3.885.5275.200
Installation and Maintenance Instructions
The PED Directive 97/23/EC is repealed and replaced by the new
PED Directive 2014/68/EU with effect from 19 July 2016.
E X P E R T I S E
S O L U T I O N S
Torque Tube TB300
Digital Transmitters
S U S T A I N A B I L I T Y
1.
Safety information
2.
Technical information
3.
Commissioning
4.
Troubleshooting
5.
Maintenance
6.
Spare parts
Ed. 1.1 IT - 2012
© Copyright 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TB300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Spirax Sarco TB300

  • Page 1 3.885.5275.200 Ed. 1.1 IT - 2012 Torque Tube TB300 Digital Transmitters Installation and Maintenance Instructions The PED Directive 97/23/EC is repealed and replaced by the new PED Directive 2014/68/EU with effect from 19 July 2016. Safety information Technical information Commissioning Troubleshooting Maintenance Spare parts ©...
  • Page 2: Safe Handling

    ATTENZIONE Lavorare in sicurezza con apparecchiature in ghisa e vapore Working safely with cast iron products on steam Informazioni di sicurezza supplementari - Additional Informations for safety Lavorare in sicurezza con prodotti Working safely with cast iron in ghisa per linee vapore products on steam I prodotti di ghisa sono comunemente presenti Cast iron products are commonly found on steam...
  • Page 3 Prevenzione dai colpi d’ariete - Prevention of water hammer Scarico condensa nelle linee vapore - Steam trapping on steam mains: Intervalli di 30÷50 m. intervals Vapore Steam Gruppo di scarico Vapore Gruppo di scarico Trap set Steam Trap set Gruppo di scarico Trap set Condensa - Condasate Condensa - Condasate...
  • Page 4 Prevenzione delle sollecitazioni di trazione Prevention of tensile stressing Evitare il disallineamento delle tubazioni - Pipe misalignment: Installazione dei prodotti o loro rimontaggio post-manutenzione: Installing products or re-assembling after maintenance: Evitare l’eccessivo serraggio. Per garantire l’uniformità del carico e dell'allineamento, Utilizzare le coppie di serraggio i bulloni delle flange devono essere serrati in modo raccomandate.
  • Page 5 Dilatazioni termiche - Thermal expansion: Gli esempi mostrano l’uso corretto dei compensatori di dilatzione. Si consiglia di richiedere una consulenza specialistica ai tecnici dell’azienda che produce i compensatori di dilatazione. Examples showing the use of expansion bellows. It is highly recommended that expert advise is sought from the bellows manufacturer.
  • Page 6 Index 1. Safety information 2. Technical information 2.1 Description 2.2 Technical data 2.3 Mounting 2.4 Dimensions 2.5 Electrical connection 3. Commissioning 4. Troubleshooting 5. Maintenance 6. Spare parts 6.1 Orientable torque tube spare parts list 6.2 Not-Orientable torque tube spare parts list 6.3 Magnet spare parts list 6.4 Transmitter spare parts list 3.885.5275.200...
  • Page 7: Safety Information

    Group 2 of the above mentioned Pressure Equipment Directive. The products’ use on other fluids may be possible but, if this is contemplated, Spirax Sarco should be contacted to confirm the suitability of the product for the application being considered.
  • Page 8: Protective Clothing

    Customers and stockists are reminded that under EC Health, Safety and Environment Law, when returning products to Spirax Sarco they must provide information on any hazards and the precautions to be taken due to contamination residues or mechanical damage which may present a health, safety or environmental risk.
  • Page 9: Technical Information

