Omron WD30 Series Operation Manual

DeviceNet Wireless Units
WD30
Wireless DeviceNet Units Connects
Slaves without Wires
• Up to 3,200 I/O points can be communicated through a Master Unit.
• Uses spread spectrum technology for superior noise resistance in
manufacturing environments.
• Long-range communications have been achieved with a relay function
(3 repeaters max.).
• Message communications are supported.
• Approval for compliance with China, U.S., and European radio wave
standards.
• RoHS Compliant

System Configuration

DeviceNet Unit
CS1W-DRM21
CX-Integrator
Master
DRS2-1
Terminator
DCN2-1
T-branch Connector
Slave
DeviceNet Slave
DRT2
DRT2
Power
Supply
Name
DeviceNet Wireless Master
DeviceNet Wireless Slave
Note: Relay Stations can be used to create up to three layers, and DeviceNet Slaves
can be connected to each layer. Terminators are required when Slaves are
connected to a Relay Station or Slave Station. Refer to the WD30 DeviceNet
Wireless Operation Manual for details on Terminator installation.
DCN1-3C
T-branch Tap with
Terminator
DRT2
DRS2-1
Terminator
DCN2-1
DCN1-3C
T-branch
T-branch Tap with
Slave Connector
Terminator
DRT2
Power
Supply
S8VS
DRT2
CompoBus/S
Programmable Slave
CPM2C-S1@OC-DRT
S8VS
DRS1-T
Terminating Resistor
Terminal Block
Number of I/O points (words used)
1,600 inputs max. (100 words)
1,600 outputs max. (100 words)
512 inputs max. (32 words)
512 outputs max. (32 words)
WD30-ME
(WD30-SE)
DeviceNet network
DCN1-3C
T-branch Tap with
DRT2
Terminator
Power
Supply
S8VS
Master
Power
Supply
S8VS
Repeater
(Layer 1)
DRS2-1
Terminator
DCN2-1
DRT2
T-branch
Connector
Repeater
(Layer 2)
IN
Power
WT30
Supply
I/O Slave
S8VS
Note: It is possible to connect
I/O Slaves for the WT30.
DeviceNet Wireless Units
WD30-SE01
(WD30-ME01)
Configurator
PC Card
(includes Configurator Software)
3G8E2-DRM21
Configurator Software
WS02-CFDC1-J
DRS2-1
Terminator
DCN2-1 T-branch Connector
PLC I/O Link Unit
Slave
DRT2
Digital
Process Controller
E5ER-DRT
DRS2-1
Terminator
DCN2-1
T-branch
Connector
Slave
DRS1-T
DRS2-1
Terminating
Terminator
Resistor
