Channel D Seta
Piccola Mk2
®
Balanced Direct-Coupled Ultra-Wide Bandwidth Ultra-Low Distortion Low Noise Battery Powered Precision Phono Preamplifier
Installation and Use Guide
Seta Piccola for Low Output / Low Impedance (MC) Phono Cartridges and High Output / High Impedance Phono Cartridges (MM)
AGM Rechargeable Battery Power Supply
Advertisement
Table of Contents
Related Manuals for Channel D Seta Piccola Mk2
Summary of Contents for Channel D Seta Piccola Mk2
- Page 1 Channel D Seta Piccola Mk2 ® Balanced Direct-Coupled Ultra-Wide Bandwidth Ultra-Low Distortion Low Noise Battery Powered Precision Phono Preamplifier Installation and Use Guide Seta Piccola for Low Output / Low Impedance (MC) Phono Cartridges and High Output / High Impedance Phono Cartridges (MM)
- Page 2 Channel D Seta® Piccola Mk2 Installation and Use Guide Channel D • Lambertville, NJ • (609) 818-0700 email: softsupport@channld.com web: http://www.channel-d.com Contents Copyright 2008, 2009, 2010, 2012, 2013, 2014, 2015, 2016, 2017 Channel D All Rights Reserved...
-
Page 3: Table Of Contents
Table of Contents Page(s) Getting Started Signal and Power Connections 2 - 3 Internal Switch and Jumper Configuration Moving Coil Configuration and Gain Moving Magnet Configuration and Gain BOOST Gain Setting Gain Adjustment Advice (Recording to Digital) 6 - 7 Cartridge Loading 7 - 8 Single Ended / Balanced Jumpers... -
Page 4: Getting Started
(192 kHz / 24 bit), balanced - input computer audio interfaces. In conjunction with Channel D Pure Vinyl software, used for applying the RIAA phono correction curve, the strengths of the latest, 21st century cutting-edge analog and digital technologies are brought together, delivering superb, high definition, transparent vinyl playback. -
Page 5: Signal And Power Connections
Power Indicator Illuminates when external power is applied and the internal battery is operating normally. TRIM Control The TRIM control is a unique, precision trim control feature used for adjusting the cartridge inter-channel balance. All phono cartridges have some degree of channel imbalance, and this feature allows correction at the source, by making a fine adjustment to the preamplifier input gain. -
Page 6: Internal Switch And Jumper Configuration
The low impedance, balanced FLAT XLR outputs are intended for connection to the balanced inputs of a professional audio interface / ADC, for use with Channel D’s Pure Vinyl software (for Macintosh computers) for applying RIAA compensation (or other similar software on other computer platforms). -
Page 7: Moving Coil Configuration And Gain
Moving Coil / Moving Magnet Configuration, Gain and Load Settings Moving Coil Configuration: Slide the switches toward the white dots on the circuit board, as shown in above photograph. The Left (as facing circuit board) DIP switch should be set so positions 1, 3, 4 and 6 are on (and 2 and 5 are off);... -
Page 8: Moving Magnet Configuration And Gain
Moving Magnet Configuration: Slide the switches away from the dots on the circuit board, as shown in above photograph. The Left (as facing circuit board) DIP switches should be set so positions 1, 3, 4 and 6 are off (and 2 and 5 are on);... -
Page 9: Boost Gain Setting
“BOOST 1” Gain Setting An additional gain of 6 dB can be realized by removing all four jumpers indicated in the illustration below. The jumpers can be removed entirely or placed in a “parking” position. To minimize noise pickup, “park” the jumpers on the pin which is farthest from the center of the board, for each pair of pins. The factory setting is with the jumpers bridged. -
Page 10: Cartridge Loading
If you’re accustomed to using conventional phonograph preamplifiers, the available Seta gain settings may seem somewhat lower than usual. However, they are tailored to using the Seta with Channel D Pure Vinyl’s digital vinyl compensation curve. The required gain is about 10 to 12 dB less than needed in a conventional phono preamplifier, because the signal is provided to Pure Vinyl with treble emphasis (boost) intact. -
Page 11: Single Ended / Balanced Jumpers
Capacitor 150 pf Jumper Open 150 pf Jumper Bridged 33 pF 158 pF 191 pF 47 pF 172 pF 205 pF 68 pF 193 pF 226 pF 100 pF 225 pF 258 pF 150 pF 275 pF 308 pF 220 pF 345 pF 378 pF 330 pF... -
Page 12: Input Ground Bypass Jumper
The shield should be connected to the XLR connector pin 1; positive cartridge connection to pin 2, and negative to pin 3. For more information, see the Pure Vinyl User Guide. Take care to confirm that your turntable / tonearm doesn’t connect the chassis ground or common to any of the cartridge signal leads. -
Page 13: Rechargeable Battery Information
Off the shelf or commercially designed battery maintenance circuits aren’t used because they are simply not designed with the ultra low noise requirements of preamplifiers in mind. The Channel D Seta design is fully analog and ultra low noise. AGM Rechargeable Battery Operation and Charging The Seta should always be kept powered, to maintain both a stable circuit temperature and the condition of the AGM battery. -
Page 14: Specifications
Specifications - Seta Piccola for Moving Coil and Moving Magnet Cartridges • Voltage Gain, Phono Outputs: 32, 35, 38, 41, 44, 47 dB (moving magnet) 55, 58, 61, 64, 67, 70, 73, 76 dB (moving coil); Voltage Gain (Flat Outputs): 20. 23, 26, 29, 32, 35 dB (moving magnet) 43, 46, 49, 52, 55, 58, 61, 64 dB (moving coil) •...
