Related Manuals for Next Pandora
Summary of Contents for Next Pandora
- Page 6 TV/RADIO PAGE+,PAGE- FIND AUDIO APPs...
- Page 8 SCART...
- Page 9 HDMI SPDIF...
-
Page 23: Table Of Contents
Contents Contents GENERAL INFORMATION Main Features For your Safety Unpacking General Operation INSTALLATION MAIN MENU 1. Media 2. Games 3. Live TV 4. Apps 5. Surfs TROUBLE SHOOTING SPECIFICATION... - Page 24 GENERAL INFORMATION GENERAL INFORMATION This Receiver will take you to the new and exciting world. A world of crystal clear wide screen pictures, digital sound, more information and new services. To make full use of your new receiver please take the time to familiarize yourself with the extensive features of the unit detailed in this User Guide.
- Page 25 GENERAL INFORMATION GENERAL INFORMATION For Your Safety To avoid electric-shock hazards, do not Keep the receiver away from flower vases, open the cabinet, refer servicing to qualified tubs, sinks, etc., in order to avoid damaging personnel only. the equipment. Do not expose the receiver under the Do not block ventilation holes of the sunlight.
- Page 26 GENERAL INFORMATION GENERAL INFORMATION Unpacking(optional) Batteries Remote Control User’s manual General Operation Throughout this manual you will notice that the daily operation of the receiver is based on a series of user friendly on screen display and menus. These menus will guide you through installation, channel organizing, viewing and many other functions.
- Page 27 Enter main menu When watching a channel, change channels or move to the next higher or lower item in the menu When watching a channel, adjust the volume or move to the left or right item in the menu...
- Page 28 This feature has been added to STB Remote controller as an added value and preventing the necessity of keeping the TV RCU at near while watching TV with Next brand STB source.
- Page 29 INSTALLATION INSTALLATION Rear Panel LNB IN: CONNECT TO SATELLITE ANTENNA LNB OUT: CONNECT TO THE OTHER RECEIVER WIFI EQUIPMENT CONNECT TO CONNECT TO A PC INTERNET FOR S/W UPGRADE POWER ON/OFF CONNECT TO TV USING A SCART CABLE CONNECT TO USB DEVICE CONNECT TO TV SET HDMI INPUT DIGITAL AUDIO OUTPUT, CONNECTS VIA COAX CABLE TO AN AUDIO DECODER DIGITAL AUDIO OUTPUT, CONNECTS VIA OPTICAL CABLE TO AN AUDIO DECODER...
- Page 30 INSTALLATION INSTALLATION Connecting to TV using HDMI support Satellite Dish HDMI Connecting to Digital Amplifier Satellite Dish DIGITAL AUDIO CONVERTOR OR SPDIF AMPLIFIER SPEAKER The picture is only for reference, please make the object as the standard.
-
Page 31: Main Menu
Press key to pop up a function list, this function list contents setting and music item. In setting list you can slides mode and slide anim. In music list you can play and pause music, select previous and next music. - Page 32 The Net contents are provided by the operator's partner (content provider). The local contents are owned by the end user in USB or hard drive.
- Page 33 MAIN MENU MAIN MENU 3.1 Program Search 1. Press keys to select the satellite up or down. Press OK key to select and mark, and you can press OK key again to cancel the selection and the mark. 2. Press red color key to Add TP. Use numeric keys to input the frequency and symbol.
- Page 34 MAIN MENU MAIN MENU Position No., & Save: The range is from 0 to 63. "0" delegates the original position. Position No., & Save: The range is from 0 to 63. "0" delegates the original position. You can select the proper value when you has rotated the antenna. You can select the proper value when you has rotated the antenna.
- Page 35 TV Guide(or Radio Guide if you are listening to radio channels) which will show the titles and other information of the current and next programs on different channels. The information is only available from the network to which the channel you are watching belongs.
- Page 36 MAIN MENU MAIN MENU 4. Apps In Apps we provide many Apps such as Browser, Weather, Youtube, Twitter, Facebook, Market, Downloads, Setting and so on. You can download apps, install and uninstall apps in this menu. Here we take System and Home Share menu to explain. 4.1 Settings This menu consists of 12 major sub-menus as follows - Network...
- Page 37 MAIN MENU MAIN MENU c) Booking manager You can manage the program you have booked in this window. If you don't book any program this list is empty. d) Record Manager 1. Timeshift switch: Select Off or On. 2. Timeshift setup : Press OK key to timeshift setup window, press number to input the record time.
- Page 38 MAIN MENU MAIN MENU 4.1.3 AV This menu consists of video resolution, video aspect ratio, adaptive mode, audio mode, scart mode, volume unification setting and press sounds. Video Resolution: Select among Auto, PAL, NTSC, HD_720P, HD_1080I and HD_1080P. Video Aspect Ratio: Select among Auto, 16:9 and 4:3. Video Format: Select among PAN_SCAN, LETTER BOX, COMBINED and IGNORE.
- Page 39 MAIN MENU MAIN MENU 4.1.6 Language & input Select language: Select between Chinese and English. Keyboard and input methods: Select among default, android keyboard and Google Pinyin input method. 4.1.7 Date & Time Time source: Select between TDT Time and NTP time. Choose Timezone: Press key to select timezone.
- Page 40 MAIN MENU MAIN MENU 4.1.12 About In this menu you can know hardware version, software version, User ID, MAC address and Sequence ID. 4.2 Home share Enter Home share menu, to initiate Home Share function with default setting, please enter Home menu and make sure the Start option selected.
-
Page 41: Trouble Shooting
TROUBLE SHOOTING TROUBLE SHOOTING Problem Possible causes What to do The display on the front Check that the main cable is plugged into Main cable is not connected. panel does not light up. the power socket. No sound or picture, but the receiver is in standby mode. - Page 42 SPECIFICATION SPECIFICATION...
