- Page 1 P1 Mini User manual PRELIMINARY...
-
Page 2: Welcome
Welcome! Dear User, Thank you for choosing our P1 Mini. We are proud of delivering you the highest quality, the greatest design and the real passion with our product. Each fixture in Portman P range is different, but all of them ensure you the best performance and support your creativity. -
Page 3: Table Of Contents
USER MANUAL – Portman Custom Lights P1 Mini Table of contents Table of contents Welcome! .........................................2 Table of contents ....................................3 Safety information ..................................4 Technical specification ................................7 Fixture Overview ....................................8 Preparation for use..................................10 Operation modes ................................... 13 Menu .......................................... -
Page 4: Safety Information
WARNING This product is for professional use only! It is not for household use. P1 Mini presents risk of lethal or severe injury due to heat, electric shock, fire or falls. Intense and flashing light could trigger epileptic seizures. Read this manual before your initial start-up and follow the safety information in this manual and engraved on the fixture. - Page 5 USER MANUAL – Portman Custom Lights P1 Mini Safety information Protection against electrical shock Disconnect the fixture from AC power when not in use. Disconnect the fixture from AC power before any operation. Do not remove the rear cover. There are no user-serviceable parts inside.
- Page 6 USER MANUAL – Portman Custom Lights P1 Retro Lamp Safety information Protection against eyesight damage and epileptic seizure Do not stare directly into the light sources. Never look at an exposed lamp while it is lit. Provide advance notice that flash light is in use.
-
Page 7: Technical Specification
USER MANUAL – Portman Custom Lights P1 Mini Technical specification Technical specification 778 x 620 x 172 mm dimensions 12,5 kg weight 100 - 240V 50Hz/60Hz input voltage power consumption 3W 1800K filament + 10W RGBW light source 1800 K (filament) + 6300K (glow white) -
Page 8: Fixture Overview
USER MANUAL – Portman Custom Lights P1 Retro Lamp Fixture Overview Fixture Overview Dimensions DMX chart 8/23... - Page 9 USER MANUAL – Portman Custom Lights P1 Mini Fixture Overview Pixels order Back view P1 Mini 9/23...
-
Page 10: Preparation For Use
Only qualified electricians in accordance with all known electrical regulations can install the fixtures. The P1 Mini comes with power input cord terminated with powerCON TRUE1 on one end and tube connectors on the other end. Follow the rules from table below to... - Page 11 Before mounting the fixture read and follow the safety recommendations indicated in the Safety Information. The Portman P1 Mini may be installed on a tripod or on a clamp. The fixture has 13 mm (0,512 in) hole for a spigot, rigging clamp or a screw. Before rigging operations make sure, that the structure onto which you are mounting the fixtures can withstand the weight of all of the fixtures.
- Page 12 USER MANUAL – Portman Custom Lights P1 Retro Lamp You can easily change the orientation of tightened handles to make your rig look even better. Gently pull the tightened handle to disengage its teeth and rotate it into the desired orientation. By releasing the handle the return spring automatically engages the teeth.
-
Page 13: Operation Modes
WDMX to control the fixture(if the WDMX card is installed). You can link the P1 Mini to a DMX controller using a 5 pin DMX wire, or Wireless Solution Sweden hardware (if WDMX card is installed). You can control each channel individually whether with a DMX controller or a manual control build in the fixture. - Page 14 Mini supports bi - directional WDMX TRX module. It means, that the fixture supports RDM in wireless mode too. To link P1 Mini with W-DMX transmitter first use “UPAIR ALL WDMX DEVICES” option from menu, than turn the scanning mode on in the transmitter.
-
Page 15: Menu
USER MANUAL – Portman Custom Lights P1 Mini Menu Menu Navigation buttons are located under the LCD display on the back panel. To enter the menu hold enter button for 2 seconds. To navigate the menu use the “+” and “-“... - Page 16 USER MANUAL – Portman Custom Lights P1 Retro Lamp Menu Menu map Main section Level 1 Level 2 Level 3 Description ADDRESS: DMX ADDRESS Sets up the DMX start address SIMPLE STANDARD Sets up the DMX mode. Refer to DMX chart for DMX channels...
- Page 17 USER MANUAL – Portman Custom Lights P1 Mini Menu FIRMWARE LPU1 Shows actual firmware version of LPU1 board. FIRMWARE LDB1 Shows actual firmware version of LDB1 board. ALL FILAMENTS 0 – 100% BRIGHTNESS Sets all filaments dimmer value FILAMENT CH.1 0 –...
-
Page 18: Dmx Chart
USER MANUAL – Portman Custom Lights P1 Retro Lamp DMX Chart DMX Chart I. Mode Simple Parameter Descripton channel Dimmer Main Source Ch. 1 Pixel 1 filament 8 bit dimmer 0 – 100% Dimmer Main Source Ch. 2 Pixel 2 filament 8 bit dimmer 0 – 100% Dimmer Main Source Ch. - Page 19 USER MANUAL – Portman Custom Lights P1 Mini DMX Chart II. Mode Standard Parameter Description channel Dimmer Main Source Ch. 1 Pixel 1 filament 8 bit dimmer 0 – 100% Dimmer Main Source Ch. 2 Pixel 2 filament 8 bit dimmer 0 – 100% Dimmer Main Source Ch.
- Page 20 USER MANUAL – Portman Custom Lights P1 Retro Lamp DMX Chart III. Mode Standard fine Parameter Description channel Dimmer Main Source Ch. 1 Pixel 1 filament 8 bit dimmer 0 – 100% Dimmer Main Source Ch. 1 fine Pixel 1 filament 16 bit dimmer 0 – 100% Dimmer Main Source Ch.
- Page 21 USER MANUAL – Portman Custom Lights P1 Mini DMX Chart Mode pixel Parameter Description channel Dimmer Main Source Ch. 1 Pixel 1 filament 8 bit dimmer 0 – 100% Red 1 glow Pixel 1 Red 8 bit Green 1 glow...
- Page 22 USER MANUAL – Portman Custom Lights P1 Retro Lamp DMX Chart V. Mode pixel fine Parameter Description channel Dimmer Main Source Ch. 1 Pixel 1 filament 8 bit dimmer 0 – 100% Dimmer Main Source Ch. 1 fine Pixel 1 filament 16 bit dimmer 0 – 100%...
- Page 23 USER MANUAL – Portman Custom Lights P1 Mini DMX Chart P1 Mini 23/23...
