Vizi-tec SBT-4K User Manual page 9

Attribute#3 - MODULATION definitions:
(switch location)
SWT 1 SWT 2 SWT 3
The third attribute. This can also be called the gain or rise of the profile. The lower the variable, the less modulation for a given
profile. The higher the variable, the more modulation. See appendix B (Pg.12) for a table of how the pulse number varies with the
profile time segments.
Examples:
If set to "0 0 0"= Standard" with grace period of 12 seconds and wait 36 seconds into the profile. 4 pulses will happen.
If attribute is set to "0 1 1" = Aggressive C and repeat above. 6 pulses will show.
From factory attribute may be set to "2=Standard". This setting was carried over from SB1 and SB2 product default.
Note: Profile updates do not take effect until after the next brake cycle.
SWT 4 SWT 5 SWT 6
Toggle Switch Position
6=Off 7=Off 8=Off
6=Off 7=Off 8=On
6=Off 7=On 8=Off
6=Off 7=On 8=On
6=On 7=Off 8=Off
6=On 7=Off 8=On
6=On 7=On 8=Off
6=On 7=On 8=On
Contact email@vizi-tec.com
SWT 7 SWT 8 SWT 9
Value
Standard
Aggressive A
Aggressive B
Aggressive C
Aggressive D
Berserk A
Berserk B
Berserk C
for more information
www.vizi-tec.com
November 26, 2017
SWT 10 SWT 11 SWT 12
Page 9 of 24
