- Page 1 Installation manual Navigation & User manual: Available to download from: www.polarisgps.com.au...
- Page 2 SD card) • The installation of 3rd party apps that may cause harm to the unit Warranty Terms The Hilux Maxx is covered for 3 years and includes: • Defective Equipment • Defective Cables Not Covered under warranty: Abuse •...
- Page 3 7-10 Pulling the OEM Head unit out Removing brackets from OEM fascia and head unit Attaching Hilux Maxx to OEM bracket and fascia Plugging Hilux Maxx into factory plugs OEM Hilux reverse camera Polaris / Aftermarket reverse camera wiring diagram...
-
Page 4: Power Harness
Please make sure you ALSO plug the Cam in RCA plug coming from that particular plug into the Cam in RCA input that plugs Yellow RCA plugs: Cam in into the back of the Hilux Maxx. -
Page 5: Wiring Diagram
Wiring Diagram... -
Page 6: Installation Notes
When pulling the dash apart, please use quality trim tools to avoid damaging your dash. Please do NOT cut any plugs off of any Polaris cameras. Doing so will void your warranty! If you need to blend other brand cameras into our system, please call Polaris on 1300 555 514 so we can refer you to a recommended dealer who has the skill and experience in performing this type of work. - Page 7 The following installation pictures have been taken using the Hilux Maxx head unit. The same principle applies when removing the factory head unit. Start by removing the two plastic screws in the gauge housing with a stubby screw driver. Gently Pull at both ends of the gauge housing to pop it...
- Page 8 With your fingers, gently pry open the long dash trim panel above the radio gradually working your way down until it’s completely removed. Now open the bottom glovebox so that you can grab the top glovebox. Gently pull it out and put aside.
- Page 9 Next is the air conditioning control panel. Get your fingers in behind the panel, pull forward to pop it out and let it sit there.
- Page 10 There are 4 screws that need to be undone (use a 10mm / phillips head), two up the top and two down the bottom. Once they are all out, pull on the fascia and pop it forward.
- Page 11 Before removing the fascia be sure to unplug the white plug in the back of the fascia on the left hand side. After this, unplug all the factory plugs from the back of the OEM head unit. Remove factory unit and brackets from fascia.
- Page 12 Push down the 5 metal clips located on the back of the Hilux Maxx. Once this is done screw the brackets back onto the fascia and slide the Hilux Maxx in all the way until the two holes on each side line up. Once you are happy with the positioning, screw the head unit to the brackets.
- Page 13 Please ensure that you also plug the CAM in yellow RCA jack into the CAM in located on loom no. 10 from the Hilux Maxx (please see page 3). See page 13—14 on how to wire up an aftermarket /...
- Page 14 Reverse Camera wiring Back of Hilux Maxx 15 pin plug You will need to tap into the Cam In Reversing wire (orange wire with black stripe) and run the wire to the reverse Light positive to trigger the Red = 12 Volt positive camera when the vehicle is in reverse.
- Page 15 Use the control box setup to plug an additional 2 cameras into the head unit when the front camera input Is already being used Figure 1 Figure 2 Hilux Maxx Loom Connect to CAM IN on the back of 15 pin plug Hilux Maxx...
- Page 16 Mount the Bluetooth microphone onto the steering wheel. Put the unit and fascia back into place, remembering to connect the white plug into the back of fascia. Follow the installation tips in reverse to put all the panels back...
- Page 17 Hilux Maxx. Refer to the user manual for instructions on how to use the Hilux Maxx. If you have any questions or concerns about fitting the Hilux Maxx, please give Polaris a call on 1300 555 514.
