Summary of Contents for OriPower H1207
-
Page 2: Table Of Contents
TABLE OF CONTENTS Patio Heater Safety Warnings ------------------------------------------- Part List ----------------------------------------------------------------------- Patio Heater Assembly ---------------------------------------------------- Operating Instructions ----------------------------------------------------- Leak Testing ------------------------------------------------------------------ Gas Requirement ----------------------------------------------------------- Connecting To a Gas Cylinder ------------------------------------------- Important Safety Rules ---------------------------------------------------- Maintenance ------ ---------------------------------------------------------- Storage ------------------------------------------------------------------------ Troubleshooting ------------------------------------------------------------- Technical Data --------------------------------------------------------------- - 1 -... -
Page 3: Patio Heater Safety Warnings
PATIO HEATER SAFETY WARNINGS PLEASE READ THE INSTRUCTIONS BEFORE USING THIS APPLIANCE. THE APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH THE INSTRUCTIONS AND LOCAL REGULATIONS. Do not use this appliance indoors, as it may cause personal injury or property damage. Do not store gas cylinder indoors. -
Page 5: Part List
PATIO HEATER ASSEMBLY ASSEMBLY INSTRUCTIONS Screwdriver / Adjustable Spanners / Wrenches Leak Detection Solution one part detergent and three parts water Before assembly, make sure all protection packing material must be moved. Assembling all nuts and bolts loosely at first. Tighten all connections after completion of assembly. -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS LIGHTING BEFORE FIRST USE AND AFTER EVERY GAS CYLINDER CHANGE, GAS DELIVERY SYSTEM MUST BE PURGED OF AIR BEFORE IGNITING! TO DO THIS, TURN THE CONTROL KNOB ANTICLOCKWISE TO THE PILOT SETTING. PRESS KNOB IN AND HOLD FOR 3 MINUTES BEFORE ATTEMPTING IGNITION. Check all gas connections prior to use. -
Page 8: Gas Requirement
GAS REQUIREMENTS The appliance must use an EN12864 approved gas regulator and CE approved gas hose with a length of 1.3 meter (BS3212 and EN1763-1). You will need to purchase suitable gas hose and regulator from your local gas dealer if the appliance does not include gas hose and regulator. -
Page 9: Maintenance
MAINTENANCE To enjoy years of outstanding performance from your heater, make sure you perform the following maintenance activities on a regular basis: Keep exterior surfaces clean. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents. While washing your unit, be sure to keep the area around the burner and pilot assembly dry at all times. If the gas control is exposed to water in any way, DO NOT try to use it. -
Page 10: Troubleshooting
TROUBLESHOOTING IF THE PROBLEM IS: AND THIS CONDITION EXISTS: THEN DO THIS: Cylinder valve is closed Open valve Blockage in orifice or pilot tube Clean or replace orifice or pilot tube Open gas line and bleed it (pressing Air in the gas line control knob in) for not more than Pilot won’t light 1-2 minutes or until you smell gas... -
Page 11: Technical Data
TECHNICAL DATA Europe: Product Name Patio Heater Model H1207 & H1107 Gas Type Propane, Butane or mixtures Country Code CH-ES-FR-GB-GR-IE-IT-PT BE-CZ-DK-FI-NL-NO AT-DE Category 3B/P 3B/P P(mbar) 28-30/37 Heat input 11kW (786g/h) 13.5kW (960g/h) Injector size(Diameter) 1.8mm 1.6mm Country Code Gas type...
