- Page 1 STAM AUDIO ENGINEERING SA-1073 EQ - USER MANUAL 1073 EQ - USER MANUAL PAGE 1...
-
Page 2: Important Safety Instructions
STAM AUDIO ENGINEERING IMPORTANT SAFETY INSTRUCTIONS The lightning flash with the arrowhead symbol, within an equilateral triangle, is to alert the user to the presence of non insulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to humans. - Page 3 21. Use this equipment in tropical and/or moderate climates. ● Stam Audio accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph, or statement contained herein.
- Page 4 STAM AUDIO ENGINEERING 1.0 INTRODUCTION The Stam Audio 1073EQ is the finest replica of the legendary british channel strip available on the market today. With several other brands attempting to clone this vintage design, we decided to go the extra mile.
- Page 5 ● ● Carnhill inductors The Stam Audio 1073 EQ is completely hand made in Chile. This is the only way we can manufacture it with these type of essential components. FEATURES ● High Frequency: +/-16dB fixed frequency shelving at 12kHz ●...
- Page 6 STAM AUDIO ENGINEERING 2.0 CONTROLS Applies 48V phantom power to the XLR microphone input. The adjacent LED lights when phantom power is active Activates EQ circuit in between Preamp section (GAIN KNOB) and output amplifier (TRIM). HI-Z The default input impedance on the microphone input is 300Ω. Pressing the HI-Z button switches the input for 1200Ω...
- Page 7 STAM AUDIO ENGINEERING GAIN SWITCH Adjust the preamplifier gain in 5 db increments. The right side is for line and the left side is for mic. There are 2 OFF steps, between Line and Mic and between the 2 gain stages of Mic operation.
-
Page 8: Specifications
STAM AUDIO ENGINEERING 4.0 SPECIFICATIONS Power Requirements 115/230 VAC, 30W Frequency Response 10Hz to -3dB at 40kHz Mic Input Impedance ≈1200/300 Ω Line Input Impedance 10k Ω DI Input Impedance ≈150k Ω Output Impedance 65 Ω Maximum Output Level +27.4 dBu @ 600Ω...
