- Page 1 Manual and Configuration KNXnet/IP Router Enertex ® Bayern GmbH – Ebermannstädter Straße 8 - 91301 Forchheim - Deutschland - mail@enertex.de...
-
Page 2: Table Of Contents
1147-HB-KNXnetIP-Router-en-1.odt, 2018-08-06 Seite 2 von 9 Note The contents of this document may be reproduced without prior written approval by Enertex® Bayern GmbH in any form, neither in whole nor in parts, copied, transmitted, distributed or stored. Enertex® is a registered trademark of Enertex® Bayern GmbH. Other product and company names men- tioned in this manual may be the marketing or trade names of their respective owners. -
Page 3: Notices
1147-HB-KNXnetIP-Router-en-1.odt, 2018-08-06 Seite 3 von 9 Notices Installation and assembly of electrical equipment must be performed by qualified electri- • cians. When connecting KNX/EIB interfaces skills are provided by KNX™-Training. • Ignoring the instructions may damage the device as well as causing fire or other ha- •... -
Page 4: Functional Description
1147-HB-KNXnetIP-Router-en-1.odt, 2018-08-06 Seite 4 von 9 Functional Description Five independent KNXnet/IP tunnel connections • KNXnet/IP Routing for communication between KNX lines, areas und systems via IP network • Telegram routing and filtering according to pysical address or group address • LED-signaling for KNX communication, Ethernet communication and programming mode •... -
Page 5: Routing (Knx → Ip)
1147-HB-KNXnetIP-Router-en-1.odt, 2018-08-06 Seite 5 von 9 Routing Multicast Address This address will be used for routing telegrams on IP side. The Multicast IP Address 224.0.23.12 has been reserved for this purpose (KNXnet/IP Routing). If you want to assign another address it has to be in the range between 224.0.0.0 and 239.255.255.255. -
Page 6: Routing (Ip → Knx)
1147-HB-KNXnetIP-Router-en-1.odt, 2018-08-06 Seite 6 von 9 blocked or filtered. You can parameterize the behaviour of the main groups 0 to 13 different to the behaviour of the main groups 14 to 15. If you choose „filter“, ETS will select the relevant tele- grams to route automatically. - Page 7 1147-HB-KNXnetIP-Router-en-1.odt, 2018-08-06 Seite 7 von 9 Show KNXnet/IP routing setting lcconfig IP->KNX: settings for telegrams from IP to KNX KNX->IP: settings for telegrams from KNX to IP GA 0-13: group telegrams of main groups 0 to 13 GA 14-15: group telegrams of main groups 14 to 15 Ph.
-
Page 8: Reset To Factory Defaults
1147-HB-KNXnetIP-Router-en-1.odt, 2018-08-06 Seite 8 von 9 Change tunnel address for each tunnel e.g. tunaddr 1 15.15.240 or reset tunnel tunaddr 1..5 address addresses to factory default (tunaddr reset) tunaddr reset Show tunnel addresses and connection status (without option), or show detailled information tunnel [1..5] for a specific tunnel (option 1..5) CCID: connection id of the tunnel connection... -
Page 9: Obligation For Distributors Under § 18 (1) Battery Act
1147-HB-KNXnetIP-Router-en-1.odt, 2018-08-06 Seite 9 von 9 KNXnet/IP routing Up to 48 telegrams per second KNXnet/IP tunneling Up to 35 telegrams per second, up to five tunnel connections SNTP Server, battery-buffered Obligation for distributors under § 18 (1) Battery Act Dear customer, you bought a battery operated product from us. Although the battery life is very long, it still needs to be disposed someday.
