  • Page 1 SM446 HS NASTRATRICE AUTOMATICA AUTOMATIC CASE SEALING MACHINE MACHINE ENRUBANNEUSE AUTOMATIQUE AUTOMATISCHE KARTONVERSCHLIESSMASCHINE PRECINTADORA AUTOMATICA MANUALE DI ISTRUZIONI E PARTI DI RICAMBIO INSTRUCTIONS MANUAL AND SPARE PARTS LIST MANUAL D’INSTRUCTIONS ET PIECES DETACHEES BEDIENUNGSANLEITUNG UND ERSTAZTEILLISTE MANUAL DE INSTRUCCIONES Y RECAMBIOS...
  • Page 2 - E-Mail: siat@siat.com Instruction manual for the use, maintenance, safety, shipment, storage, unpacking, set-up, repairing, trouble shoo- ting, spare parts and disposal concerning the case sealing machine model SM446 HS. This publication is property of SIAT S.P.A. Via Puecher, 22 - 22078 TURATE (CO) - ITALY Tel.

  • Page 3: Abbreviations And Acronyms

    = polypropylene PTFE = Polytetrafluorethylene Tape replacement 12.3 = Polyvinylchloride Ref. = reference mark Trouble shooting 12.7 SIAT SPA = Società Internazionale Applicazioni Tecniche (Società per Azioni) Tav. = Illustration Blade replacement 13.9 Belt replacement 13.10 Adjustment of belt tension 13.11...

  • Page 4: Manufacturing Specifications

    1-INTRODUCTION MANUFACTURING SPECIFICATIONS The automatic case sealing machine Mod. SM44 HS has been designed and manufactured compling with the legal requirements in force at the date of its manufacture. THE REFERENCE DOCUMENTS ARE: Machines guidelines 2006/42/CE Standards applied UNI EN 415-7 EN 415-9:2009 Guidelines EMC 2004/108/CE Standards applied...

  • Page 5: General Information

    Ampere Model Serial Number Hertz Volt Type Phase FOR AFTER-SALE SERVICE AND SPARE PARTS PLEASE APPLY TO: AGENT/DISTRIBUTOR OR LOCAL AFTER SALE SERVICE: Via Puecher, 22 22078 TURATE (CO) - ITALY Tel. 02-964951 Fax. 02-9682239 E-mail siat@siat.com April 2013 ENGLISH...
  • Page 6 2-GENERAL INFORMATION WARRANTY Within the limits of what is set forth below, Seller agrees to repair or replace without cost to Buyer any defective goods when such de- fect occurs within a period of twelve (12) months from the date in which Seller's goods have been put into use, but in no event beyond thirteen (13) months from the date of shipment.

  • Page 7: General Safety Information

    3-SAFETY GENERAL SAFETY INFORMATION Read all the instructions carefully before starting the work with the machine; please pay particular attention to sections marked by the symbol The machine is provided with a complete safety protection and with a two LOCKABLE EMERGENCY STOP BUTTON placed on the same protection and on the control panel;...
  • Page 8 3-SAFETY SKILL 2 MECHANICAL MAINTENANCE TECHNICIAN This operator is trained to use the machine as the MACHINE OPERATOR and in addition is able to work with the safety protection disconnected, to check and adjust mechanical parts, to carry out maintenance operations and repair the machine.
  • Page 9 3-SAFETY NUMBER OF THE OPERATORS The operations described hereinafter have been analized by the manufacturer; the number of operators shown for each operation is suitable to perform it in the best way. A smaller or larger number of operators could be unsafe. OPERATORS’...

