Hafco Woodmaster PT-6 Assembly And Operating Instructions Manual

Six inch jointer with stand
Hide thumbs

Advertisement

Table of Contents

W619 PT-6
2-3-18
SIX INCH JOINTER
WITH STAND
ASSEMBLY AND OPERATING INSTRUCTIONS

Advertisement

Table of Contents
loading

Related Manuals for Hafco Woodmaster PT-6

Summary of Contents for Hafco Woodmaster PT-6

  • Page 1 W619 PT-6 2-3-18 SIX INCH JOINTER WITH STAND ASSEMBLY AND OPERATING INSTRUCTIONS...

  • Page 2: Specifications

    Specifications ITEM DESCRIPTION Motor 240VAC,HZ,single phase;1 HP；50HZ/2850 Cutter Head 2-1/4 inch diameter;3 cutting knives;50HZ/4600 Table Size 46-1/2(L)x 7-5/8 (W) inches Tilt:90 to 45 degrees Fence Size：3-7／8(H)X 27-3／4(L)inches Overall Size 26-1/2(L)X 46-1/2 (W)X 38-1/4(H)inches Cutting Depth Up 8mm Rabbit Cut Depth Up 8mm M-2 High speed steel;...
  • Page 3 6.Use the right tool for the job．Do not attempt to force a small tool or attachment to do the work of a larger industrial tool. There are certain applications for which this tool was designed. Do not modify this tool and do not use this tool for a purpose for which it was not intended. 7.Dresss properly．Do not wear loose clothing or jewelry as they can be caught in moving parts．Protective．electrically non—conductive...
  • Page 4 19.Do not operate tool if under the influence of alcohol or drugs．Read warning labels on prescriptions to determine if your judgment or reflexes are impaired while taking drugs．If there is any doubt ,do not operate the tool． 20．Use proper size and type extension cord. If an extension cord is required. it must be of the proper size and type to supply the correct current to the tool without heating up.
  • Page 5 13. Maintain control of the workpiece at all times. Never allow it to rest on the moving cutting blade without holding on to it with the push paddles.It could fly backward at high speed and force, and cause serious injury. 14.
  • Page 6 Page 6...
  • Page 7 Fitting Motor # Carefully put stand on its side as shown support each end so stand sits on its corner This will make it easier to fit heavy motor. # Fit motor using 4 spacers supplied under motor feet, 4 x M8 x 45mm long Socket head cap screws flat washers lock washers and nuts supplied as shown Nip bolts up ,do not tighten yet.
  • Page 8 Caution Sharp blades are fitted to the spindle of this machine and remain exposed until the blade cover is fitted further in the assembly instructions. Great care must be taken Because of sharp edges Fitting machine to stand # Lift the main planner body onto the stand With the infeed table to the right as shown) Screw 3 x long studs up under the stand with a washer and tighten.
  • Page 9 Setting Vee belt and guarding # Using a straight edge or by sighting up from the top, line up the spindle and Motor pulley by sliding both or either along their shafts. Using a straight edge to line up pulleys Motor pulley fitted with hub out! When this is done ensure both grub...
  • Page 10 Fitting Fence assembly # Caution of sharp blades## Using 2 x M10 x 35 long socket head cap screws, washers and lock washers. Fit the rear fence sup assembly to the rear of the machine. Slide top section all the way back.
  • Page 11 Slide the fence assemble forward towards the rebate edge of the out feed table. Fence can be adjusted to be parallel to the rebate edge by removing the fence of the frame and screwing in or out one of the attachment pins in the fence then reassembling and checking again as needed Screw in or out one...
  • Page 12 Adjusting and setting fence at 130 degrees Swing the 90 degree stop out of the way. Tilt the fence all the way back Using 2 Squares, one with a 45 degree angle or a compound set square, Adjust the 130 degree stop bolt to get fence to 130 degrees, when set lock the bolt with the lock nut .
  • Page 13 Fitting lower dust chute M5 x 10mm hex head bolt Fit the lower dust chute plate and extraction port The plate has 2 tabs these sit in the top side slots of the dust chute and then slide plate up. Fit the plastic extraction cute over the bottom and secure both with the 2off M5 x 10 hex head bolts supplied Table adjustment...

