INSECT-O-CUTOR Halo Aqua Instructions

Professional Glueboard Insect Control
Please read these instructions carefully and store in a safe place for
future reference.
HALO
Insect-O-Cutor
As part of the
a versatile professional flykiller which utilises highly effective UV tubes and
is designed for use with a high specification glupac
available as a 15, 30 or 45W model which can be wall or desk mounted,
and a 2x30w model for ceiling suspension. Halo
model, which is designed for use areas which require hosing down.
CONTENTS OF PACKAGE
- 1 x Halo Aqua flykiller
- 1x Glupac ® pheromone impregnated glueboard
- 1 x Removable aluminium debris tray
- 2 x High powered shatterproof UV tubes
- 4 x Screws and wall plugs
- 2 x Vertical mount glueboard retaining pins
- 1 x Servicing key fob and mains cable tidy tie wrap wire
WARNING - THIS APPLIANCE MUST BE EARTHED (CLASS 1)
INSECT CONTROL PRODUCTS
Halo Aqua utilises high powered ultra violet tubes to attract flying insects
and retains the caught insects on a pheromone impregnated glueboard
for inspection or hygienic disposal.
WARNING
Halo Aqua is IP45 rated and is designed for use in applications
appropriate to this ingress protection rating.
Halo Aqua is not to be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction.
Children should be supervised to ensure they do not play with the
appliance.
Halo Aqua is not suitable for applications where potentially explosive
environments may exist.
POSITIONING AND GUIDANCE FOR USING HALO
THIS UNIT IS FOR INDOOR USE ONLY.
Halo Aqua should ideally be fixed around two meters above the ground,
preferably in the darkest place within the area to be protected. ENSURE
THERE IS A MINIMUM OF 550mm BETWEEN ONE SIDE OF HALO AND THE
ADJACENT SURFACE, TO PROVIDE ENOUGH SPACE TO INSERT THE
GLUEBOARD (SEE MOUNTING INSTRUCTIONS.) Do not position the unit
close to windows, skylights or other sources of light, or where it may be
obscured by furniture, doors or other obstacles. Ideally, Halo Aqua
should be visible from every part of the area to be protected.
Halo Aqua should ideally be in operation for 24 hours a day, ensuring
your premises are kept free of flying insects. Insects are most attracted
to Halo Aqua at night when there is no competition from daylight or
other light sources.
*Excludes tubes, glueboards and starters. Does not cover breakdown due to misuse, incorrect
operation or use in an incorrect application.
® brand of insect control products, Halo is
® glueboard. Halo is
Aqua is a 45w IP45 rated
GUARANTEE
Halo Aqua has a three year guarantee and if maintained as
recommended in these instructions should continue to work for many
years.* Use of non-approved consumables may invalidate the
guarantee. Ensure genuine glupac
with this product.
INSTALLATION
INSTALLATION SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY.
For wall mounting, use the supplied wall mounting plugs and screws,
making sure correct wall plugs are used for specialist mounting materials,
such as plasterboard.
Wall Mounting - Halo Aqua can be wall mounted horizontally or
vertically. For horizontal mounting, use the two cut outs on the debris
tray to mark the correct wall mounting points. For vertical wall
mounting, insert the two large plastic glueboard retaining pins in the two
holes on the glueboard runners, to stop the glueboard falling out of the
unit. (Supplied in the fixing kit)
Wall Mounting
Once Halo Aqua is installed in position, fit the glupac
place as described in the glueboard replacement section of this
document. Halo Aqua should be hardwired into an appropriate power
supply (as indicated on the specification label) by a qualified
electrician. Use the supplied black mains cable tidy tie wrap wire to
hide any excess mains cable behind the product if required.
To maximise the effectiveness of Halo Aqua in catching flying insects,
the top of moulding has light apertures to increase the UV irradiance
emitted from the product. However, if required, these apertures can be
covered to protect the glueboard from debris and prolong its life, by
simply sliding the reflective aluminium cover forward.
Light Apertures &
Cable Management
CLEANING
CLEANING SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY,
AFTER ENSURING THAT THE UNIT IS DISCONNECTED FROM THE MAINS
SUPPLY.
It is recommended that cleaning is carried out regularly when the
glueboard is replaced. Once the glueboard is removed, the unit should
be thoroughly wiped down with a damp cloth, removing any build up of
dirt. Ensure the unit is completely dry before reconnecting it to the
power supply.
® glueboards are used in conjunction
® glueboard in
Halo Aqua
