LG LM-X120HM Service Manual page 132

No Part No Description
81 EAE66045501 Capacitor,Ceramic,Chip
82 EAG65731501 Connector,BtoB
83 EAG66476901 Connector,I/O
84 EAG66495501 Connector,RF
85 EAG66551701 Connector,BtoB
86 EAH64213301 Diode,TVS
87 EAH64873401 Diode,TVS
88 EAM64811801 Filter,Separator,Switch
89 EAP64971801 Inductor,Multilayer,Chip
90 EAP65011001 Inductor,Multilayer,Chip
91 EAP65068201 Inductor,Multilayer,Chip
92 EAX69075601 PCB,Sub
93 EBC64798001 Resistor,Chip
94 EBC64816301 Resistor,Chip
95 MBV64461602 Clip
96 EAD65666801 Cable,FFC
97 EAA65825401 Antenna Assembly
98 EAB65549301 Speaker Module
99 MDQ66458201 Frame
100 ACQ91555904 Cover Assembly,Rear
101 MCK71165704 Cover,Rear
102 MDJ66184201 Filter
103 MHK67368601 Sheet
104 MBG67703101 Button
105 MCR68149201 Decor
106 MCR68206901 Decor
107 MJN71648101 Tape
108 MFB65333101 Lens,Flash
109 MCQ70585901 Damper
110 MJN71591401 Tape
111 MCQ70585801 Damper,Camera
112 MBG67684201 Button,Side
113 MJN71591501 Tape
114 MJN71574101 Tape
115 MKC67298901 Window,Camera
116 ABN76299401 Cap Assembly
117 EBR88916901 PCB Assembly,Main
118 EBR89520701 PCB Assembly,Main,Auto
119 EBR88966301 PCB Assembly,Main,SMT
120 EBR89476301 PCB Assembly,Main,SMT Top
LGE Internal Use Only
Qty
12 C0105,C0106,C0107,C0108,C0111,C0112,C0113,C0116,C0117,C0118,C0119,C0121
1 J0101
1 J0102
1 J0211
1 J0103
1 TVS0105
1 TVS0102
1 U0202
1 C0219
1 R0210
3 L0201,L0204,R0209
1 PCB
10 C0218,C0220,R0101,R0102,R0103,R0104,R0105,R0131,R0132,R0208
2 R0106,R0107
2 ANT1,ANT2
1 EAD030000
1 EAA040000
1 EAB010100
1 MDQ000000
1 ACQ063300
1 MCK063300
1 MDJ000000
1 MHK000000
1 MBG000000
1 MCR000000
1 MCR000001
1 MJN000001
1 MFB029600
1 MCQ000000
1 MJN000002
1 MCQ009400
1 MBG071300
1 MJN000000
1 MJN000003
1 MKC009400
1 ABN000000
1 EBR071900
1 EBR071400
1 EBR071800
1 EBR071700
132
14. REPLACEMENT PART LIST
Location No.