  • Page 10: Residual Hazards

    3-SAFETY RESIDUAL HAZARDS The case sealer SM44 HS has been designed following the EC direc- tives, and incorporates various safety protections which should never be removed or disabled. Notwithstanding the safety precautions conceived by the designers of the machine, it is essential that the operator and service personnel be warned that the following uneliminable residual hazards exis WARNING! Tape cutting blades.
  • Page 11 - Clean the machine using only dry cloths or light detergents. Do not use solvents, petrochemicals etc. - Do not modify the machine or any part of it. The manufacturer will not be responsible for any modifications. - We advise to apply directly to Siat for modifications. - Follow carefully the installation instructions of this manual.
  • Page 12 3-SAFETY Shows the running direction of the belts. Label code: 3.0.01040.96A Show the earth wire connection point on the machine frame. Label code: 3.0.01039.96A Caution!: High voltage Label code: 3.0.01100.96A Tape threading path for upper taping unit. Label code: 3.0.01023.96A Compulsory position to lift the machine with for- ktrucks or other suitable raising equipment.

  • Page 13: Preliminary Information

    4 - PRELIMINARY INFORMATION GENERAL DESCRIPTION OF THE MACHINE The SM446 HS case sealer with side drive belts is designed to seal boxes by applying two tape strips on the top and bottom flaps simultaneously. No operator is required. The machine adjusts itself automatically to the case size and folds the 4 upper flaps. The introduction of the cases into the machine is performed by the indexing system AS24.

  • Page 14: Main Components

    4-PRELIMINARY INFORMATION MAIN COMPONENTS The infeed conveyor is composed of: The machine is composed of: n. 1 frame n. 1 frame n. 4 adjustable legs n. 4 adjustable legs n. 1 electric motor n. 2 columns n. 1 motorized belt n.

  • Page 15: Overall Dimensions

    4-PRELIMINARY INFORMATION OVERALL DIMENSIONS April 2013 ENGLISH...
  • Page 16 5-SHIPMENT - HANDLING - STORAGE MACHINE TRANSPORTATION AND HANDLING The machine and the infeed conveyor are shipped in 2 separate pac- kings, fixed on a wooden pallet. They can be lifted with a normal fork lift. The standard packing is suitable for surface and air transportation. Oversea packing on request.
  • Page 17 6-UNPACKING Cut the polypropylene straps. Use a cutter to remove the part of the carton fixed by the staples along the entire perimeter of the packing. (Otherwise remove the staples by using a suitable tool) After having cut the carton or removed the staples, lift the packing up in order to free the machine.

  • Page 18: Packing Disposal

    6-UNPACKING To lift the machine up, position the lift forks where there are the labels RH side on right hand side or front-back sides and remove the pallet. Machine weight + control board: 480 + 100 kg. Conveyor brackets removal Loosen the nuts 1 and remove the brackets.

  • Page 19: Installation

    7-INSTALLATION 7.0. SAFETY MEASURES Read carefully chapter 3. 7.1. ENVIRONMENTAL CONDITIONS REQUIRED -Temperature min. = 5 °C; max. 40 °C -Umidity min 30%; max. 80% -Dust free environment 7.2. SPACE REQUIRED FOR MACHINEOPERATION AND MAINTENANCE Min. distance from the wall: A = 1500 mm; B = 1000 mm; Min.
  • Page 20 7-INSTALLATION SAFETY GUARDS: INSIDE AND OUTSIDE MACHINE EMERGENCY STOP PUSH-BUTTON Position and assemble the inside (A) and outside (B) guard panels with the upper and bottom brackets and stiffening frofile plates as shown in the pictures. 7.5.1. INSIDE SAFETY GUARDS Support brackets (upper and bottom);...

