USERʼS MANUAL
CARTRIDGE ICE SHAVER
HD12X
HD12X
MODEL
TRANSFER (RE-SALE) OF MACHINE
Should you sell or give the machine
to a 3rd party, make sure that this
"OPERATION MANUAL" goes with
it for safe and correct operation.
CARTRIDGE ICE SHAVER
INDEX
FOR SAFETY ..............................1
PART NAMES AND FUNCTIONS ......4
HOW TO USE ...........................5
CLEANING & MAINTENANCE .........9
SPECIFICATIONS .....................12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hatsuyuki HD12X
Summary of Contents for Hatsuyuki HD12X
- Page 1 CARTRIDGE ICE SHAVER INDEX USERʼS MANUAL FOR SAFETY …………………………1 CARTRIDGE ICE SHAVER PART NAMES AND FUNCTIONS ……4 HD12X HD12X MODEL HOW TO USE ………………………5 CLEANING & MAINTENANCE ………9 SPECIFICATIONS …………………12 TRANSFER (RE-SALE) OF MACHINE Should you sell or give the machine to a 3rd party, make sure that this “OPERATION MANUAL” goes with it for safe and correct operation.
- Page 2 Safety Instructions Safety Instructions ● To ensure the proper use of this product, carefully read and understand all instructions before using this product. ● This instruction manual indicates important safety rules and precautions that must be observed. ● The following is the meanings of the markings and symbols used in this instruction manual. Incorrect operation of machine is dangerous and can cause serious injury or WARNING death. Incorrect operation of machine is dangerous and can cause injury of person or CAUTION material damages . Note: Property damage includes damage to homes, households, livestock, pets, and etc. Examples of Mark / Pictograph : △...
- Page 3 WARNING Do not expose the product to water. In case of using an earth leakage breaker: If the earth leakage breaker turns OFF, Will result in a risk of contact your local dealer. short circuit, electric shock, rust, and malfunction. Turning the switch ON will result in a risk of Contact electric shock and fire. Avoid water dealer Do not damage power supply cord. Turn the power OFF in case any abnormality occurs. Unplug the product, Never work on power cord and cut the power source, and immediately never pull, twist or bundle it. Do not place a heavy thing on it. contact your local dealer. It can damage the power cord and can cause electric shock Operating a product with or fire. abnormality will result in Prohibited Unplug a risk of electric shock and fire. Check for dust on prong of power plug Before attempting any maintenance or and outlet slot at fixed intervals. inspection, ensure to turn the power OFF, Ensure that plug is inserted firmly all the way. unplug the product, and wear gloves. Dust and improper connections Will result in a risk of injury. will results in a risk of electric Maintenance shock and fire.
- Page 4 WARNING Install the product horizontally on a steady Do not use flammable sprays near the product. Keep vapors and flammable material away flat surface. from the product. Improper installation can cause the unit to fall down Vapors or flammable material and result in risk of injury. may catch fire by the spark of electric switches and result in a risk of fire. Level Prohibited Install the product on a waterproof surface. Hold the plug head when unplugging. Do not grasp any part other than the plug head. Water such as dewfall or melting ice may drop from the product Do not pull the electric cord and moisten the surrounding area. off the outlet by grasping the plug cord. Pulling the electric cord may damage the power cord Installation and result in electric shock or fire. Prohibited Avoid direct sunlight. At the end of each day, turn OFF the power switch and unplug the product for safety. Direct sunlight can result in a risk of crack on plastic parts. This is to prevent dust from accumulating on the plug and electric outlet. Dust on plug and outlet can result in a risk of heat and fire. Prohibited Unplug Be sure to switch OFF and unplug ...
- Page 5 PART NAMES AND FUNCTIONS PART NAMES AND FUNCTIONS ● The purpose of this machine is to make shaved ice from pure water ice or flavored ice. Do not use this machine for any purpose other than making shaved ice. Main Body Power Switch Power Plug Main Shaft It rotates during operation. It transfers power to press ice downward. Power Cord Ice holder (Rotor) is fixed on the bottom. Handle This moves the main shaft upward and downward. Cartridge Rotor (Ice Holder) (with blade and blade adjuster) It grips ice and rotates with ice. Put ice in it. Drip Tray Accessory User's Manual Position of Caution Label NOTE ● Do not peel off the Caution Label. ● If the label unsticks or the word on the label fade, please purchase a new label (Caution Label is on the back of the main body.) from your vendor. ...
- Page 6 CHECK BEFORE OPERATION CHECK BEFORE OPERATION ● Please connect the machine plug to AC 220V / 240V, and do not use a generator. Troubles caused by using a generator cannot be guaranteed. IMPORTANT ① Nutritious ice : Nutritious ice must be kept frozen at an appropriate temperature. Unless the temperature is controlled, it cannot be shaved properly. ② Water ice : Ice that is too cold or cloudy in color is not suitable for shaving because it is too hard. Use transparent ice stored for a while at room temperature. Ice that is cloudy in color will not produce soft and fluffy shaved ice. It could damage the blade tip and the blade will not shave ice. Use transparent ice for soft and fluffy shaved ice. ③ Do not put things on the unit.
