- Page 1 AIR SOURCE HEAT PUMP WATER HEATER Installation & Instruction Manual English Version...
-
Page 2: Table Of Contents
Water heater Contents CONTENTS Ⅰ .To our customers(before installation) -------------------------------------------------1 Ⅱ .Product Introducing -----------------------------------------------------------------------2 Ⅲ.Work principle ------------------------------------------------------------------------------3 Ⅳ.Performance Data --------------------------------------------------------------------------3 Ⅴ .Dimension ------------------------------------------------------------------------------------4 Ⅵ.Operation introductions ------------------------------------------------------------------5 Ⅶ . Electric Circuit Wiring Diagram -----------------------------------------------17 Ⅷ . Installation instructions ------------- ---------------------------------------------------18 Ⅸ. Maintenance ----------------- ---------------------------------------------------------------21... -
Page 3: Ⅰ .To Our Customers(Before Installation)
Water heater Ⅰ.To our customers Dear Sir: In order to use this machine safely, please read this INTRUCTION MANUAL carefully before using and installation. Heat pump water heater is a professional machine, it may cause damage or hazard when wrong installed, it should be installed by a competent person in accordance with the relevant standards for the country of use. -
Page 4: Ⅱ .Product Introducing
Water heater Ⅱ.Product Introduction Product Introduction Safe and Reliable Unlike traditional electric water heater, heat pump water heater do not directly generate heat by electricity , it use less electricity to move heat from one place to another , electric circuit is separated from water circuit ,which is also not easy for electric shock, inflammable , explosion and poisoning ! Safer and more reliable! Highly efficient &... -
Page 5: Ⅲ.work Principle
Heat energy energy pass to water Water inlet Expansion valve Liquid tank Dry filter Water heater Ⅳ.Performance Data Performance Data Model SWBC-3.0H-A/P Rated heating capacity(w) 3000 Power supply(V/Ph/Hz) 220/1/50 Input power(kw) 0.81 Running current(A) Circulating unit hot water generated(L/h) ℃... -
Page 6: Ⅴ.dimension
Water heater Ⅴ.Dimension The dimension for air source heat pump water heater... -
Page 7: Ⅵ.operation Introductions
Water heater Ⅵ.Operation introduction Operation introduction 1. Controller introduction defrosting Heating mode Data showing area Clock Timer on Timer off Timer on/ off sign ON/OFF MODE TIMER UP/DOWN 2 Wire controller button definition button ---to turn on or turn off your heat pump. Long press 10 seconds for factory default setting. - Page 8 Water heater Ⅵ.Operation introduction 3 Wire Controller Operation In the state of OFF, LCD display clock and working mode only. see P1 When Press “power” button, heat pump turn on, and LCD display as below. Parameter data setting You could check and change the setting from any status as below steps. 1.Press up/ down button for the parameter you want to change setting.
- Page 9 Water heater Ⅵ.Operation introduction Real Time Clock Setting In the default state，press " " once to enter Real Time Clock Setting State; In the state of Real Time Clock Setting, press" " once again，hour numbers flash, press " "or " "，can adjust the hour for the clock.
- Page 10 Water heater Ⅵ.Operation introduction Operation introduction 3. Parameters Parameters Remark Definition Range Default 0:protect on Ambient temperature too low protection Can adjust SET 0 parameter 1:protect off SET 1 Tank water temperature setting Can adjust 25-60℃ 50℃ 30-90Min Defrosting Cycle 40Min Can adjust SET 2...
- Page 11 Water heater Ⅵ.Operation introduction Operation introduction 4 Failure code and parameter tables Long-distance Protect/Failure Remark controller Heat ump in Stand-by mode Normal running Inlet water temperature sensor failure Outlet water temperature sensor failure Coil temperature sensor 1 failure Gas suction side temperature sensor 1 failure Ambient temperature sensor failure Coil temperature sensor 2 failure Winter anti-freezing protection I...