  • Page 21: Emergency Stop Button

    7-INSTALLATION EMERGENCY STOP BUTTON Furthermore mount the complete bracket with emergency stop but- ton. PNEUMATIC CONNECTION Connect air pipes from the sealing machine to the conveyor centring guides cylinder connectors and to infeed conveyor cylinders. Fitting acronyms shown in the picture identify the pipes number coming from the machine.
  • Page 22 7-INSTALLATION 7.11 Carton sealer front box Box CA1 Cables n.3 and 6 Cable n. 6 Cable n. 3 Carton sealer front box Box CA2 Cable n. 6 Connectors: W77 Motor April 2013 ENGLISH...
  • Page 23 7-INSTALLATION 7.12 Carton sealer rear box Cable n. 5 Indexing unit box and vertical axes motors Cable n.4 Connectors: XP17 W76-76 motor + ground wire on the fixing screw April 2013 ENGLISH...
  • Page 24 7-INSTALLATION Infeed conveyor photocell connection April 2013 ENGLISH...
  • Page 25 7-INSTALLATION 7.13 PRELIMINARY ELECTRIC CHECK-OUT Before connecting the machine to the mains please carry out the following operations: 7.13.1Make sure that the socket is provided with a ground protection circuit and that both the mains voltage and fre- quency meet the indications on the name plate of the machine. 7.13.2Check that the connection of the machine to the mains meets the provisions of law and/or the safety regulations in your country.

  • Page 26: Control Board

    8-CONTROLS 8.1 CONTROL BOARD 1. Main switch 2. Voltage warning light 3. Auxiliaries push button (control board electrical components enabling) 4. Stop button 5. Start button 6. Touch screen control panel 7. Warning (flashing light + buzzer) 8. Emergency stop button REAR BOX 1 Centering guide pressure regulator 2.

  • Page 27: Operation

    9-OPERATION Turn on the air to the machine by the ON/OFF valve; set the main switch in ON position; close the safety guards; release the EMERGENCY STOP button; press Auxiliaries button and Start Button (if there are no alarm signalling). Start button activation: motors start (machine and indexing unit) and lifting of the indexing unit drive belt.
  • Page 28 9-OPERATION 9.3. OPERATION MODES DESCRIPTION The carton sealer works only in automatic: closed safety protection, free emergency stop button, enabled control panel and start button activated, open compressed air circuit. MACHINE START: - Press auxiliaries button (3); verify the lighting of the incorporated pilot lamp.
  • Page 29 9-OPERATION Reset as necessary after intervention for the elimination of the problem that caused the alarm signalling. Press B A: Main page B: Alarm reset C: Reset acoustic signalling D: Alarms log Return to main menu mode (A). SM446-HS E: Alarms page F: Machine general reset G: Page mode of manual machine axes drive H: Page operation automatic cycle...
  • Page 30 9-OPERATION - Mode of page of operation automatic cycle - In this condition the machine results ready for the star- ting of the sealing cycle as foreseen. J- Box counter (total non resettable) K: Box counter (partial resettable) L: Indexing unit vertical axe (only visualization) M: Indexing unit horizontal axe (only visualization) N: Machine vertical axe (only visualization) O: Box height (only visualization)
  • Page 31 9-OPERATION 9.4 ALARM SIGNALIZATIONS -000 Emergency -001 Air pressure -002 Min. guides closing -003 Thermal Overload QM1 -004 Thermal Overload QM2 -005 Thermal Overload QM3 -006 Thermal Overload QM4 -009 Origin TI vert. missing -010 Origin TO vert. missing -011 TI horizontal not ready -012 Origin TI horiz.
  • Page 32 10-SAFETY DEVICES OF THE MACHINE 10.1 SAFETY GUARD It limts the access to the machine, protecting the operator from the mo- ving parts. 10.2 BLADE GUARDS Both the top and bottom taping units have a blade guard. 10.3 BELT GUARDS The drive belts are protected by safety covers on their external sides and by rigid elements on the exit side.
  • Page 33 THIS PAGE IS BLANK April 2013 ENGLISH...