- Page 7 OPERATION INSTRUCTIONS Plug the machine into outlet. ● Make sure that the main switch is turned OFF before plugging the machine into outlet. Place the Rotor (Ice Holder). ● ① Lower the handle. Rotor Handle ② Place the Rotor on the tip of the main shaft. * The Rotor stays on the main shaft firmly due to magnetic energy. ● Pull the handle upward to raise the rotor. Place ice in the cartridge. Block Ice ● Beware of injury. Cartridge A blade is mounted on the cartridge. Insert the cartridge into the main body. ● Make sure that the cartridge is inserted all the way. IMPORTANT If the cartridge is not inserted all the way, the machine may cause malfunction, or foreign objects may contaminate the cartridge. Lower the handle and hold ice. ● Fix the rotor firmly to the ice. * If this is not observed, the ice may not rotate with the rotor.
- Page 8 Start of Operation ● Place the receptacle for shaved ice under the cartridge and switch on the machine. Turn the blade adjustment knob for the desired ice texture. Turn clockwise for coaser and counter-clockwise for finer. Fine Blade Adjustment Coarse knob Turn off the main switch after shaving ice. ● Then, the rotor stops rotating. Take out the cartridge. ● Pull the handle upward. ① Lift the cartridge. ② Slide it out from the main body. NOTE If you do not lift the cartridge, it will not come out. Take out the rotor. ● Lower the handle and take out the rotor. Clean the cartridge and rotor. CAUTION Turn the blade adjustment knob counter-clockwise to lower the blade before cleaning. The blade is sharp and it can cause injury.
- Page 9 Unplug the machine. ● Be sure to unplug machine after use. OVERLOAD PROTECTOR/RESET This machine is equipped with an overload protector, which will automatically protect the motor by stopping operation in the event of overload. When protector engages, machine will stop. Should this occur, please take the following measures: Switch the machine OFF and unplug machine. Block Ice Check the machine and rectify the problem; eg. Take out the ice from the cartridge in case the blade is stuck in the ice. Then, place the ice back into the cartridge. Blade Cartridge Leave the machine switched off and unplugged for 20 minutes. ● The machine will recover automatically after a 20 minute rest. * If the protector engages often, contact your supplier. ...
- Page 10 CLEANING & MAINTENANCE CLEANING & MAINTENANCE CAUTION Because the plastic parts may be damaged, do not use the following substances. Thinner, benzene, alcohol, petroleum, powder soap, polishing powder, alkaline detergent, acid, soda hyposulfite, scrub brush etc. In case of using chemical cloth, follow the instructions provided with it. DAILY MAINTENANCE ● CLEANING (Cartridge, Rotor, and Drip Tray) Cartridge Bottom Surface Cartridge Rotor Fine Handle Blade Blade Adjustment knob Pull the handle upward and Lower the handle and Turn the blade adjustment take out the cartridge. take out the rotor. knob counter-clockwise to lower the blade below the bottom surface of the cartridge. If the blade is not low enough, it could cause injury. Clean The Cartridge, Rotor, When wiping the cartridge and Drip Tray with a sponge with a sponge or dry cloth, using a soft neutral detergent. please do not wipe it in Then, wipe them with a clean clockwise direction. dry cloth and do not leave any Doing so may cause injury detergent residue. inflicted by the blade on the cartridge. Caution: Beware of the spikes and blade while cleaning.
- Page 11 MAINTENANCE MAINTENANCE YEARLY MAINTENANCE (1 OR 2 TIMES PER YEAR) Checking the earth (ground) cord. Check the earth (ground) cord and its joint to confirm they are not cut damaged or loose. If you find any problems, please contact an electrical expert or engineer. Checking power supply plug. ● Dedicated (exclusive use) outlets. Always use a dedicated outlet for each machine. Never use extension cords or connect to other power supply cords. Never connect multiple plugs into the same outlet. Failure to comply may cause the power supply cord to melt/burn, resulting in electric shock or fire. ● Do not damage power supply cord. Never tamper with the power cord and never pull, twist, or bundle it. Never place heavy objects on top of it. This may damage the power cord resulting in electric shock or fire. ● Keep the plug clean and plug it into outlet correctly. Always keep the plug clean and plug it into an outlet correctly. Dirty plugs or imperfectly connected plugs can cause electric shock or fire. HOW TO KEEP THE MACHINE (STORAGE) To warehouse on store the machine for more than one week, dry it completely and keep the machine in a place free from moisture.
- Page 12 ● Before you call repair services, refer to the following instructions. If the problem is not solved after trying the following suggestions, contact your local dealer. ● Plug in the unit. The unit dosenʼt start. ● Switch OFF, and remove the cause according to instructions on Page 8. ● Set the rotor properly in place. ● The ice is sticking to the rotor. ● Keep the ice at the correct temperature. The unit works, but does not shave ice well. ● Place the ice in the cartridge. ● The ice is not held properly by the ● Set the rotor in place and lower the rotor. handle to hold the ice down. ● Ice cannot be shaved well. ● The blade is dull. Replace the cartridge to a new one. ● Ice cannot be shaved well. ● Turn the blade adjustment knob clockwise to raise the blade for shaving.
- Page 13 SPECIFICATIONS SPECIFICATIONS Model HD12X 230V Electrical 50/60 Hz. 1 PH. Electric Consumption 140/150W Rated Time 8 minutes Unit Dimensions(mm) 267W×354D×479H 10kgs. Unit Net Weight...
- Page 15 Manufacturer : 1533-1 Dogamine, Hagasaki, Kuwana, Mie, 511-0944, Japan.
