperasian yang tidak benar karena mengabaikan instruksi yang diberikan akan menimbulkan cedera atau kerusakan. Tingkat risiko yang ditimbulkan dikategorikan melalui indikasi berikut. AWAS Simbol ini mengindikasikan kemungkinan kematian atau cedera serius.
Page 24
Tindakan Pencegahan Keselamatan Koneksi perkabelan dalam ruangan/luar Buang bahan-bahan kemasan di tempat Pastikan untuk memeriksa konektor kabel ruangan harus dikencangkan dengan kuat yang aman, seperti baut, paku, baterai, daya tidak kotor, tidak kendur atau patah dan kabel harus diarahkan dengan benar benda-benda yang patah dsb setelah dan pasang konektor sepenuhnya.
Page 25
Tindakan Pencegahan Keselamatan Jangan gunakan produk untuk tujuan tertentu Jangan hambat inlet atau outlet aliran udara. Gunakan kain yang lembut untuk seperti mengawetkan makanan, pekerjaan seni, membersihkan. Jangan gunakan detergen, dsb. Produk ini merupakan AC pelanggan, bukan cairan yang keras atau cipratan air dsb. sistem refrigeran yang akurat.
Keamanan Elektrik Keamanan Elektrik AWAS • Peralatan ini harus dihubungkan ke ground dengan benar. Untuk meminimalisir risiko tersengat listrik, Anda harus selalu menghubungkannya ke outlet yang memiliki koneksi ke ground. • Jangan memotong atau melepaskan konektor ground dari konektor daya. •...
Pengenalan Produk Pengenalan Produk Berikut adalah pengenalan singkat tentang unit dalam dan luar ruangan. Unit Dalam Ruangan Inlet udara Plasma Filter Filter udara Gril depan Tombol ON/OFF Penerima Sinyal Triple Filter LED Display H1N1 Filter Ionizer Bilah Horizontal Outlet Udara Kisi-Kisi Vertikal Lampu Indikasi Pengoperasian Power...
Instruksi Pengoperasian Instruksi Pengoperasian Bagaimana Memasang Baterai 1. Lepaskan penutup baterai dengan menariknya sesuai arah tanda panah. 2. Pasang baterai baru dengan memastikan bahwa sisi (+) dan (-) baterai berada di posisi yang benar. 3. Pasang kembali penutup baterai dengan menggesernya kembali ke posisinya.
Instruksi Pengoperasian Remote Control Nirkabel Kontrol-kontrol akan tampak seperti di bawah ini. 1. TOMBOL ON/OFF Pemancar sinyal Operasi akan mulai bila tombol ini ditekan dan berhenti bila tombol ini ditekan lagi. 2. TOMBOL SELEKSI MODE PENGOPERASIAN Digunakan untuk memilih mode operasi. 3.
Instruksi Pengoperasian Mode Pengoperasian roller Tekan tombol Start/Stop Unit akan merespons dengan suara bip. Buka pintu remote control. Untuk memilih Operasi Pemanasan,.tekan tombol Operation Mode Selection. Setiap kali tombol ditekan, mode operasi akan berubah sesuai arah panah. Penyejukan Otomatis Anti Lembab Sehat Tutup pintu remote control.
Instruksi Pengoperasian Pengoperasian Otomatis Dalam modus operasi ini sebenarnya pengaturan suhu dan kecepatan kipas secara otomatis ditetapkan oleh kontrol elektronik berdasarkan logika saat ini suhu kamar. Jika Anda merasa panas atau dingin tekan pengaturan suhu tombol masing-masing untuk lebih cooling atau efek pemanasan.
PERHATIAN Periksa untuk indikator A.M. dan P.M. PLASMA Bersuci & Ion Generasi Operasi Penyaring plasma adalah teknologi yang dikembangkan oleh LG untuk menyingkirkan mikroskopis asupan kontaminan di udara dengan menghasilkan plasma elektron biaya tinggi. Plasma ini membunuh dan menghancurkan kontaminan bersih sepenuhnya untuk menyediakan dan higienis udara.
Instruksi Pengoperasian Kecerahan Display Kecerahan display unit dapat diatur menggunakan remote control. Buka penutup remote control dan tekan tombol KECERAHAN LED. LED display akan menjadi gelap. Tekan kembali tombol untuk mengatur kecerahan display. (Urutan 100% 0% LUMINOSITY akan diulang setiap kali Anda menekan tombol.) Jika Anda menekan tombol apa pun, pengaturan akan kembali ke 100% LUMINOSITY.
Instruksi Pengoperasian Kontrol Arah Udara Vertikal Aliran udara naik/turun (Aliran Udara Vertikal) dapat PERHATIAN diatur dengan menggunakan remote control. PERHATIAN Apabila Anda menekan tombol CHAOS swing, arah aliran udara horizontal diubah secara otomatis berdasarkan algoritma CHAOS untuk mendistribusikan udara di dalam ruangan secara merata dan pada saat yang sama untuk membuat tubuh manusia merasa nyaman, seperti sedang menikmati sepoi-sepoi angin alami.
Instruksi Pengoperasian Pengoperasian paksa Pengoperasian paksa dilakukan saat remote control tidak dapat digunakan. Pengoperasian akan dimulai saat tombol ON/OFF ditekan. Jika Anda ingin menghentikan pengoperasian, tekan lagi tombolnya. TOMBOL ON/OFF Model Pendinginan Mode pen goperasian Pendinginan Kecepatan KIPAS Dalam Tinggi 22°C Pengaturan Suhu Pengoperasian tes...
Perawatan dan Servis Perawatan dan Servis PERHATIAN Sebelum melakukan perawatan apa pun, matikan daya utama ke sistem, lepaskan koneksi pemutus sirkuit dan lepaskan kabel daya. Unit Dalam Ruangan Bersihkan unit dengan kain kering yang lembut. Jangan gunakan pemutih atau pembersih yang bersifat abrasif. PERHATIAN Jangan gunakan salah satu dari bahan berikut •...
Perawatan dan Servis Unit Luar Ruangan Koil penukar panas dan ventilasi panel pada unit luar ruangan harus diperiksa secara teratur. Jika tersumbat oleh kotoran atau jelaga, penukar panas, dan ventilasi panel dapat dibersihkan di tempat pencucian uap profesional. CATATAN Koil yang kotor atau tersumbat akan mengurangi e siensi pengoperasian sistem dan menyebabkan biaya pengoperasian yang tinggi.
Perawatan dan Servis Tips Penelusuran Gangguan! Hemat waktu dan uang! AC dapat beroperasi secara tidak normal jika: Masalah Kemungkinan Penyebab Yang Harus Dilakukan AC tidak terkoneksi. • Pastikan konektor AC didorong secara penuh ke dalam outlet. Sekering putus/pemutus • Periksa rumah sekring/kotak pemutus sirkuit dan ganti sekring atau reset pemutus sirkuit.