  • Page 34: Set-Up And Adjustments

    11-SET-UP AND ADJUSTMENTS 11.0 SECURITY ll the operations to prepare and adjust the machine must be made with the E-stop locked. 11.1. TAPE LOADING ON THE TOP UNIT Insert a tape roll on the drum and push it fully forward. Attach the tape leg to the threading tool (supplied with the tools kit).
  • Page 35 11-SET-UP AND ADJUSTMENTS 11.2 TAPE LOADING ON THE BOTTOM UNIT Remove the bottom taping unit from its housing and put it on a working bench; -Put a tape roll on the drum and thread the tape through the unit as shown on the label in the same manner as for the top unit;...
  • Page 36 11-SET-UP AND ADJUSTMENTS 11.6 MAIN PRESSURE REGULATOR A) it adjusts the entry working pressure B) gauge to read the entry air pressure Optimal working pressure: 6 BAR Feeding tube diameter: 10 mm N.B.: in case the working pressure is below 6 BAR or the feeding tube has a small diameter, some malfunctions can happen! (es: the upper group comes down, the rear flap folder works but the machine stops) 11.7 CENTERING GUIDES PRESSURE...
  • Page 37 11-SET-UP AND ADJUSTMENTS 11.9 BOX HEIGHT PICK-UP 3) Pressure regulator with built-in pressure gauge. The pressure regulator 3 adjusts the pressure according to the board strength. -Decrease in case of light boxes. -Increase in case of strong boxes. -Minimum pressure must be adjusted so that the paddle returns auto- matically in position once the box is passed.
  • Page 38 11-SET-UP AND ADJUSTMENTS 11.10 PNEUMATIC SPEED REGULATORS A) Side belts opening-closing speed regulators B) Centering gudes (infeed conveyor) speed regulators Side belts opening-closing speed regulators These are not common operations. They have to be made only when it has been necessary to work on the pneumatic cylinder. To change the speed, do as follows: unscrew the locking nut 1 turn the knob 2 clockwise to reduce the belts closing speed;...
  • Page 39 11-SET-UP AND ADJUSTMENTS 11.11 SPEED REGULATORS OF THE REAR FLAP FOLDER These are not common operations. They have to be made only when it has been necessary to work on the pneumatic cylinder. To change the speed, do as follows: The speed of the rear flap folder unit can be akjusted by the flow regula- tors mounted on the pneumatic cylinders..

  • Page 40: Machine Use

    12 - MACHINE USE 12.1 OPERATOR CORRECT WORKING POSITION 12.2 MACHINE STARTING - Close the side safety guards - Release the E-stops - Give air to the circuit - Turn the main switch in ON position - Press the AUXILIARIES button - Press the RESET button - Press the START button 12.3 PRODUCTION STARTING...
  • Page 41 12 - MACHINE USE 12.5 CLEANING fore carrying out any cleaning or maintenance operation stop the ma- chine by pressing the OFF button on the main switch. Disconnect the electric power and disconnect pneumatic circuit through valve A. CLEANING - Skill 1 operator Use dry clothes or light detergents.

  • Page 42: Troubleshooting

    12 - MACHINE USE 12.8 TROUBLE SHOOTING SITUATION CAUSE SOLUTION TROUBLE The side belts are not correctly posi- Check the position. tioned. Tape is not centered on the box. The box flaps are not centered. Check the flaps dimensions; the flaps must be equal.

  • Page 43: Maintenance

    13-MAINTENANCE 13.0 SAFETY MEASURES (See section 3) Carrying out maintenance and repairs may require to work in dangerous situa- tions. This machine has been designed making reference to the standards EN292 and EN292/2. 13.1 Tools kit and SPARE parts SUPPLIED WITH THE MACHINE 1 N.1 blade (spare blade for taping unit;...

  • Page 44: Machine Lubrication

    13-MAINTENANCE 13.4 SECURITIES CH ECK-UP 1 Tape units blade guards; 2 Lockable emergency stop push-buttons; 3 Rigid protection plate mounted on the side drives; 4 Safety guards; 13.5 MACHINE LUBRICATION Lubricate quarterly with grease/Metal/metal (see paragraph 13.6): 1 Slide cross bar ball guides for side drives (grease nipples on the blocks) ;...

