- Page 1 Instruction manual Spin srl Via Casalecchio 35 - Rimini Italy - tel.0039.0541 730777 -731315...
-
Page 3: Table Of Contents
CONTENTS Cap. 1 – General information – security regulations - Page 4 Cap. 2 - Technical specifications Page 5 Cap. 3 - Installation of security parameter Page 6 Cap. 4 – Description of the station Page 7 Cap. 5 – Preparation of the station Page 9 Cap. - Page 4 This manual is supposed for the using and maintenance of the recycling, recovery, vacuum and recharge station OK CLIMA. It is absolutely necessary to read this manual attentively before the using the device. This device is equipped with means of security, which are helpful to protect the user against harms or injuries.
-
Page 5: Cap. 2 Technical Specifications
CAP. 2 TECHNICAL SPECIFICATIONS TECHNICAL CHARACTERISTICS Compressor: Hermetic with the recovered automatic oil Capacity: 1/3 PS Recovery capacity (liquid phase) 400gr/min Vacuum pump: One-step Capacity: Vacuum grad: 7x10 Vacuum test: Automatically with alarm sound and message on display Deposit bottle: With heating –... -
Page 6: Cap. 3 - Installation Of Security Parameter
3.3 PERFORMABLE WORKS The OK CLIMA is capable to perform the following phases: recovery, recycling, vacuum and charging of air conditioning plants for vehicles and industrial vehicles, which contain freon R134A. The producer denies every responsibility which derives from the forbidden use of other Freon. -
Page 7: Cap. 4 Description Of The Station
CAP. 4 DESCRIPTION OF THE STATION Fig. 3a Fig. 3 Fig. 4 Fig. 4a Fig. 6 Fig. 5a Fig. 5 Fig. 6a... - Page 8 LEGEND HIGH PRESSURE GAUGE LOW PRESSURE GAUGE BOTTLE PRESSURE GAUGE DISPLAY LCD ILLUMINATED WITH 2 LINES KEY “+” FOR CHANGING THE CHOICE/PARAMETER KEY “-” FOR CHANGING THE CHOICE/PARAMETER KEY “ENTER” TO CONFIRM THE CHOICE/PARAMETER KEY “C” FOR EXIT/DELETE OF PROGRAM LOW PRESSURE COUPLING HIGH PRESSURE COUPLING HIGH PRESSURE COCK...
-
Page 9: Cap. 5 - Preparation Of The Station
CHAP.5 PREPARATION OF THE STATION FOR THE PREPARATION OF THE USE OF THE STATION WE REFER TO THE PHOTO ON PAGE 5. 1- Install the tubes onto the high- and low pressure coupling (I-L) as described in fig.7. 2- Screw the quick couplings onto the tubes (blue = low pressure – red = high pressure). Fig. -
Page 10: Cap. 6 - Using Of The Station
CHAP. 6 USE OF THE CENTRAL UNIT 6.0 RECHARGE OF GAS (Charge internal bottle) The amount of freon, which is present in the internal bottle, has been inserted for the performance of the check and controll of the station and is sufficient for performing a complete charging; Therefore it is advisable at switch-on to charge the necessary gas with the use of an external bottle. -
Page 11: Manual
6.2 MANUAL From the base menu press the key “ENTER”, like that you can enter into the submenu, which contains the following parameter: RECOVERY, VACUUM, OIL INJECTION, CHARGING; RECOVERY (manual); For the performance of the recovery of freon press the key “ENTER” after the choice “Recovery”. If the plant is empty (PRESSURE ZERO), the message “Attention 7 plant empty, control whether the cocks of the station and the quick couplings are open“... -
Page 12: Half-Automatic
6.3 HALF AUTOMATIC With the program “half automatic”, it is automatically possible to perform the following phases: - Recovery – Oil discharge – Vacuum – vacuum test; Choose from the main menu “half automatic” and confirm with “ENTER”; The display shows: “vacuum time”; Program with the arrow keys “+”and “-”... - Page 13 6.4 AUTOMATC With the program “automatic”, it is possible to execute all phases automatically (from the recovery to the charge); Ensure that the station has a sufficient amount of freon before switching-on the station in order to function properly, otherwise perform a recovery as mentioned in par. 6.0. From the main menu pressing the arrow key “+ “...
-
Page 14: Data Base
6.5 DATA BANK (personalized – vehicles) With the personalized data bank it is possible to memorize 30 vehicles and to give them an appropriate number; like that it is possible to perform all phases by simply calling the appropriate vehicle number; For execution press the key “ENTER”... -
Page 15: Utility
6.6 UTILITY With the program “Using”, it is possible to perform the following steps: gas recharge – calibration test- measure unit – language – printer heading- service Recharge GAS See Chap. 6.0 CALIBRATION TEST Choose “Calibration test” and confirm with key “ENTER”, on the display appears the weight of the gas in the bottle and the coefficient of the cell. -
Page 16: Cap. 7 - Maintenance
CHAP. 7 REGULAR MAINTENANCE To maintain the station with full efficiency it is necessary to perform regular maintenances. The disrespect of performing the maintenances from the customers side frees the producer From every responsibility concerning the guarantee. All maintenance works have to be performed after the separation of the station from the net. Replace the drier filter and the oil of the pump regularly (according to the use) and clean the de-oiling filter as well. - Page 17 Exchange of drier filter. Exchange the drier filter every 100/150 working hours of the recovery compressor or at least every 2 years even when the station is not in continuous use. 1) Separate the rear panel from the station. 2) Unscrew the filter slowly and carefully. 3) Install the new filter (in considering of the direction).
-
Page 18: Cap. 8 - Help On Finding Default Functions
CHAP. 8 Suggestions to solve functioning problems In order to solve problems please keep exactly to the security norms mentioned in Chap 1. PROBLEM Solving The station does not switch-on; Control the security of the mounted line on the switch-on block. The main switch does not illuminate. -
Page 19: Cap. 9 - Plan For Blockage Of Functions
OVERVIEW OVER THE FUNCTIONS “main menus and Under menus” This overview allow a quick localization of a certain function coming from the main menu. Main menu MENU’ 1.Manual 2.Half automatic - 3.Automatic- 4.Data banks 5.Usage – available Gas amount recovery, Vacuum, oil injection, charging Phase 1: from the recovery to the leak test Phase 2: oil injection-charging single phase :... -
Page 20: Cap. 10 Guarantee
CAP. 9 GUARANTEE The device has a guarantee period of 12 months from the date of delivery. Within the guarantee the compressor and the vacuum pump is not included, because it can occur, that the compressor is being treated with a different oil than the recommended one. -
Page 21: List Data Bank
PERSONALIZED DATABASE Number Vehicle modell Vacuum time Duration of Amount of Amount of gas Program (Minutes) Vacuumtest oil (gr) ( Kg) (Minutes) -
Page 22: Declaration Of Conformity Ce
DECLARATION OF CONFORMITY CE COMPANY SPIN srl seated in Rimini, Via Casalecchio 35 DECLARES HEREWITH THAT THE FOLLOWING DEVICE: A/C SERVICESTATION Mod. “OK CLIMA” SERIAL NO ___________________ On which this declaration refers, conforms with the following guidelines: GUIDELINE FOR THE MACHINE SECURITY AND APPROPRIATE...