  • Page 14: Operation

    Setting the Outfeed Table to the Cutterhead Knives Caution: During this procedure, remove power to the machine. Cutterhead Blades are very sharp. Use caution. Number the blades (1, 2, and 3) with a magic marker. Rotate the Cutterhead by turning the Pulley (2A) until blade number 1 is at the 12 o'clock position.

  • Page 15: Rabbet Cut

    Jointing Cut Jointing cuts or edge jointing are made to square the edge of a workpiece. The workpiece is positioned on the Jointer with its narrow edge on the lnfeed Table and the major flat surface against the Fence. For planing cuts, the major surface of the workpiece is placed on the lnfeed Table with the narrow edge against the Fence.
  • Page 16 P1ocedure Unplug Power Cord from electrical outlet. Set tl1e depth of cut by adiusting the lnfeed Table height. ,> 1\dJust tlln Fence to the desired angle and distance . Pass tl1e workpiece over lnfeed Table to the blade and verify the desired depth and re, ice location.
  • Page 17 T ighten each set screw 1 /4 turn starting at the bottom and working up through all the screws. If play still exists, repeat steps. T ighten Loe� Screws (35) and lock nuts. Removing and Replacing Knives Caution: All knife lock bolts must be firmly tightened or you risk ejection of the knife(s) and lock bar from the Cutterhead.
  • Page 18 TABLE LIST ITEM DESCRIPTION Q'TY ITEM DESCRIPTION Q'TY OUTFEED TABLE HEX BOIT M8x25 BRACKET FLAT WASHER ￠8 LINK BASE SPECIAL BOLT FLAT WASHER ￠10 BLOCK BLOCK COLLAR HEX NUT M12 SCREW SHATE CAP SCREW M6x12 SET SCREW M6x8 LEVER ROD HANDWHEEL HANDLE FLAT WASHER 6...
  • Page 19 Page 19...
  • Page 20 Cutterhead Parts List ITEM DESCRIPTION CUTTERHEAD STUD M10-1.5*105 FLAT WASHER 10 LOCK WASHER 10 HEX NUT M10*1.5 BEARING BLOCK LEFT BALL BEARING 6202ZZ HEX BOIT M6-1*10 KNIVES(SET OF3) FIAT HEAD SCREW M5-0.8*10 KEY5*5*30 BEARING BLOCK RIGHT SET SCREW M6-1*10 PULLEY BALL BEARING 6203ZZ KNIFE JIG FOOT E-CLIP 9...
  • Page 21 STAND LIST DESCRIPTION DESCRIPTION DUST OUTLET RUB COLLAR COVER UPPER PEAR BRACE WNG SCREW UPPER SIDE BRACE HEX BOIT M8*45 FLAT WASHER10 FLAT WASHER SPECIAL STUD DUST CHUTE CARRIAGE BOIT SHORT BRACE KEY5*5*25 UPPER FRONT BRACE BELT COVER LONG BRACE MOTOR PULLEY FOOT HEX NUT M5...
  • Page 22 Page 22...

  • Page 23: Fence Diagram And Part List

    FENCE DIAGRAM AND PART LIST 222 221 ITEM DESCRIPTION ITEM DESCRIPTION 201 FENCE 221 STOP TAB 202 PIVOT STUD 222 SPECIAL BOLT 203 FLAT WASHER 10 223 FENCE HINGE 204 NUT M10 224 SPECIAL CAP SCREW 205 SPECIAL SCREW M10*45 225 FENCE STOP BRACKET 206 FLAT WASHER 8 226 FENCE BRACKET...

  • Page 24: Electrical Schematic

    Electrical Schematic CAPACITOR 300 mF • 125 VAC YELLOW BLACK WHITE GREEN GROUND BLACK BLACK GREEN GROUND Page 24...