- Page 12 Water heater Ⅵ.Operation introduction 5) Two ways to connect wifi a. First way For Android System Install the APP of “SmartLink3 Demo” ◎ ◎ Turn on the heat pump, and make sure the area of heat pump installed cover with wifi signal. What's more, make sure your smart phone with wifi connected.
- Page 13 Water heater Ⅵ.Operation introduction a. First way It may take 1 minute to match all wifi setting. ◎ If connected successful, it could show “SmartLink Compelted” as below pic. If failed, it could show “time out”as below pic, then you have to repeat step 3 & 4 again. ◎...
- Page 14 Water heater Ⅵ.Operation introduction a. First way For IOS System Find out “SmartLink” in the APP Store, download and install it. ◎ You can scan below QR code for fast installation as well. ◎ Input the passwords of your local wifi. ◎...
- Page 15 Water heater Ⅵ.Operation introduction b. Second way for wifi setting Turn on the heat pump. ◎ Use laptop or smart phone to find wifi “HF-LPB100”and connect it. ◎ Open website of “10.10.100.254”, input user name and password as below. ◎ User name: admin Password: admin After that, you could find below interface.
- Page 16 Water heater Ⅵ.Operation introduction b. Second way for wifi setting Then select STA setting, press Scan, then press Save. See below refer pic. ◎ ◎ Please choose the safety and reliable local area network which available. Then press OK to Confirm.
- Page 17 Water heater Ⅵ.Operation introduction b. Second way for wifi setting Make sure the Encryption Method choose WPA2PSK, and Encryption Algorithm choose AES. ◎ Input the password of your local area network. Then press Save. After finished all above steps, come to Restart interface, and press OK to confirm ◎...
- Page 18 Water heater Ⅵ.Operation introduction c. Remarks ◎ Make sure to press “SAVE” for each setting. If IP address changed, all above setting need to re-set. ◎ If you try first way of “Smartlink3 DOMO” and failed, ◎ then try the second way for wifi setting. Have to long press Turn on/off button (see below pic) for 10 seconds, otherwise, wifi signal will never come out.
-
Page 19: Ⅶ.electric Circuit Wiring Diagram
Water heater Ⅵ.Operation introduction 6 Setting about S1 & S2 switch S1 Switch---Second Set Point S2 Switch----Long distance demand 6.1 Second Set Point available when S1 switch has well connected. At the same time, water temp set point setting decided by ambient temp, Parameter SET 9 and Parameter SET A. -
Page 20: Ⅷ.installation Instructions
Water heater Ⅷ.Installation instructions Installation instructions 1. Unit installation 1).Installation location Host unit 1 Should be installed in a larger & well-ventilated place. 1 Installation location should ensure unhindered access outlet (inlet & outlet shown as below). 1 Install gutter or set up positions near the outfall, to facilitate the drainage. 1 The installation base or bracket should be steady, to ensure the smooth operation of running units. - Page 21 Water heater Ⅷ.Installation instructions Installation instructions 2. Pipeline connecting Installation notes: 1 Water drain pipes, overflow pipes should be installed next to the drainage inlets to facilitate drainage, vent valve should be installed on vent pipes. 1 Repair valve should be installed in front of the electromagnetic valve on the pipeline system, which is convenient for future repair.
- Page 22 Water heater Ⅷ.Installation instructions Running Test and operation 1. Preparatory work before the running test. a) Inspection of heat pump water heater units: 1 Check if the unit appearance and the pipeline system were damaged during transport. 1 Check if there is air exist in the water pipes, if yes, should empty all the air inside by the manual exhaust valve and the exhaust valve on the water pumps.
-
Page 23: Ⅸ.maintenance
Water heater Ⅸ.Maintenance Maintenance Heat pump water heater is a high automatic equipment, please perform regular inspection termly. If the unit can be long-term and efficiently maintenance, the operating reliability and service life will have an unexpected increase. 1.The extra water filters should be cleaned regularly to ensure clean water quality of the system, and to avoid damage caused by dirty water filter blocking. - Page 24 Air Source Heat Pump-Water Heater...
