REMINDER
CALL 1-888-755-6750
BEFORE RETURNING TO STORE.
PACKAGE CONTENTS
Part
A
B
C
D
E
Bio media balls with bag
F
G
H
I
Anchoring Flange
J
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement parts.
•
Estimated Assembly Time: 45 minutes
•
Tools required for assembly: Carpenter's level, marker,utility knife ,
screwdriver, hacksaw,.
PRODUCT DESCRIPTION
Waterfall spillway is specifically design to maximize the natural processes that remove ammonia from the
water. Water pumped into tank brings the dissolved wastes into contact with bacterial colonies on the
many surfaces of the filter pad and bio ball. These colonies digest, or metabolize the ammonia. Some
types of bacteria turn it into nitrites; others take the still toxic nitrites and dissolved oxygen and turn them
into less toxic nitrates, a natural fertilizer that is easily taken up by plants. When water filter and back into
pond likes a beautiful waterfall, it will help to aerate the water. When the proper balance of fish, plants and
aeration is reached, you don't have to clean your pond for the entire season. This waterfall spillway is
designed to work with a water pump that can circulate of 1200 to 3750 gallons per hour.
PLEASE CALL 1-888-755-6750 BEFORE RETURNING TO THE STORE.
WWW.THEPONDBOSS.NET
16 in. Waterfall Spillway
Description
Tank
Coupler
Gasket
Adapter
Filter pad
Clip
Cover
Screw
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday, or
email us at customercare@thepondboss.net. Or visit our
website www.thepondboss.net.
Quantity
1
1
1
1
2
1
2
1
1
12
J
G
E
C
B
I
philipshead
temporary nail,
ITEM #DWF16
H
G
F
E
D
A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pond Boss DWF16
Summary of Contents for Pond Boss DWF16
- Page 1 16 in. Waterfall Spillway ITEM #DWF16 REMINDER Questions, problems, missing parts? Before returning to your retailer, call our customer service department at CALL 1-888-755-6750 1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday, or BEFORE RETURNING TO STORE. email us at customercare@thepondboss.net. Or visit our website www.thepondboss.net.
- Page 2 ASSEMBLY INSTRUCTIONS 1. Choose a location for your waterfall spillway, it can sit inside Waterfall returning directly to pond the liner or at the liner perimeter. Most of the time it is placed at the beginning of a stream. The important thing to remember is that all of the water coming out of the filter must stay within the pond liner to avoid water loss.
- Page 3 4. Carefully cut and remove the section of liner in the spillway opening. Fig. 4 Fig. 4 5. Apply a continuous 1/4" bead of sealer around the flange of tank. Make sure there are no spaces or voids in the bead between the holes and the edge of the cut-out on the flange of the tank.
- Page 4 8. Assembly the anchoring Flange into the tank flange to securely seal the liner to the tank, carefullly install the screws snug, finally remove the temporary nails and attach the last two screw. Fig. 8 Fig. 8 9. For maximum water flow, it is recommended that the largest tubing size for your pump is used.
- Page 5 12. Place the filter pad over bio media ball bags and tank. Fig. 12 Filter pad Fig. 12 13. Slide 2 clips to cover, then snap them to tank. Fig. 13 Clip Cover Clip Fig. 13 14. Connect tubing to the outlet adapter, then use hose clamp hold it tight.
- Page 6 CARE AND MAINTENANCE • Before cleaning, always disconnect the pump connect to this waterfall spillway from the power source. • Occasional cleaning of the filter pads will be necessary to ensure the proper functioning of the system. The filter pad is a designed to trap debris and particles. Filter pads should be removed and washed with clean water when they are visibly soiled.
- Page 7 This warranty period begins on the date of purchase by the original purchaser. Unless otherwise specified all pond boss® electrical products are warranted to the user against defective material and workmanship, under normal working conditions for 1 year from the date of purchase.
