Waterco Britestream MK5 Owner's Manual

Led fibreglass niche pool lights
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
BRITESTREAM LED FIBREGLASS
NICHE POOL LIGHTS MK5
Owner's Manual
!
SAFETY INSTRUCTIONS: - Read prior to Installing or using Waterco Pool Light
WARNING
Transformer for LED pool lights. This equipment must be installed and serviced
by a qualified technician.
Improper installation can create electrical hazards which could result in property
damage, serious injury or death. Improper installation will void the warranty.
If the electrical supply cord of this product is damaged, return to supplier for
repair to avoid hazards.
Notice to Installer
This manual contains important information about the installation, operation and safe use
of this product. Once the product has been installed this manual must be given to the
owner/operator of this equipment.
www.waterco.com

Advertisement

loading

Related Manuals for Waterco Britestream MK5

Summary of Contents for Waterco Britestream MK5

  • Page 1 BRITESTREAM LED FIBREGLASS NICHE POOL LIGHTS MK5 Owner’s Manual SAFETY INSTRUCTIONS: - Read prior to Installing or using Waterco Pool Light WARNING Transformer for LED pool lights. This equipment must be installed and serviced by a qualified technician. Improper installation can create electrical hazards which could result in property damage, serious injury or death.
  • Page 2 LED FIBREGLASS NICHE POOL LIGHT INTRODUCTION The Waterco LED Niche fiberglass pool light has been specifically designed for easy installation into fibreglass pools. Features include the following: • Flush mounted with a minimal 28mm projection into pool. • Super bright LED’s capable of delivering 352 lumens (White LED).

  • Page 3: Installation

    Note: It is recommended that the pool light be fully immersed in water & the installation is inspected for leaks prior to back filling the pool light/s installation area. • The 20m power cable is now ready for connection to a Waterco single or multi connect pool light transformer.
  • Page 4 LED REPLACEMENT LIGHT INSTALLATION Disconnecting the LED light • Disconnect power to light at the circuit breaker. • Remove the 2 screws (12) securing the light lens (1) to the outer flange niche body (3). This will allow the lens assembly to be removed from the pool water, but will still be connected to the niche body (3) via the 1m coiled power cord that is stored within the niche body (3).
  • Page 5 Waterco Britestream LED Fibreglass Niche Pool Lights MK5 I pg 04 Connecting replacement LED light The replacement LED lights are available as white, tricolour or multicolour RGB models and are supplied as a complete light assembly with the additional components as follows: 2 x Quick connect spade electrical connectors (8 &...

  • Page 6: Troubleshooting

    (3) and refit the new replacement LED light assembly and secure with the 2 screws (12). Congratulations, reconnect power to your light at the circuit breaker and your new Waterco replacement LED light is ready for use.

  • Page 7: General Safety Rules

    I pg 06 GENERAL SAFETY RULES The installation of the Waterco LED Pool Light should be carried out in accordance to the safety instructions of swimming pools especially Standard HD 60364-7-702:2010, Install & protection output circuit in accordance with AS/NZS61558.2.6, AS/NZS 3000:2007 or as amended and the specific instructions for each facility.
  • Page 8 Tel: +61 8 8244 6000 Tel: +1 450 748 1421 Tel: +65 6344 2378 acT diSTriBuTiON WaTercO (NZ) LiMiTed Tel: +61 2 6280 6476 auckland, New Zealand Tel: +64 9 525 7570 Waterco Limited ABN 62 002 070 733 (W63495) 10/2016...
