Telegesis
ETRX2PA
©2009 Telegesis (UK) Ltd
ETRX2-PA ZIGBEE® MODULE
PRODUCT MANUAL
TG-ETRX2PA-PM-003-106
Product Manual 1.06
ETRX2PA Product Manual (Rev 1.06)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETRX2-PA and is the answer not in the manual?

Questions and answers

Related Manuals for Telegesis ETRX2-PA

Summary of Contents for Telegesis ETRX2-PA

  • Page 1 Telegesis TG-ETRX2PA-PM-003-106 ETRX2PA Product Manual 1.06 ETRX2-PA ZIGBEE® MODULE PRODUCT MANUAL ©2009 Telegesis (UK) Ltd ETRX2PA Product Manual (Rev 1.06)

  • Page 2: Table Of Contents

    For Leaded Solder ......................23 13.2 For Lead-free Solder......................23 PRODUCT LABEL DRAWING ................... 24 RECOMMENDED FOOTPRINT ..................25 15.1 Example carrier board...................... 26 RELIABILITY TESTS ......................27 ©2009 Telegesis (UK) Ltd - 2 - ETRX2PA Product Manual (Rev 1.06)
  • Page 3 Packaging ........................30 ORDERING INFORMATION ....................31 TRADEMARKS........................32 DISCLAIMER........................32 ROHS DECLARATION....................... 32 DATA SHEET STATUS...................... 32 LIFE SUPPORT POLICY....................32 RELATED DOCUMENTS ....................33 CONTACT INFORMATION ....................33 ©2009 Telegesis (UK) Ltd - 3 - ETRX2PA Product Manual (Rev 1.06)
  • Page 4 It has been designed to be integrated into any device without the need for RF experience and expertise. The form factor of the ETRX2-PA is identical to the ETRX2, so either module can be used depending on the range requirements of the particular application.

  • Page 5: Introduction

    The configurable functionality often allows the ETRX2-PA wireless meshing module to be used without an additional host microcontroller saving even more integration time and costs. In addition to the Telegesis AT Commandset, the ETRX2-PA can be used in with custom build firmware or the Ember EZSP over UART protocol interface...

  • Page 6: Product Approvals

    (right-angle) Table 1: Approved Antennae While the applicant for a device into which the ETRX2-PA or ETRX2HR-PA (with an antenna listed in Table 1) is installed is not required to obtain a new authorization for the module, this does not preclude the possibility that some other form of authorization or testing may be required for the end product.

  • Page 7: Fcc Labelling Requirements

    2.1.1 FCC Labelling Requirements When integrating the ETRX2-PA or ETRX2HR-PA into a product if must be ensured that the FCC labelling requirements are met. This includes a clearly visible label on the outside of the finished product specifying the Telegesis FCC identifier (FCC ID: T7VEM250B) as well as the notice above.

  • Page 8: Declarations Of Conformity

    Some level of interoperability with 3rd party ZigBee PRO compliant nodes Please note that the R2xx and to some extent the Telegesis AT-Command line interpreter are based on a private application profile and use the Ember meshing and self-healing stack, so interoperability with wireless mesh networking solutions from other manufacturers is unlikely when using this default firmware.

  • Page 9: Module Pinout

    The table below gives details about the 38 module pin signals for direct SMD soldering of the ETRX2-PA to the application board. The pin numbers shown in brackets () are the related pins of the EM250. In order to use the ETRX2-PA as a plug-in solution a Harwin 1.27mm pitch connector can be fitted on the bottom of the ETRX2-PA (Harwin part number M50-3601042).
  • Page 10 NOT connected and the amplifier is working at maximum gain. Controlling the maximum output Power can also be achieved in software. {3} RTS/CTS handshaking is selectable in firmware. See the AT Command Manual. ©2009 Telegesis (UK) Ltd - 10 - ETRX2PA Product Manual (Rev 1.06)

  • Page 11: Hardware Description

    RF output pad Thirdly, the RF output can be connected to pad 2 for routing on to the underlying circuit board. There is then no ceramic antenna nor U.FL connector. ©2009 Telegesis (UK) Ltd - 11 - ETRX2PA Product Manual (Rev 1.06)

  • Page 12: Hardware Interface

    I/O. UART The AT style command interpreter can be accessed via the TXD and RXD pins. The ETRX2-PA can buffer up to 128 bytes of incoming data in a software FIFO buffer and uses XON/XOFF or hardware flow control.

  • Page 13: Firmware Description

    SPI and I2C buses are not supported by the current firmware release, but can be used with custom firmware. As a third option as opposed to using the Telegesis AT command interface or developing custom firmware, the Ember EZSP UART interface can be provided to allow ZigBee® application development using a host controller driven binary protocol.

  • Page 14: Software Interface

    ETRX2PA 6.2 Software Interface Using the default firmware the ETRX2-PA is controlled using a simple AT-style command interface and (mostly) non-volatile S-Registers. In order to get a full listing of all the available AT- Commands, please refer to the AT command dictionary document which corresponds to the firmware revision you intend to use.

  • Page 15: Absolute Maximum Ratings

    8 Operating Conditions Please Note: The firmware of the ETRX2 series and the ETRX2-PA series is identical, therefore when talking about power settings in the following chapters, the actual output power out of the on board EM250 is described, rather than the power amplified output out of the module.
  • Page 16 Please Note: The average current consumption during operation is dependent on the firmware and the network load, therefore these figures are given in the command dictionary of the respective firmware. ©2009 Telegesis (UK) Ltd - 16 - ETRX2PA Product Manual (Rev 1.06)

  • Page 17: Dc Electrical Characteristics

    (1) For more information about the internal regulated core voltage refer to part 5.7 in [2]. As the Notes: internal regulated core voltage at V mainly feeds circuitry on ETRX2-PA, the V module pin may only be slightly loaded and without feeding noise to V is not available in Power Mode 3 (see the AT Command Manual for details of power modes).

