- Page 1 InsuLogix® T Product Manual Weidmann Technologies Deutschland GmbH Washingtonstraße 16/16a D-01139 Dresden, Germany Version 1.1 Telefon: +49 (0)351 8435990 InsuLogix® T Product Manual...
-
Page 2: Table Of Contents
InsuLogix® T System Configuration and Operation ............22 Integrating the InsuLogix® T into a data acquisition system ..........22 Using a PC/Laptop to connect to InsuLogix® T ..............23 Using a PC/Laptop to connect to InsuLogix T via Modbus over RS485 ......23 InsuLogix® T Product Manual... - Page 3 Figure 12 Bending restrictions ....................15 Figure 13 Mechanical restrictions ....................15 Figure 14 Weidmann Smart Spacer with Nomex disk..............17 Figure 15 Examples of key spacers prepared for optic fiber probe installation ......18 Figure 16 Examples of optic fiber probe mounting in key spacer (Smart Spacer assembly) ..18 Figure 17: Connecting the optic fiber cable to connectors on plate and to instrument ....19...
-
Page 4: Introduction
The InsuLogix® T instrument is warranted (Parts and Workmanship) for two full years from the date of purchase. Upon written notification of any defect, Weidmann will either repair or replace any faulty product or components thereof. A Return Material Authorization (RMA) must be obtained from Weidmann or authorized distributor prior to any merchandise return. -
Page 5: System Description
2. System Description The InsuLogix® T can be delivered to user as a system, and includes: InsuLogix® T instrument Optic fiber probes DIN Plate and DIN Ring Optic fiber connectors Optic fiber extensions DIN Rail AC/DC or DC/DC converter (optional) NEMA 4 (IP66) cabinet (optional) The system can also be delivered in partial shipments. -
Page 6: Figure 2: Insulogix® T Dimensions
Figure 2: InsuLogix® T dimensions Table 1: InsuLogix® T instrument specifications Number of Channels 2 to 16 Measuring Range -200 °C to 300 °C Accuracy < ± 1 K Resolution 0.1 K Measuring time/channel 250 ms Operating temperature -20 °C to 60 °C Storage temperature -20 °C to 70 °C Light source lifetime... -
Page 7: Tank Wall Kit
Tank wall kit The Tank Wall Kit consists of: Tank wall Ring Tank wall Plate J-Box – protection for tank wall Ring/Plate/connectors O-ring (comes with Ring and Plate, to be installed between Ring and Plate) Gasket (comes with J-Box, to me installed between J-Box and Plate) Bolts The components listed above are typically supplied as a kit, based on customer’s orders they can also be supplied in various combinations (only the plate, plate with J-Box, etc) -
Page 8: Tank Wall Ring
Tank wall Ring The tank wall Ring must be installed on transformer tank wall by welding process. A sealing O-ring is supplied with the Ring. The O-ring is to be installed between the Ring and the Plate, having the role of preventing the oil leaks. The Ring is supplied with threaded holes for the bolts that will be used to install the Plate on the Ring. -
Page 9: Tank Wall Plate
Tank wall Plate The Plate is designed to be mounted on DIN Ring using 8xM18 bolts that are also supplied with the Plate. The Plate comes with the optic fiber connectors already installed on it. The number of connectors supplied and mounted on the Plate is equal to number of optic fiber probes that will be installed inside the transformer. -
Page 10: Connectors
Connectors The number of Feedthroughs is at least equal to the probes that will be installed in the transformer tank. Make sure to clean up the connectors’ fiber optic ends using the cleaning tool supplied with the instrument, and make sure to keep the caps all the time on the connectors, removing them only before connecting the extensions/probes to the plate. -
Page 11: Optic Fiber Probes And Extensions
IP66 ( IEC 60529), NEMA 4, ISO 20653 Optic fiber Probes and Extensions The optic fiber cables that are delivered with the InsuLogix T system are: Optic fiber probes – consist of optic fiber with GaAs sensor and connector Optic fiber extensions – consist of optic fiber with two connectors Probes The outer jacket of the optic fiber temperature probes is made out of PTFE. -
Page 12: Extensions
Figure 10 Optic fiber in Oil Coupling (optional) with Ceramic Disk (optional) Extensions The optic fiber extensions consist of protected optic fiber cable with optic fiber connectors mounted on both ends. The extensions are used to connect the InsuLogix® T instrument to connectors that are installed on plate. -
Page 13: Installation
3. Installation There are several operations that user must follow in order to install a complete system. Some of these steps will be skipped in case of partial installation (when installing only the probes, only probes and tank wall kit, etc). The steps to be taken in order to install a complete system are: 1. - Page 14 (probe, connector on plate, the instrument’s channel or the Portable extension). If still not able to solve the problem then contact Weidmann and be prepared to inform on device the results of your troubleshooting process.
