GASHUNTER 1 GAS LEAK DETECTION ALARM PANEL INSTALLATION AND OPERATION MANUAL
The GasHunter 1 detects the presence of gases in environments where it is not
supposed to be. Should gas be detected the alarm panel will trigger an internal buzzer
and an LED will start to flash. There are also a number of volt free relays that will switch
when gas has been detected.
OUTPUTS ARE AVAILABLE?
3 X 2 amp Volt free changeover common alarm relay. Will switch state on detecting
an alarm. Perfect for connection to a BMS, an external sounder/beacon, for
switching on a pump or triggering a telephone dialler.
12VDC output for running low voltage devices directly from the panel.
Power fail relay will switch should the mains power be interrupted.
Output connector for Echo repeater panel used for remote monitoring in a different
location to the main panel location.
Mute button - silences the panel after an alarm has been triggered as well as used to
reboot the panel should a fault occur.
Onboard LED outputs for System Healthy, Power On, Gas Leak Detected, Line Fault
and Power Fail.
12VDC 1.2 aH Battery back up 20 hours in standby mode.
Helpline Telephone: 0330 1595933 Installation and Operation manual - GasHunter1 System
(continuously monitors the gas
probes connected for breaks in
Alarm status light
Off - All OK
Red Flashing - Leak Detected
Alarm Test
Button
(press to ensure that the LED
lights are functioning correctly)
Further information is available on our website
Fault monitoring
continuity)
Green - All OK
Red - Fault Detected
Power On
Green - ON
Power Off
No Light
Power Fail
illuminates to
indicate running on
battery backup
Alarm Test
illuminates when
test button pressed
Mute
Button
(press to silence the audio
alarm)
