TUTORIAL
HOW TO USE THE NODON OCTAN REMOTE
WITH THE VERA EDGE
Any question, please contact
support@id-rf.net

Advertisement

loading
Need help?

Need help?

Do you have a question about the Octan Remote and is the answer not in the manual?

Questions and answers

Related Manuals for nodon Octan Remote

Summary of Contents for nodon Octan Remote

  • Page 1 TUTORIAL HOW TO USE THE NODON OCTAN REMOTE WITH THE VERA EDGE Any question, please contact support@id-rf.net...
  • Page 2 You will find below a tutorial to use the NodOn Octan Remote with the VeraEdge gateway. IMPORTANT NOTE: The NodOn Octan Remote is not yet fully integrated by Vera’s team. Some features are then depreciated or need some advanced technical knowledge to be implemented. 1- OVERVIEW OF THE NODON OCTAN REMOTE...
  • Page 3 “Generic Device”. Before Inclusion, it is advisable to make an Exclusion to ensure that the remote control is not included in another Z-Wave network. To achieve this Exclusion, Please refer to VeraEdge interface and Octan Remote User Guide.
  • Page 4 Once the VeraEdge ask you to perform Inclusion on your Octan Remote, please follow below procedure Simultaneously press the buttons • and + of the remote control for 1 second. The LED glows in pink to confirm the selection. Then press the button •...
  • Page 5 3- SET-UP THE OCTAN REMOTE Important: To enjoy fully the Octan Remote, we advise you to use “Scene” instead of Direct Associations. VeraEdge currently support 2 types of Scene: Central Scene and Scene Activation.
  • Page 6 4 times the name “False”. In this case, consider that the first “false” is Button #1, the second Button #2, etc. You can also create a Scene through the scene menu and select the Octan Remote as a trigger. For this, choose Option “A scene is activated” and specify 10 for button •...
  • Page 7 B. Scene Activation Mode (Advanced Mode) As mentioned above, in order to enjoy the 16 scenes of the Octan Remote, you can use Scene Activation Mode and LUA script. We’re working with Vera’s team to make this feature more user-friendly and convenient in the shortest time.
  • Page 8 Confirm the setting and save it. 2. Ask VeraEdge to apply your configuration Go back to the main menu of the Octan Remote and click on the button called “Advanced”. Go to the tab called “Commands” Once in the menu, click on “configure node right now”.
  • Page 9 Please wait until VeraEdge configures it according to your need. 3. Create a Scene with LUA Script To finish, you need now to create a Scene. Chose the Octan Remote as a trigger and put a scene ID of 0 Then, in the step “Finish the Scene”...
  • Page 10 Octan Remote. First, you have to add configuration parameter to the Octan Remote. Select your Octan Remote in the “Devices” menu and then click on the menu called “Device Options” Then you should arrive on a menu where you can see a button call “Add Configuration settings”.
  • Page 11 “+” and “-“ Confirm the setting and save it. Then go back to the main menu of the Octan Remote and click on the button called “Advanced”. Go to the tab called “Commands” Once in the menu, click on “configure node right now”.
  • Page 12 The 2 others portable controllers of NodOn (Soft Remote and Wall Switch) are working in the exact same manner as the NodOn Octan Remote, once the Inclusion is done. You can apply above tutorial. For Learning modes (Inclusion / Exclusion) of the Wall Switch and the Soft Remote, please refer to the relevant User Guide.
