DESCRIPTION
The BLPS, TS350 and TS752 Series of pressure and temperature sensors are designed for
use with the PPC4000 Fuel Air Ratio Controller and BurnerLogix Burner Management
System with Integrated Boiler Control.
The pressure sensors (P/N BLPS-x) utilize a solid state pressure transducer to indicate
steam pressure. The temperature sensors (P/N TS350-x and TS752-x) utilize a platinum,
positive temperature coefficient sensing element to provide indication of water tempera-
ture, stack temperature, boiler water temperature of a steam boiler, and outdoor air temper-
ature. The pressure sensors have a maximum overpressure specification of 200% Full Scale
Output and 800% Burst. The pressure sensors are equipped with a 1/4" NPT male fitting.
The Immersion Style Temperature Sensors have a 1/2" NPT mounting for the 2", 4" and 8"
thermowell probe.
The pressure and temperature sensors provide a 4-20 mA control signal over their respec-
tive stated ranges to the PPC4000 and BurnerLogix Control systems. No setting or calibra-
tion is required for either type of sensor.
The PPC4000 and BurnerLogix Control systems perform continuous safety checks on the
operation of all pressure and temperature sensors to insure their safe and proper operation
(e.g. under range, over range, open wiring, etc.).
WARNING: The PPC4000 Fuel Air ratio Controller and BurnerLogix Control
System must only be used with the approved pressure and temperature sensors.
(e.g.: BLPS-15, TS350-4, etc.). Do not use with any other types of pressure or tem-
perature sensors. UL approval requires these sensors.