    2. Technical Information Description Series TB300 torque tube liquid level instruments utilize the buoyancy exerted on a displacer when immersed in a liquid. The buoyancy on the displacer is proportional to the liquid level and operates on an elastic torque tube which, transforming the applied force in a rotary movement, operates the magnet and consequently the electronic transmitter.
  • Page 10 Tecnical data Torque tube 0÷ 356 mm (14") 0÷ 508 mm (20") 0÷ 610 mm (24") 0÷ 813 mm (32") Standard ranges of measurement in mm 0÷1219 mm (48") 0÷1524 mm (60") 0÷1829 mm (72") 0÷2134 mm (84") (or inches) 0÷2439 mm (96") 0÷2743 mm (108") 0÷3048 mm (120")
  • Page 11 Mounting The level transmitter TB300 are described in detail in the data sheet 7E.300. They are available for external mounting (displacer cage type) or for top or side mounting (displacer internal to process, without cage) The mounting on the tank is achieved by means of flanged connections and the various styles are shown in figure 4.
  • Page 12 Dimensions Mounting and Dimensions for Fixed position version (F) (mm) Ranges Ø Displacer Inches 14" 20" 24" 32" 507.5 1190 1077 406.5 48" 1219 710.5 1596 1483 1219 1332 609.5 60" 1524 1901 1788 1524 1637 72" 1829 * 1829 1015.5 2206 2093...
  • Page 13 Mounting and Dimensions for Adjustable position version (O) (mm) Range Ø Displacer Inches 14" 20" 24" 32" 486.5 1083 1013 406.5 48" 1219 689.5 1489 1419 1219 1289 609.5 60" 1524 1794 1724 1524 1594 72" 1829 994.5 2099 2029 1829 * 1899 914.5...
  • Page 14 Top mounting MT Side mounting ML * Arrangement of connections TF - Top and Bottom TL - Top and Side LL - Side and Side LF - Side and Bottom Mounting with External displacer cage * Fig. 6 - Mounting styles Electrical connection Reach the wiring block by removing the Electrical Connection Cover.
  • Page 15 Avoid routing signal wiring close to power cables or switching equipment. The TB300 is protected against reverse polarity, and can withstand ±50 mA without damage. The TB300 connection could be done conform the figure 9 and 10. For proper operation, the Hand-Held Terminal requires a minimum load of 250 Ohm between it and the power supply.
  • Page 16 Connection of the TB300 in multidrop configuration should be done as in Fig. 10. Note that a ma- ximum of 15 transmitter can be connected on the same line and that they should be connected in parallel. Take care to the power supply as well, when many transmitters are connected on the same line.
  • Page 17 3. Commissioning The transmitter is calibrated in the factory, nevertheles ot is possible to recalibrate it in the field through the "simple adjusting" procedure. There are two orifices on the Transmitter , under the nameplate, identified by "S" and "Z" respectively, which provide access to two magnetic switches actuated by means of a magnetic tool (Refer to Fig.12).
  • Page 18: Troubleshooting

    4. Troubleshooting DIAGNOSTIC SYMPTOM PROBABLE ERROR SOURCE • Position Transmitter Connections • Check wiring polarity and continuity Position is • Power Supply not display • Check load curve • Electronic Circuit Failure • Check the boards for malfunctions and faulty boards for spare ones In case of exceptional events, like strong shocks or earthquakes, please verify operating functionality and execute the calibration procedure.
  • Page 19: Spare Parts

    6. Spare parts Orientable torque tube spare parts list Displacer and torque tube detail Part. No. Description Adjustable slide Screwed pillar Graduade sector Torque tube Slide screw Retaining ring Link Fixing washer Socket head screw M4x16 Screw M2x5 Bolt Washer Upper screwed plug 27-29) Gaskets Screw...
  • Page 20 Non-Orientable torque tube spare parts list Displacer and torque tube detail Part. No. Description Adjustable slide Fixing washer Graduated sector Screw M2x5 Slide screw Washer Link 27-29-30) Gaskets Socket head screw M4x16 Displacer cage Lever Screwed plug (1¼" NPT) Torque tube arm Screw Upper connecting flange set Lever slide...
  • Page 21 Magnet spare parts list Part. No. Description Spacer Screw Blind flange Nut + washer Pillar Bush Screw + Washer Magnet Screw Housing Flange Screw Plate Screw 3.885.5275.200...
  • Page 22 Transimitter spare parts list Part. No. Description Cover 'O' rings Screw Digital indicator Main board Sensor locking screw Cover locking screw Housing Protections cap Identification plate with fixing screw Terminal block Screw Cover External ground screw Transducer 'O' rings 3.885.5275.200...
  • Page 23 REPAIRS Please contact our nearest Branch Office or Agent, or directly Spirax-Sarco S.r.l. Via per Cinisello, 18 - 20834 Nova Milanese (MB) – ITALY - Tel.: +39 0362 49 17.1 - Fax: +39 0362 49 17 307 LOSS OF GUARANTEE Total or partial disregard of above instructions involves loss of any right to guarantee.
  • Page 24 Spirax-Sarco S.r.l. - Via per Cinisello, 18 - 20834 Nova Milanese (MB) - Tel.: 0362 49 17.1 - Fax: 0362 49 17 307 3.885.5275.200 Ed. 1.1 IT - 2012.04...