  • Page 45: Blade Cleaning

    13-MAINTENANCE 13.6 SUGGESTED PRODUCTS FOR LUBRICATION GREASE TYPE: METAL/METAL: B.C.190 HEAVY DUTY (otherwise grease for chains and bearings) METAL/PLASTIC: PLATE MASTER M+L (molybdenum grease and PTFE for plastic and metallic materials) OIL TYPE: regular lubricating oil or general purpose spray lubricant. 13.7 LUBRICATION OF THE TAPING UNIT Lubricate monthly with oil the points shown on Picture.
  • Page 46 13-MAINTENANCE 13.10 SIDE DRIVE BELTS REPLACEMENT Skull 2 operator. Notice: in order to convey the case correctly, it is necessary that both belts have the same level of wear. Remove the plug from the mains and take the air off the circuit. Disconnect the Klingel plug from the socket.
  • Page 47 13-MAINTENANCE Remove the locking screws and the protection covers. Loosen the tensioning screws. Release the nut of the tensioning plate. Remove and replace the drive belt. WARNING! Before setting the new belt, check the wear of the orange plastic rings on the drive pulleys: replace them if they are worn out.
  • Page 48 13-MAINTENANCE 13.11 ADJUSTMENT OF THE BELTS TENSION Check the tension of the belt by pulling it outwards in the middle. A force of 3,5 kg should produce a gap of 25 mm (1 inch) between the belt and the frame. April 2013 ENGLISH...
  • Page 49 LIST OF THE MAINTENANCE OPERATIONS CARRIED OUT ON THE MACHINE Date Description of operation April 2013 ENGLISH...

