  • Page 1 MagneMover LITE User Manual Addendum, Air-cooled Motors Document: 10003676721 Version: 01...
  • Page 2 Ver. 01 ® Although every effort is made to keep this document accurate and up-to-date, MagneMotion assumes no responsibility for any errors, omissions, or inaccuracies. Information that is provided in this document is subject to change without notice. Any sample code that that is referenced in this document or included with MagneMotion software is included for illustration only and is, therefore, unsupported.

  • Page 3: Table Of Contents

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Contents About This Addendum ......................5 Purpose ..........................5 Audience ..........................5 Prerequisites ........................5 Reference Documents ......................5 Introduction ..........................6 Overview ..........................6 Air-cooled Motor Overview ....................6 Safety ............................
  • Page 4 Table 6: Labels Used on the 125 mm R 90° Curve Ethernet Air-cooled Motors ....13 Table 7: Air-cooled Motor Pneumatic Connectors ..............21 Table 8: MagneMover LITE Air-cooled Motor Preventive Maintenance Schedule ....23 Copyright © 2019 Rockwell Automation, Inc.

  • Page 5: About This Addendum

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 About This Addendum This document is an addendum to the MagneMover LITE User Manual and describes the air- cooled motor option. Purpose ® This document explains how to install, operate, and maintain the MagneMover LITE (MM ™...

  • Page 6: Introduction

    The motor is delivered with plugs installed in the ports, which allows the motor to be used as a standard MagneMover LITE motor. Remove the plugs to use the air-cooled option. Guide Rail...

  • Page 7: Safety

    See the MagneMover LITE User Manual for all regulatory compliance information. Safety Considerations See the MagneMover LITE User Manual for all personnel and equipment safety information. Symbol Identification See the MagneMover LITE User Manual for all symbol identification and use information.

  • Page 8: Label Identification And Location

    Ver. 01 Label Identification and Location Safety and identification labels are placed on those MagneMover LITE components that require them to provide hazard identification and information about the components at the point of use. This section describes each label, identifies its location, and for safety labels identifies the hazard and possible injuries.

  • Page 9: Figure 3: Label Locations On The 250 Mm Rs-422 Air-Cooled Motors

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Table 2: Labels Used on the 250 mm RS-422 Air-cooled Motors Product Information Label Qty: 1 Location: On the side of the motor Information Label Figure 3: Label Locations on the 250 mm RS-422 Air-cooled Motors Copyright ©...

  • Page 10: Figure 4: Label Locations On The 125 Mm R 90° Curve Rs-422 Air-Cooled Motors

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Table 3: Labels Used on the 125 mm R 90° Curve RS-422 Air-cooled Motors Product Information Label Qty: 1 Location: On the side of the motor Information Label Figure 4: Label Locations on the 125 mm R 90° Curve RS-422 Air-cooled Motors Copyright ©...

  • Page 11: Figure 5: Label Locations On The 1000 Mm Ethernet Air-Cooled Motors

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Table 4: Labels Used on the 1000 mm Ethernet Air-cooled Motors Product Information Label Qty: 1 Location: On the bottom of the motor MAC ID Label S/N:???????????? Qty: 2 MAC:...

  • Page 12: Figure 6: Label Locations On The 250 Mm Ethernet Air-Cooled Motors

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Table 5: Labels Used on the 250 mm Ethernet Air-cooled Motors Product Information Label Qty: 1 Location: On the side of the motor MAC ID Label S/N:???????????? Qty: 2 MAC:...

  • Page 13: Figure 7: Label Locations On The 125 Mm R 90° Curve Ethernet Air-Cooled Motors

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Table 6: Labels Used on the 125 mm R 90° Curve Ethernet Air-cooled Motors Product Information Label Qty: 1 Location: On the side of the motor MAC ID Label S/N:????????????

