Minitor EW-01 Instruction Manual

6. PARTS LIST

1.Point Tool
2.Bush
EW-102
3.O-Ring
EW-103
4.Front Housing
EW-104
5.Front Spring
EW-105
6.O-Ring (7.66×1.78)
EW-106
7.O-Ring (12.1×1.6)
EW-107
8.O-Ring (2.5×1.8)
EW-108
9.Valve Ball
EW-109
10.Switch Valve
EW-110
11.O-Ring (3.1×1.6)
12.Ball Guide
EW-112
13.Rear Spring
EW-113
14.Housing
EW-114
15.O-Ring (11.1×1.6)
16.Rear Housing
EW-116
17.Hose Connector M7
18.Air Hose Black 2.5m
19.Hose Connector 1/4
20.Coupler
EW-120
21.Bronze Bush
EW-121
2019.08.16 IME-EW-01
-4-
Read following instructions before attempting to use.
Keep this manual always in the vicinity of use for your reference.
Before using the unit, check if there are any damages on the unit due to
transport conditions. If any damages are found, contact our Minimo dealer.

WARNING

WARNING
(Indicates that incorrect operations presents significant danger of (Indicates that incorrect operations presents significant danger of
accident resulting in death or serious injury to the user.) accident resulting in death or serious injury to the user.)
○ Wear an appropriate eye protection and a respiratory protective equipment
when using the handpiece.
○ Use compressed air with the pressure 4 ～ 7 kgf / ㎠ (56 ～ 99psi)
EW-111
○ Do not attempt to disassemble and remodel the unit.
○ Do not touch the point tool when vibrating.

CAUTION

EW-115 (Indicates that incorrect operation presents possibility of injury to the
user or damage to the unit.)
○ Never push the point tool hard onto the workpiece.
EW-117
Excessive force on the tool will cause damage to the tool and also reduce the
EW-118
cutting power.
EW-119
○ Use air filter and/or dryer to eliminate water, water vapor and any other dust
particle in compressed air.
○ Avoid any heavy impact to the unit. Do not drop it!
○ Keep the unit away from children.
EW-01 WORK MARKER

SAFETY PRECAUTIONS

-1-