  • Page 50: Additional Instructions

    14-ADDITIONAL INSTRUCTIONS 14.1 INSTRUCTIONS FOR SCRAPPING AND DISPOSAL OF THE MACHINE The machine is made of the following materials: - steel frame - nylon conveyor rollers - PVC drive belts - nylon pulleys In order to dispose of the above materials please comply with the law in force in your country. 14.2 INSTRUCTIONS ON EMERGENCY SITUATIONS In case of danger/fire: disconnect the electric power.
  • Page 51 15-ENCLOSURES 15.1 STATEMENT OF CONFORMITY to the Directives on Machinery 2006/42 CE. 15.2 SAFETY LABELS The safety labels are important for the correct use of the machine. In case any label is damaged or removed, it is responsibily of the user to replace it immediately. 15.3 EMISSIONS OF RADIATIONS, GAS, VAPOURS AND DUST Nothing to report...
  • Page 53 MACHINE ENRUBANNEU SE AUTOMATIQUE AUTOMATISCHE KARTONVERSCHLIESSMASCHINE PRECINTADORA AUTOMATICA PARTI DI RICAMBIO SPARE PARTS LIST PIECES DETACHEES ERSTAZTEILLISTE RECAMBIOS SIA T S.p.A. - Via Puecher, 22 - 22078 TURATE (CO) ITALY - P.O. BOX 1 Tel. 02-964951 - Telefax 02-9689727 http://www.siat.com - E-Mail: siat@siat.com...
  • Page 54 SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012471 Bancale assemblato c/ins. SM446-HS S471368700A GAMBA SCORREVOLE FORMATORE ASS F144 SIAT S340382600A PIEDINO 312525 LV.F-100-24-M16 x98 - F S450571517Z GAMBA SCORR.FORMATORE CON RIV. F144/146 S300117997A RIGHELLA MILLIM.F144/145 S320085993Z STAFFA ESTERNA SM/XL/3M S321153793A...
  • Page 55 SM446_HS Fig. 15650 Ottobre 2012...
  • Page 56 Figura Descrizione figura Magazzino Prodotto Descrizione 15651 Trav. Scorr. Mot. Ass. SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012476 Traversa guida motorizzazioni c/inserti S4710003200A Pignone 3/8" Z35 c/cuscinetto S3310004292A Pignone Z=35 p=3/8" S3400156A Cuscinetto 6005-2RS1 SKF S340019192Z Anello arresto per foro 47 S330491693Z Rondella /6,5/30X5 S340002693Z...
  • Page 57 28\40 SM446_HS Fig. 15651 Ottobre 2012...
  • Page 58 Figura Descrizione figura Magazzino Prodotto Descrizione 15652 Pressatori laterali SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. S3210014247A Piastra inf. Dx pressatori laterali S3210014347A Piastra inf. Sx pressatori laterali S3210014547A Piastra sup. pressatori laterali S3310004147A Blocchetto unione piastre S340005393Z Vite TSVEI M6X16 zincata S340040393Z Vite TSVEI M5X16 zincata S340002393Z...
  • Page 59 SM446_HS Fig. 15652 Ottobre 2012...
  • Page 60 Figura Descrizione figura Magazzino Prodotto Descrizione 15653 Chiudifalda post. SBA0012492 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012493 Supporto chiudifalde sup. c/ins. SBA0012393 Braccio chiudifalde ass. c/ins. S4304333ZZZ FLANGIA FULL DI BEARING E DADI 800a/3M S332244492A Perno braccio chiudifalde sup. S471228100A Chiudifalda post.
  • Page 61 SM446_HS Fig. 15653 Ottobre 2012...
  • Page 62 Figura Descrizione figura Magazzino Prodotto Descrizione 15653 Chiudifalda post. SBA0012492 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBC0020561T Perno cilindro chiudifalda SM446-HS S340006293Z Rondella piana per vite M12 zincata S340094592Z Anello di sicurezza 8 DIN 6799 S471433300A Cilindro chiudifalde 1 ass. "Festo" S471433100A Cilindro chiudifalde 2 ass.
  • Page 63 SM446_HS Fig. 15653 Ottobre 2012...
  • Page 64 Figura Descrizione figura Magazzino Prodotto Descrizione 15654 Gruppo protezioni SBA0012495 SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. S340398000A Cern. Elesa CFA.65 CH-6 Cod. 422232 SM S3801095ZZZ Maniglia M443/110 S340003393Z Rondella tripla x vite M6 zincata S340057793Z Vite TCEI M6X16 zincata S450480817Z Supporto int.
  • Page 65 SM446_HS Fig. 15654 Ottobre 2012...
