Chapter 2: Introduction - Strongman Tools Telford Installation Manual & Operation Instructions

This Manual has been made to supply the owner as well the user with the basic instructions for
installation and a correct use of the Single post car parking lift .
Read this guide carefully before using the lift and follow the instructions given by this guide to grant
it a correct function, efficiency and a long service life.
Single post car parking lift is dependant parking type where it requires valet to
remove lower car away before lowering the platform.
This lift is suitable for residential parking purposes. The platform moves only vertically, so that the
users have to clear the ground level to get the higher level car down. It is hydraulic driven Type that
lifted directly by cylinder with chain connected to carriage.
This is electro-hydraulic lift used ONLY for motor vehicle parking.
The product designed according to the EN 1493:2010 and EN 14010:2003+A1:2009.
Reference of Directive Machine: 2006/42/EC.
Working Principle:
1. When operating the unit and pushing UP Button, the hydraulic power unit will be electrically
activated to pump hydraulic oil from tank to hydraulic oil cylinder.
2. The hydraulic cylinder will pull upwards the steel chain which is connected to the carriage.
3. The carriage will lift the platform as both of them are connected with bolts.
4. Once reaching pr-determined lifting height, the carriage will touch the limit switch and stop
the hydraulic motor.
5. The ground floor under the platform is free for parking lower car.