  • Page 14: Mechanical, Electrical, Magnetic Hazards

    Air-cooled Motors 10003676721 Ver. 01 Mechanical, Electrical, Magnetic Hazards See the MagneMover LITE User Manual for detailed hazard and safety information. CAUTION Crush/Pinch Hazard Moving mechanisms have no obstruction sensors. Do not operate the MagneMover LITE components without barriers in place or personal injury could result in the squeezing or compression of fingers or other body parts between moving mechanisms.

  • Page 15: Specifications

    The exclusion zones that are shown are for the MM LITE motor only. Additional exclusion zones may be required based on the use of the motor. See the MagneMover LITE User Manual for the electrical specifications. Exposed Materials • 316/316L Stainless Steel.

  • Page 16: 250 Millimeter Motor

    The exclusion zones that are shown are for the MM LITE motor only. Additional exclusion zones may be required based on the use of the motor. See the MagneMover LITE User Manual for the electrical specifications. Exposed Materials • 316/316L Stainless Steel.

  • Page 17: 125 Millimeter R 90° Curve Motor

    The exclusion zones that are shown are for the MM LITE motor only. Additional exclusion zones may be required based on the use of the motor. See the MagneMover LITE User Manual for the electrical specifications. Exposed Materials • 316/316L Stainless Steel.

  • Page 18: 1000 Millimeter Motor

    The exclusion zones that are shown are for the MM LITE Ethernet motor only. Additional exclusion zones may be required based on the use of the motor. See the MagneMover LITE User Manual for the electrical specifications. Exposed Materials • 316/316L Stainless Steel.

  • Page 19: 250 Millimeter Motor

    The exclusion zones that are shown are for the MM LITE Ethernet motor only. Additional exclusion zones may be required based on the use of the motor. See the MagneMover LITE User Manual for the electrical specifications. Exposed Materials • 316/316L Stainless Steel.

  • Page 20: 125 Millimeter R 90° Curve Motor

    The exclusion zones that are shown are for the MM LITE Ethernet motor only. Additional exclusion zones may be required based on the use of the motor. See the MagneMover LITE User Manual for the electrical specifications. Exposed Materials • 316, 316L Stainless Steel.

  • Page 21: Pneumatic Specifications

    Ver. 01 Pneumatic Specifications The MagneMover LITE air-cooled motors allow a continuous flow of clean, dry air to provide additional cooling. These motors can be run as normal MM LITE motors by installing the supplied plugs in the port locations.

  • Page 22: Environmental Requirements

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Environmental Requirements Motors Temperature: Operating: 0 °C to 50 °C [32 °F to 122 °F] Storage: -18 °C to 50 °C [0 °F to 122 °F] Humidity: 85% Maximum (relative, noncondensing) Copyright ©...

  • Page 23: Maintenance

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Maintenance Preventive Maintenance Table 8: MagneMover LITE Air-cooled Motor Preventive Maintenance Schedule Component Maintenance Action Frequency* Page # Motor Verify that the air supply is at or below 1.0 3 months or –...
  • Page 24 MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 This page intentionally left blank. Copyright © 2019 Rockwell Automation, Inc. Page 24 of 26...

  • Page 25: More Information

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 More Information MagneMotion Website: www.magnemotion.com Questions and Comments: www.magnemotion.com/contact/ Revision History Ver. Change Description Initial release Added Ethernet air-cooled motors, WEEE disposal information, and mechanical specifications for all motors. Updated label location information, the Pneumatic Specifications and Environmental Requirements, and Preventive Maintenance.

  • Page 26: Rockwell Automation Support

    MagneMover LITE User Manual Addendum, Air-cooled Motors 10003676721 Ver. 01 Rockwell Automation Support Use the following resources to access support information. Technical Support Center Knowledgebase Articles, How-to Videos, FAQs, Chat, User https://rockwellautomation.custhelp.com/ Forums, and Product Notification Updates. Local Technical Support Phone Numbers Locate the phone number for your country.
