- Page 1 Channel D Seta Piccola Buffer ® Balanced Direct-Coupled Ultra Wide Bandwidth Active DAC Attenuator With AGM Rechargeable Battery Power Supply Installation and Use Guide...
- Page 2 Seta Piccola Buffer Installation and Use Guide With AGM Rechargeable Battery Power Supply Installation and Use Guide Use Guide Revision 1a Channel D • Lambertville, New Jersey • (609) 818-0700 email: softsupport@channld.com web: http://www.channel-d.com Contents Copyright 2008, 2009, 2010, 2012, 2013, 2014, 2015 Channel D All Rights Reserved...
- Page 3 Table of Contents Page Getting Started Signal Connections Signal Inputs Signal Outputs Power, Gain Adjustment Ground Bypass Jumpers Pin 1 Output GND Single Ended Jumpers Battery Life / Battery Replacement Specifications Seta Piccola Buffer Gain Settings...
- Page 4 After unpacking, connect the provided external power supply to an AC power source and plug the barrel connector into the power jack on the rear panel of the Seta. Note: the switching type, “wall wart” supply was carefully selected for its especially low noise. The switching power supply also provides much better galvanic and high frequency noise isolation from utility power than a linear power supply.
-
Page 5: Balanced Outputs
Unbalanced (Single Ended) Outputs Balanced Outputs Balanced Inputs Power Indicator Power Connector Jack Battery Condition Indicators Power • Connect the barrel connector of the supplied power adaptor to the (tip positive) power input jack. Gain Adjustment WARNING! Always make changes to the Gain with the power amplifier muted or turned off, to keep loud transients from playing through the loudspeakers, which may damage the loudspeakers. - Page 6 AGM battery. The idle (no signal, battery charged) power consumption is only 1 watt. If necessary, the Seta may be disconnected from the power supply for up to a few months without adversely affecting the battery life. Do not store the Seta at elevated temperatures, such as in an attic or garage.
- Page 7 Warranty • One year parts and labor, limited warranty. In the unlikely event your Seta must be returned to Channel D for repair, contact Channel D in advance for a return material authorization number and shipping instructions.
- Page 8 Seta Piccola Buffer Gain Settings Nominal Gain (dB) (Actual) Switch Position (ON) (-29.8) 3, 7 (-23.7) (-17.8) 1, 2, 4, 5, 6, 8, 9, 10 (-11.7) 1, 2, 4, 6, 8, 9 (-9.96) 1, 2, 4, 9 -6 (-5.77)