  • Page 66 Figura Descrizione figura Magazzino Prodotto Descrizione 15655 Gr. porta unità sup. SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBC20638V Spalla porta unità sup. SBC00020641 Scivolo destro porta unità sup. SBC00020642 Scivolo sinistro porta unità sup. SBC0014869V Carter spalla porta unità S330892993Z Distanziale 10X10X150 S332586695A...
  • Page 67 14 10 12 10 SM446_HS Fig. 15655 Ottobre 2012...
  • Page 68 Figura Descrizione figura Magazzino Prodotto Descrizione 15656 Gr. porta unità inf. SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012478 Spalla dx porta unità inf. c/inserti SBA0012479 Spalla sx porta unità inf. c/inserti S330628493Z Distanziale 12X12X140 SM11 zincato S340002193Z Vite TE M6X12 zincata S340017593Z Rondella piana per vite M6 zincata S340058493Z...
  • Page 69 SM446_HS Fig. 15656 Ottobre 2012...
  • Page 70 Figura Descrizione figura Magazzino Prodotto Descrizione 15657 Gruppo motorizz. SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012480 Motorizz. Dx 220/240-380/415V 50 HZ SBA0012482 Guida sup. dx motorizz. c/inserti SBA0012483 Guida inf. dx motorizz. c/inserti s330596093Z Distanziale es. 10X81 zincato S340002193Z Vite TE M6X12 zincata S340017593Z Rondella piana x vite M6 zincata...
  • Page 71 51-63 3-62 2-61 SM446_HS Fig. 15657/1 Ottobre 2012...
  • Page 72 Figura Descrizione figura Magazzino Prodotto Descrizione 15657 Gruppo motorizz. SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. S331163893Z Vite spec. x tensionamento S3101491ZZZ Distanziale x motori SM/XL/3M S340005593Z Vite TSVEI M5X20 zincata S350050693Z Rondella fissaggio motori S330962392Z ( C ) Puleggia dentata 20XL050 brunita S340038892Z Grano EIPP M5X6 brunito S3401593ZZZ...
  • Page 73 SM446_HS Fig. 15657/2 Ottobre 2012...
  • Page 74 Figura Descrizione figura Magazzino Prodotto Descrizione 15658 Gr. Cass. imp. Pneum. SBA0012491 SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBC00020744V Staffa fissaggio cassetta S340065593Z Rondella tripla x vite M8 zincata S340028093Z Vite TE M8X20 zincata S3310003893A Distanziale fissaggio cassetta S340203293Z Vite TCEI M8X12 zincata S340012393Z Rondella piana x vite M8 zincata...
  • Page 75 SM446_HS Fig. 15658 Ottobre 2012...
  • Page 76 Figura Descrizione figura Magazzino Prodotto Descrizione 15659 Gruppo bancale SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. S4510005147A Supporto piastra connettori c/inserti S340057793Z Vite TCEI M6X16 zincata S340017593Z Rondella piana x vite M6 zincata S3210015147A Carter protezione connettori S340037193Z Vite TE M5X12 zincata S340006193Z Rondella piana x vite M5 zincata SCC0000738...
  • Page 77 SM446_HS Fig. 15659 Ottobre 2012...
  • Page 78 Figura Descrizione figura Magazzino Prodotto Descrizione 15660 Gr. colonne guide SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012473 Struttura superiore assemblata SBC0020631V Protezione dx colonna fissa SM446-HS SBC0020630V Protezione sx colonna fissa SM446-HS SBC0020750V Carter protez. colonna dx SM446-HS SBC0020687V Traversa colonne fisse SM446-HS SCA0001652 Rotaia guida lineare Mod.
  • Page 79 SM446_HS Fig. 15660 Ottobre 2012...
  • Page 80 Figura Descrizione figura Magazzino Prodotto Descrizione 15661 Gr. Bancale SEB0000675 SM446-HS Posizione Ricambio Descrizione Quantità U.M. S340028093Z Vite TE M8x20 zinc. S340012393Z Rondella piana x vite M8 zinc. S340028393Z Dado autobl. M8 basso zinc. S340094592Z Anello di sicurezza 8 DIN 6799 S331079593Z Perno attacco cil.
  • Page 81 SM446_HS Fig. 15661 Novembre 2012...
  • Page 83 Fig. 15646/1 Fig. 15646 Fig. 15646/2 Fig. 15644 Fig. 15649 Fig. 15648 Fig. 15647 Fig. 15645 AS26-650-HS Ottobre 2012 SBC0022349...
  • Page 84 SBC0019745V SQUADRA FOTOCEL./CATADIOTTRO AS26 HS SCC0002208 TFC POLAR E3F2-R4B4-M1-M-E PNP M12 S4304737ZZZ GAMBA CON PIEDINO SA2 SR4 S320589893A STAFFA PER GAMBE E TRAVERSE SIAT 2000 S320567193A PIASTRINE FISS. GAMBA SBC0020710V SQUADRA FTC INGRESSO MACCHINA SBC0020712V CANALINA FISSAGGIO CAVI SU BANCALE...
