  • Page 1 INSTRUCTION REF: IN166 ISSUE NO. 6 DATE - 21.03.16 Page 1 of 24 INSTRUCTIONS MODEL: P4BO SAFETY INSTRUCTIONS INSTALLATION INSTRUCTIONS OPERATION INSTRUCTIONS MAINTENANCE INSTRUCTIONS CONVERSION INSTRUCTIONS FAULT FINDING TECHNICAL DATA PARTS LIST SPARES LIST WARRANTY INFORMATION Customer Information ______________________ MODEL NUMBER:...
  • Page 2 To avoid scratching the highly polished exterior surface of this equipment whilst in transit, the protective film on the exterior surfaces has NOT been removed. It is IMPORTANT that this protective film is peeled off before the equipment is used. www.parry.co.uk...

  • Page 3: Installation Instructions

    INSTRUCTION REF: IN166 ISSUE NO. 6 DATE - 21.03.16 Page 3 of 24 MODEL P4BO The products stated above are designed and built to comply with the latest versions of the following standards: BS EN 203-1 BS EN 203-2-1 BS EN 203-2-2...
  • Page 4 To adjust the catch, use a screwdriver to press in roller to below the plate, turn clockwise to adjust downward, and anti-clockwise to lift the roller. www.parry.co.uk...

  • Page 5: Gas Connection

    All packing and protective film must be removed from panels etc. prior to commissioning the appliance. All gas appliances must be fitted by a competent person to gas safety regulations in force. www.parry.co.uk...
  • Page 6 5. To turn burners off, turn knob clockwise all the way round. Parry recommends that the hob is used only with pans that have a minimum diameter of 120mm, and up to a maximum of 295mm diameter. This ensures that there is satisfactory combustion, and the pan is stable as it sits on the finger of the pan support.
  • Page 7 A drip tray is fitted beneath the hob burners to catch any spillage, during normal use, this tray may get hot. Only remove when tray has cooled or with suitable gloves. www.parry.co.uk...
  • Page 8 PLATE TARTS FLAKY Parry advise that only pans with between a maximum external diameter of 29cm and a minimum external diameter of 10cm are used on the hob burners of this appliance to ensure stability and satisfactory combustion with the pan supports provided www.parry.co.uk...
  • Page 9 QUALIFIED ENGINEER IN WHICH CASE THE LOW RATE ADJUSTER SHOULD BE RE-SEALED. Parry recommends that this unit is serviced at least every 6 months As part of a full service we recommend the following checks are carried out.  Before any maintenance isolate the appliance from the gas supply ...
  • Page 10 The internal walls of the oven have been vitreous enamelled to make them easy to clean. The oven has two wire shelves and one vitreous enamelled bottom tray. These can be removed for cleaning but the lower tray must be in position when the appliance is being used. www.parry.co.uk...

  • Page 11: Fault Finding

    Dirt or grease broken or loose Clean reconnect / replace connection H.T.Lead Incorrect spark gap Set gap 3-4mm Burner fails on low rate Loose Thermocouple Replace Faulty Magnet in F.F.D. Replace thermostat Burner fails on low rate Thermocouple out of position. Reposition www.parry.co.uk...
  • Page 12 Assemble in reverse order. Ensure locknut is securely tightened. OVEN BURNER/IGNITON - Remove oven base. Disconnect oven supply tube, H.T.lead and thermocouple. Burner is held in by 2 screws. Piezo spark generator is secured by a locknut. Electrode secured to burner bracket by centre screw. www.parry.co.uk...
  • Page 13 NAT hob valve injector HOBINJECT185 injector stamped with 185 Oven valve NAT oven burner injector COPBPS-60 bypass screw stamped with 60 Oven burner NAT oven burner injector INJECT150 injector stamped with 150 Labels NAT GAS only + G20 1 Instructions CONVIN34-4 www.parry.co.uk...
  • Page 14 Page 14 of 24 Instruction Ref CONVIN35 Issue No. Date updated 07/09/2011 LPG – Conversion Instructions P4BO – Paragon 4 Burner Oven Product For use with models with the following serial numbers Model From P4BO-4 11011812 These instructions can be used for converting from Natural Gas to LPG...
  • Page 15 Page 15 of 24 Conversion Procedure for P4BO Warning Ensure the appliance is isolated from the gas supply before commencing conversion (Please note P4BO only has four hob burners) Remove pan support and burner caps. Lift off aluminium burner plates.
  • Page 16 Remove low rate screws in tap body and replace with low rate screw from the conversion kit. Converting the oven burner Unscrew the 15mm nut on the jet that goes into the burner www.parry.co.uk...
  • Page 17 Tighten up the 15mm Unwind the bypass screw on the oven valve and replace with the bypass screw for the required gas Connect the unit back to the gas supply Test for gas soundness Replace the facia and knobs accordingly www.parry.co.uk...
  • Page 18 Page 18 of 24 When conversion is complete affix new data label and gas type label supplied with the conversion kit, detailing type of gas and pressure. TECHNICAL DETAILS : MODEL P4BO Hob Burner OPERATING PRESSURE TOTAL HEAT INPUT (NET) 20mb / 8”...

  • Page 19: Operating Pressure

    26.146 kW = 89211 Btu/h GAS RATE m³/h ft³/h lb/h kg/h NATURAL G20 3.075 m³/h 108.593 ft³/h PROPANE G31 1.002 m³/h 35.385 ft³/h 3.889 lb/h 1.764 kg/h G25 @ 25mbar 3.218 m³/h 113.643 ft³/h AIR FLOW RATE FOR 32.18 m³/h COMBUSTION 20m³/h www.parry.co.uk...
  • Page 20 INSTRUCTION REF: IN166 ISSUE NO. 6 DATE - 21.03.16 Page 20 of 24 PARTS LIST MODEL P4B0 Side View Top View www.parry.co.uk...
  • Page 21 INSTRUCTION REF: IN166 ISSUE NO. 6 DATE - 21.03.16 Page 21 of 24 Item Number Components P4BO New hob burner BURNRHOB New hob valve GASTAPHOB New hob rear thermocouple THCP600ISP New hob front thermocouple THCP320ISP New hob injector Natural Gas...
  • Page 22  Please ensure you have read the section not covered under warranty to avoid any unnecessary warranty charges.  If the problem with the machine can not be resolved please contact the company that supplied you the machine. (SERVICE CALLS CAN NOT BE PLACED DIRECT WITH PARRY) www.parry.co.uk...

  • Page 23: Not Covered Under Warranty

    6 burner cooker.  Excessive carbon build up on griddle plates.  Over use of lava rock on the chargrills recommended use by Parry 2kg only.  Faulty electrics – eg, customers plug socket, plug, wiring, junction box fault, wrong fuse.
  • Page 24 Failure to pay any warranty charges will result in the customers warranty been put on hold until the bill has been settled. Any issues regarding the raised charges should be put in writing to our warranty department for further investigation. Parry Group Ltd Town End Road Draycott Derby...
