- Page 1 Quick Start Guide tantra-2400 Smart Cloud Managed Mesh Wi-Fi Router Agami Creations Pvt Ltd. www.agami.io...
-
Page 2: Package Contents
Introduction Thank you for purchasing tantra-2400 unit. This is a cloud managed whole home Wi-Fi solution that works with your existing internet connection to provide secure and fast internet connectivity to Wi-Fi enabled devices in your entire home. Package Contents 1. -
Page 3: Getting Started
Getting Started To get started, follow the below steps: 1. Open the package and place the tantra-2400 access point (AP) and it’s package contents on a clean and flat surface 2. Verify that the power connection is available for your tantra-... -
Page 4: Hardware Installation
The following table lists the connections available in tantra-2400 AP. USB Port Eth2/LAN 10/100/1000BASE-T Gigabit Ethernet port Eth1/WAN/Po 10/100/1000BASE-T Gigabit Ethernet port with 802.3af-compliant Power over Ethernet (PoE) support Reset Reset button to restore the AP to its original factory default settings... - Page 5 (a) Mounting on the wall (b) Mounting on a ceiling T-bar. 1. Use the included screws to attach two ceiling-mount T-bar clips to the back of the AP. 2. Push the AP onto the ceiling T-bar until it clicks securely in place. Note: The ceiling mounting clips are for two different sizes of ceiling T-bars.
- Page 6 (b) Mounting on a ceiling T-bar Connect the cables and power adapters. (a) Connect Ethernet cables. 1. Connect Category 5e or better cable to the Eth1/WAN/PoE 1000BASE-T RJ- 45 port. When connected to a PoE source, the Eth1/WAN/PoE port connection provides power to the unit.
- Page 7 (a) Connect Ethernet Cables (b) Connect AC power adapter 2. (Optional) Connect a local LAN switch or computer to the Eth2/LAN 1000BASE-T RJ-45 port. (b) Connect AC power adapter. 1. Connect the AC power adapter to the DC power jack on the AP and then plug the adapter into a nearby AC power source.
- Page 8 Check AP LEDs Check AP LEDs. The following table lists the LEDs available in tantra-2400 AP. Power LED A solid orange light indicates that the device is synchronized with the cloud server 2G-WiFi/5G-WiFi A solid green light indicates that the 2.4GHz/5.0GHz wireless radio is enabled Eth1/WAN/PoE &...
-
Page 9: Network Topology
Network Topology The following figure shows a graphical representation of tantra-2400 AP deployment and management. Note: Eth1 represents WAN connection and Eth2 represents LAN connection. - Page 10 To setup tantra 2400 follow the on-screen instructions and for detailed step-by-step instructions refer the tantra 2400 User Guide available at https://agami.io/support/ Accessing Cloud Configuration Portal The Cloud configuration portal allow you to manage your wireless network and view network statistics on your desktop/laptop.
-
Page 11: Mobile App Installation
Mobile App Installation Download the tantraWiFi Mobile App, available from the App Store® (iOS) or Google Play™ Store (Android). It provides ability to configure tantra 2400 APs and access the extensive visibility for the health and performance of your network. It also offers quality indicators and recommended resolutions to discovered issues. - Page 12 Radio Frequencies: 2.4 – 2.4835 GHz (US, Canada, ETSI) 5.15 – 5.25 GHz (lower band) US/Canada, Europe 5.725 – 5.825 GHz (upper band) US/Canada Power Specifications PoE Input Power: 44–55 VDC, 0.63–0.3 A, 802.3af/at-Compliant DC Input Power: 12 VDC, 1A Power Consumption PoE Input: PoE 44–55 VDC, 11 W max...
-
Page 13: Service / Warranty
Service Warranty In order to protect your rights and interests, please read the Warranty Policy carefully. The Warranty Policy is available at: https://agami.io/ This Limited Warranty applies to tantra APs purchased from Agami Creations Pvt Ltd. Safety Information Only use power adapter provided in the box. - Page 14 On improper use of the tantra unit, we cannot guarantee that no accidents or damage will occur. Please use this product with utmost care and operate at your own risk. Support For answers to frequently asked questions (FAQs) and technical support, please navigate to: https://agami.io/support/...
- Page 15 Agami Creations Pvt. Ltd. Flat No.12, 1st Floor, Sunder Sri Apts, New No.20, Old No. 38/39, Ramanujam ST, Chennai 600 017 ©Agami Creations Pvt. Ltd., tantra are trademarks of Agami Creations Pvt. Ltd. Non-Agami trademarks are used only for reference purpose.