  • Page 85 AS26-650-HS Fig. 15645 Ottobre 2012...
  • Page 86 Figura Descrizione figura Magazzino Prodotto Descrizione 15648 SEI0001359 AS26-650-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012435 piastra fiancata dx c\ins. SBA0012424 rullo ass. SBC0020697T albero x rullo SBA0012423 rullo zigrinato ass. SBC0019651T dist. D15-24 sp. 19,5 S460424605A supp. c\bearing trasp. Tape ct SBC0019626 piastra fermascatole SCB0000588...
  • Page 87 AS26-650-HS Fig. 15648 Ottobre 2012...
  • Page 88 Figura Descrizione figura Magazzino Prodotto Descrizione 15649 SEI0001359 AS26-650-HS Posizione Ricambio Descrizione Quantità U.M. SBC0020677V guida centr. Vern. SBC0019636 staffa fix guida S340023593Z dado M6 zinc. A bassa resist. S340017593Z rondella piana x vite M6 zinc. SCA0000133 vite TBEI M6x20 iso 7380 zinc. S340020693Z vite TCEI M10 x 20 zinc.
  • Page 89 AS26-650-HS Fig. 15649 Ottobre 2012...
  • Page 90 Figura Descrizione figura Magazzino Prodotto Descrizione 15647 SEI0001359 AS26-650-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012436V supp. Rid. Ass. S3803569ZZZ mot. H71 B5B6 220\240V-380\415V 50Hz SCA0001595 rid. Nmrv 050 pam71 B5 rap.1:7,5 SBC0019647T albero rif. SBC0019649T colonnina rid. S331600200A pignone 3\8" Z17 trasp. Nastro SBC0019665V carter motorizz.
  • Page 91 AS26-650-HS Fig. 15647 Ottobre 2012...
  • Page 92 Figura Descrizione figura Magazzino Prodotto Descrizione 15644 Gr. Protezioni SBA0012470 SEI0001359 AS26-650-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012457 Pannello laterale prem. SBA0012461 Telaio laterale prem. S340398000A Cerniera elesa cfa 65 ch6 S3801095ZZZ Maniglia M443/110 S3401707ZZZ Aggancio x blocco a scatto T330 S3401601ZZZ Blocco a scatto spec.
  • Page 93 AS26-650-HS Fig. 15644 Ottobre 2012...
  • Page 94 Figura Descrizione figura Magazzino Prodotto Descrizione 15646 SEI0001359 AS26-650-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012875 GR.TASTAT. C-PROXIMITY PREM.AS26-650-HS SBA0012454 BRACCIO TASTATORE PREM. AS26-650-HS SBC0014875V Supporto fotocellula tastatore AS24-HS SCC0001987 FOTOCELLULA POLARIZZATA ML8-55/103/143 SCA0000289 CAT.PORTACAVI 0182.30.037.1602.MA/FA S3802029ZZZ CATARIFRANGENTE E39-R1 SM44 SBC0019805V SQUADRETTA FIS.
  • Page 95 AS26-650-HS Fig. 15646 Ottobre 2012...
  • Page 96 Figura Descrizione figura Magazzino Prodotto Descrizione 15646 SEI0001359 AS26-650-HS Posizione Ricambio Descrizione Quantità U.M. SBC0020686V PANNELLO CHIUSURA PROTEZIONE ASSE SBA0012441 PROTEZIONE ASSE ELETTRICO C-INS. SCC0002385 SERVOMOTORE JUNMA + FRENO 400W SBC0015933T Adattatore motore-riduttore S340220392Z RANELLA DI SAFETY "S" (SCHNORR) /5 F144 S340006193Z RONDELLA PIANA X VITE M5 ZINC.
  • Page 97 AS26-650-HS Fig. 15646 Ottobre 2012...
  • Page 98 Figura Descrizione figura Magazzino Prodotto Descrizione 15646_1 Braccio tast. Prem. SBA0012454 SEI0001359 AS26-650-HS Posizione Ricambio Descrizione Quantità U.M. S340058493Z Vite tcei M8x16 zinc. S340012393Z Rondella piana x vite M8 zinc. SBC0017434V Piastra supporto tastatore SBC0017440T Piastrina fiss. Gr. Tastatore SBC0020713V Braccio tastatore SBC0017437V Squadra catena portacavi...
  • Page 99 AS26-650-HS Fig. 15646/1 Ottobre 2012...
  • Page 100 Figura Descrizione figura Magazzino Prodotto Descrizione 15646_2 GR.TAST. C-PROXIMITY PREM. SBA0012875 SEI0001359 AS26-650-HS Posizione Ricambio Descrizione Quantità U.M. SBA0012878 Spalla sx supp. Tast. ass. S3400193ZZZ Cuscinetto 60000 2rs S350050693Z Rondella fix motori S340051693Z Vite tsvei m5x12 zinc. SBC0014796Z Perno tast. SBC0014798T Dist.
  • Page 101 AS26-650-HS Fig. 15646/2 Ottobre 2012...