-
Page 15: Optic Fiber Probes And Extensions - Manipulation And Installation
Optic fiber Probes and Extensions – Manipulation and Installation Handling the optic fiber cables Bending radius 200µm silica core fiber hort time (max. 24h) bending radius: not less than 4 cm. Permanent installation bending radius: not less than 8cm. Figure 12 Bending restrictions Figure 13 Mechanical restrictions Probe Installation in Windings The ultimate responsibility for the probe installation and performance remains with the... -
Page 16: Weidmann Disk
Do not over-tie the cotton straps. Weidmann Disk™ The Weidmann Disk™ is made out of Nomex® material. Error! Reference source not found. shows the probe’s sensing end mounted in the Nomex disk. The spacer must have hole with a diameter of 19 mm and the spacer thickness must be 3.2 mm.. -
Page 17: Weidmann Smart Spacer
OEMs specific design. The probe mounting in key spacer and testing of finalized product are done at Weidmann facility, following that the OEM will receive the final product along with a Testing and Performance Certificate. This eliminates the assembly and testing processes that normally the OEM is doing before installing the optic fiber in transformer windings using key spacer solution. -
Page 18: Feedthrough Connectors Installation
Figure 16 Examples of optic fiber probe mounting in key spacer (Smart Spacer assembly) Feedthrough connectors installation Weidmann is supplying the transformer tank wall plate with the connectors pre-installed on it. The connectors and leak-proof and is not needed to re-tighten them over transformer lifetime. -
Page 19: Verifying The Optic Fiber Continuity During Installation Process
Ideally the OEM should route the extensions through their own conduit also inside the transformer control cabinet. If this is not done then Weidmann strongly recommends that optic fiber extensions sections located inside the transformer control cabinet be clearly identified by the transformer OEM with tags as "Optic fiber - Fragile"... -
Page 20: Connectors Cleaning
(probe, connector on plate, the instrument’s channel or the extension). If still not able to solve the problem then contact Weidmann and be prepared to inform on the results of your troubleshooting process. -
Page 21: Optic Fiber Connections Testing
InsuLogix® T can be used. Weidmann strongly recommends purchasing and keeping in the winding production shop at least one InsuLogix® T portable unit to be used for testing the optic fiber monitoring systems. -
Page 22: Insulogix® T System Configuration And Operation
4. InsuLogix® T System Configuration and Operation The InsuLogix T is designed to measure and report the temperatures using optic fiber and Gallium Arsenide sensor technology. The system is designed for long term operation on power transformer and in substation environment. -
Page 23: Using A Pc/Laptop To Connect To Insulogix® T
The InsuLogix® T can communicate only via Modbus over RS485 or Ethernet. A converter from RS485 to USB (Modbus compatible) is required in order to connect the instrument to a computer. The user can order a converter from Weidmann or source it from a different supplier. RS485... -
Page 24: Data Recording
Example 3: CH1, CH3, CH4, CH6 and CH8 are allocated to relay K3 while the channels CH1, CH2, CH4, CH5, CH7 and CH8 are allocated to relay K4. The relays will trigger if at least one of the allocated channels reports a temperature exceeding the set threshold. Each channel can be allocated an Activation Temperature. -
Page 25: Figure 21: Insulogix® T Lcd
Data polling frequency can be set via MODBUS command set. Data polling from InsuLogix® T and display on InsuLogix® T LCD varies depending on the number of channels. Figure 21: InsuLogix® T LCD InsuLogix® T Product Manual... -
Page 26: Annex A – Wiring Diagram For Insulogix® T Integration With The Transformer Control Cabinet
ANNEX A – Wiring Diagram for InsuLogix® T integration with the transformer control cabinet InsuLogix® T Product Manual... -
Page 27: Annex B – Modbus
ANNEX B – MODBUS See MODBUS Protocol Manual InsuLogix® T Product Manual...
