InsuLogix® T Portable One Channel
Temperature Measurement System
Manual
Weidmann Technologies Deutschland GmbH
Washingtonstraße 16/16a
D-01139 Dresden, Germany
Version 1.2
Telefon: +49 (0)351 8435990
InsuLogix® T Portable One Channel Manual
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InsuLogix T and is the answer not in the manual?

Questions and answers

Summary of Contents for Weidmann InsuLogix T

  • Page 1 InsuLogix® T Portable One Channel Temperature Measurement System Manual Weidmann Technologies Deutschland GmbH Washingtonstraße 16/16a D-01139 Dresden, Germany Version 1.2 Telefon: +49 (0)351 8435990 InsuLogix® T Portable One Channel Manual Page 1...
  • Page 2: Table Of Contents

    Contents General ............................. 3 Safety ............................3 Unpacking, Inspection, Service ....................3 Introduction ..........................4 Product specifications ......................5 Calibration ..........................5 Getting started.......................... 6 Sensor handling ........................... 6 Connection with PC ........................6 Connecting the probes......................... 6 Testing the temperature probe ..................... 7 Temperature probe handling .......................
  • Page 3: General

    1. General The fiber optical thermometer described in the operating instructions has been designed and manufactured using state-of-the-art technology. All components are subject to stringent quality and environmental criteria during production. These operating instructions contain important information on handling the instrument. Working safely requires that all safety instructions and work instructions are observed.
  • Page 4: Introduction

    The outer jacket of the fiber optic temperature sensors is made out of Teflon, at the sensor tip a GaAs crystal (Gallium Arsenide) is attached. The probe sensor is completely non-conductive. Weidmann’s fiber optic sensors offer complete immunity to RF and microwave radiation with high temperature operating capability, intrinsic safety, and non-invasive use. The probes are also designed to withstand harsh and corrosive environments.
  • Page 5: Product Specifications

    5. Product specifications Instrument specifications Number of channels Power Requirements 9 VDC, power pack included Current 1.5 A Display range 0 to 300°C Accuracy up to ± 0.2°C Resolution 0.1°C Communication RS-232 Display: LCD display 1x8 digits, background lighting Storage temperature: -20°C to +50°C Operating temperature: 0°C to +40°C...
  • Page 6: Getting Started

    In this case the sensor is damaged and needs to be repaired / replaced. Connection with PC Before establishing the first connection, please check whether the InsuLogix T device is connected to the power supply and the pc via the rs-232 cable respectively. Connecting the probes The temperature sensors are connected via the ST-connectors to the BNC sockets at the back panel.
  • Page 7: Testing The Temperature Probe

    Figure 1 Connecting the fiber optic probe to instrument To ensure accurate measurements and long life of the fiber optic sensors and instruments, it is necessary to clean them regularly. More information about cleaning can be found in a later chapter.
  • Page 8: Cleaning Of Sensor Connectors And Plugs

    Figure 3 Mechanical restrictions Cleaning of sensor connectors and plugs Weidmann is optionally supplying a fiber optic one-click cleaner. The tool is simple and quick to use as is shown in image below. Figure 4 Fiber optic connector cleaning tool InsuLogix®...
  • Page 9: Software

    8. Software For a description of usable software read the following documents: - InsuLogixT_Manual_FOTEMP_Assistent_EN_Rev01.pdf (English version) - InsuLogixT_Manual_FOTEMP_Assistent_DE_rev01.pdf (German version) 9. Using the InsuLogix® T FoTemp one channel handheld device Figure 5 Connect the fiber optic probe is connected to handheld device Figure 6 Instrument switched on and reading the temperature InsuLogix®...
  • Page 10 Note: The signal level received from sensor must be at least 20% in order for instrument to calculate the temperature. Figure 7 Press Menu/Enter key longer than one second to display Menu option Use the UP and DOWN keys to enter the desired OFFSET. Save and exit menu pressing the „MENU/ENTER“...
