- Page 1 technical data Floor Standing Unit FXLQ-MAVE...
- Page 2 technical data Floor Standing Unit FXLQ-MAVE...
- Page 3 • Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE ® • VRV Systems • Indoor Units...
-
Page 4: Table Of Contents
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE TABLE OF CONTENTS FXLQ-MAVE Specifications ............3 Technical Specifications . - Page 5 • Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE ® • VRV Systems • Indoor Units...
-
Page 6: Specifications
Specifications A V E o o r S y s Q - M o o r I n d V R V F X L 1-1 TECHNICAL SPECIFICATIONS FXLQ20MAVE FXLQ25MAVE FXLQ32MAVE FXLQ40MAVE FXLQ50MAVE FXLQ63MAVE Capacity Cooling 2.20 2.80 3.60 4.50 5.60... -
Page 7: Electrical Specifications (50Hz)
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Specifications 1-2 ELECTRICAL SPECIFICATIONS (50HZ) FXLQ20MAVE FXLQ25MAVE FXLQ32MAVE FXLQ40MAVE FXLQ50MAVE FXLQ63MAVE Power Supply Name Phase Frequency Voltage 220-240 Current Minimum circuit amps (MCA) Maximum fuse amps (MFA) Full load amps (FLA) -
Page 8: Safety Device Settings
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Safety device settings FXLQ20MA FXLQ25MA FXLQ32MA FXLQ40MA FXLQ50MA FXLQ63MA PC BOARD FUSE 250V 10A “10 ƒC FAN MOTOR THERMAL PROTECTOR OFF: 135 / ON: 120 or less 3D034529C Options FXLQ20MA FXLQ25MA FXLQ32MA FXLQ40MA FXLQ50MA... -
Page 9: Control Systems
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Control systems Individual control systems FXLQ20MA FXLQ25MA FXLQ32MA FXLQ40MA FXLQ50MA FXLQ63MA WIRED REMOTE CONTROL BRC1D52 INFRARED REMOTE CONTROL Heat pump BRC4C62 Cooling only BRC4C64 SIMPLIFIED REMOTE CONTROL BRC2A51 REMOTE CONTROL FOR HOTEL USE BRC3A61 Centralised control systems FXLQ20MA... -
Page 10: Capacity Tables
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Capacity tables 5 - 1 Cooling capacity tables FXLQ-MA TC: Total capacity;kW - SHC: Sensible capacity;kW Indoor air temperature Outdoor Nominal 14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB Unit size air temp. capacity 20.0DB 23.0DB... - Page 11 • Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Capacity tables 5 - 1 Cooling capacity tables FXLQ-MA TC: Total capacity;kW - SHC: Sensible capacity;kW Indoor air temperature Outdoor Nominal 14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB Unit size air temp. capacity 20.0DB 23.0DB...
-
Page 12: Heating Capacity Tables
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Capacity tables 5 - 2 Heating capacity tables FXLQ-MA Indoor air temperature ƒCDB Outdoor Unit Size Nominal capacity 16.0 18.0 20.0 21.0 22.0 24.0 air temperature ƒCDB ƒCWB -19.8 -20.0 -18.8 -19.0 -16.7 -17.0... - Page 13 • Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Capacity tables 5 - 2 Heating capacity tables FXLQ-MA Indoor air temperature ƒCDB Outdoor Unit Size Nominal capacity 16.0 18.0 20.0 21.0 22.0 24.0 air temperature ƒCDB ƒCWB -19.8 -20.0 -18.8 -19.0 -16.7 -17.0...
-
Page 14: Dimensional Drawing & Centre Of Gravity
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Dimensional drawing & centre of gravity 6 - 1 Dimensional drawing FXLQ20,25MA 20 or more Discharge 1,750 or more 100 or more 100 or more Front face 1,000 or more Suction Base Required installation space Perforated hole for piping... - Page 15 • Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Dimensional drawing & centre of gravity 6 - 1 Dimensional drawing FXLQ50,63MA 20 or more Discharge 100 or more 100 or more 1,750 or more Front face Suction 1,000 or more Base Required installation space Perforated hole for piping...
-
Page 16: Centre Of Gravity
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Dimensional drawing & centre of gravity 6 - 2 Centre of gravity FXLQ-MA Model FXLQ20MA FXLQ25MA FXLQ32MA FXLQ40MA FXLQ50MA FXLQ63MA 4D034527C ® • VRV Systems • Indoor Units... -
Page 17: Piping Diagram
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Piping diagram FXLQ-MA Gas pipe connection port Heat exchanger Liquid pipe connection port Filter Filter Electronic expansion valve 4D034245A ® • VRV Systems • Indoor Units... -
Page 18: Wiring Diagram
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Wiring diagram 8 - 1 Wiring diagram FXLQ-MA Power supply 220-240V 220V 50Hz 60Hz Note 2 Input from outside Note 1 Transmission wiring central remote control Wired remote control Control box (Optional accessory) Indoor unit R2T •... -
Page 19: Sound Data
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Sound data 9 - 1 Sound pressure spectrum FXLQ20,25MA 4D034528A FXLQ32MA 4D034564A Approximate Approximate threshold hearing for threshold hearing for continuous noise continuous noise Octave band center frequency (Hz) Octave band center frequency (Hz) NOTES NOTES Over all (dB):... - Page 20 • Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Sound data 9 - 1 Sound pressure spectrum FXLQ63MA 4D034567A Approximate threshold hearing for continuous noise Octave band center frequency (Hz) NOTES Over all (dB): Scale 230V 240V (B, G, N is already rectified) 39.5 41.5 Measuring place: Anechoic chamber...
-
Page 21: Installation
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Installation 10 - 1 Suspension bolt pitch position FXLQ-MA • Positioning of holes for fastening to the wall • How to open/close the front panel Model FXLQ20,25MA FXLQ32,40MA FXLQ50,63MA 1,010 Open the lid of control panel (both left and right). Remove screws (both left and right). -
Page 22: Service Space
• Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Installation 10 - 2 Service space FXLQ-MA Window Model Air flow direction FXLQ20,25MA 1,030 1,750 or more FXLQ32,40MA 1,170 100 or Front side 100 or more more FXLQ50,63MA 1,450 (FXLQ) (FXLQ) Air inlet 1,000 or 150 or... - Page 23 • Indoor Units • FLOOR STANDING UNIT • FXLQ-MAVE Installation 10 - 2 Service space ® • VRV Systems • Indoor Units...
- Page 24 Specifications are subject to change without environment. This challenge demands the eco design prior notice. Daikin Europe N.V. explicitly rejects any liability for any direct or and development of a wide range of products and an indirect damage, in the broadest sense, arising from or related to the use energy management system, resulting in energy and/or interpretation of this publication.