  • Page 18: D Converter Characteristics

    RF frontend filter attenuation for interferers in the range 1710- 1910MHz Relative frequency error (2x40ppm required by [1]) Relative timing error (2x40ppm required by [1]) Linear RSSI range Spurious Emissions <1GHz Spurious Emissions >1GHz ©2009 Telegesis (UK) Ltd - 18 - ETRX2PA Product Manual (Rev 1.06)
  • Page 19 Table 9. Synthesiser Characteristics Power On Reset (POR) Specifications Limit Unit POR release POR assert POR release 1.35 1.65 CORE POR hysteresis 0.08 0.12 CORE Table 10. Power On Reset Specifications ©2009 Telegesis (UK) Ltd - 19 - ETRX2PA Product Manual (Rev 1.06)

  • Page 20: Tx Power Characteristics

    Figure 4. Module Current vs. Power Setting Please Note: The power setting is the setting of the EM250’s output power (before amplification). This setting is used by all firmware running on the ETRX2-PA. ©2009 Telegesis (UK) Ltd - 20 -...

  • Page 21: Physical Dimensions

    1.27mm Distance between rows of pads 1.50mm Distance between edge of PCB and pad 2.75mm Distance between edge of PCB and pad 3.8mm Table 11. Physical Dimensions ETRX2 ©2009 Telegesis (UK) Ltd - 21 - ETRX2PA Product Manual (Rev 1.06)
  • Page 22 -PA version. If using the U.FL RF connector the “keep- out” area can be significantly reduced. NB : The module transmit/receive range will depend strongly on the antenna used and also the housing of the finished product. ©2009 Telegesis (UK) Ltd - 22 - ETRX2PA Product Manual (Rev 1.06)

  • Page 23: Soldering Temperature Time Profile (For Reflow Soldering)

    Maximum Reflow Cycles: 2 Opposite-side reflow is prohibited due to the module’s weight. (i.e. you must not place the module on the bottom / underside of your pcb and re-flow). ©2009 Telegesis (UK) Ltd - 23 - ETRX2PA Product Manual (Rev 1.06)

  • Page 24: Product Label Drawing

    [2 signs], the identifier for the hardware release [2 signs] and the production date code in the format Year-Month-Day [6 signs], separated by a semicolon. Table 12. ETRX2-PA Label Details ©2009 Telegesis (UK) Ltd - 24 -...

  • Page 25: Recommended Footprint

    You must also ensure that there are no exposed pads or vias on your layout which may contact with the pads (for the optional connector), or vias on the bottom surface of the ETRX2-PA module. If the module is to be soldered by hand for prototyping we recommend that you increase the height of the pads to allow easier access.

  • Page 26: Example Carrier Board

    Since the RF performance of the module with the on board antenna is strongly dependent on the proper location of the module on its carrier board, Figure 10 shows the reference carrier board which was used during testing by Telegesis. Figure 10: Reference Board For best performance it is recommended to locate the antenna towards the corner of the carrier board and to respect the recommended keep-out areas as described in section 12.

  • Page 27: Reliability Tests

    These products are not intended for other uses, other than under the special conditions shown below. Before using these products under such special conditions, check their ©2009 Telegesis (UK) Ltd - 27 - ETRX2PA Product Manual (Rev 1.06)

  • Page 28: Storage Conditions

    Storage (before assembly of the end product) of the modules for more than one year after the date of delivery at your company even if all the above conditions (1) to (3) have been met, should be avoided. ©2009 Telegesis (UK) Ltd - 28 - ETRX2PA Product Manual (Rev 1.06)

  • Page 29: Packaging

    Components Empty pockets Top cover NB: Empty pockets in the component packed area shall be less than two per reel and those empty pockets shall not be consecutive. ©2009 Telegesis (UK) Ltd - 29 - ETRX2PA Product Manual (Rev 1.06)

  • Page 30: Component Orientation

    Figure 2 2.0 +/-0.2 18.4 Packaging Each reel will be packed in a hermetically-sealed bag Marking : Part No. / Quantity / Lot No. and manufacturer part# with bar-code ©2009 Telegesis (UK) Ltd - 30 - ETRX2PA Product Manual (Rev 1.06)

  • Page 31: Ordering Information

    Customers’ PO’s must state the Ordering/Product Code. • There is no “blank” version of the ETRX2-PA Module available. All Modules are pre- programmed with the Telegesis AT style command interpreter based on the EmberZNet stack. (Where customers wish to add their own firmware they can erase and write it to the flash memory of the EM250).

  • Page 32: Trademarks

    Cadmium and cadmium compounds 23 Data Sheet Status Telegesis (UK) Ltd. reserves the right to change the specification without notice, in order to improve the design and supply the best possible product. Please consult the most recently issued data sheet before initiating or completing a design.

  • Page 33: Related Documents

    26 Contact Information Website: www.telegesis.com E-mail sales@telegesis.com Telegesis (UK) Limited Marlow Business Centre 84 Station Road Marlow Bucks. SL7 1NX Tel: +44 (0)1628 894347 Fax: +44 (0)1628 894333 ©2009 Telegesis (UK) Ltd - 33 - ETRX2PA Product Manual (Rev 1.06)
