8. Specifications

Interfaces
Parameters
Modem/Telephone
Serial CONFIG
Cellular Antenna
GPS Antenna
Power Input
Features
Parameters
SLIC
Voice
Cellular Connection
SIM Card
Push Buttons
LEDs
Dimensions (L x W x D)
Weight
Mounting
Environmental
Parameters
Operating Temperature
(Note: Operating temperature may be further limited by specific Plug-In Terminus terminal)
Relative Humidity
Description
RJ11 connector (FXS)
USB Mini -- user terminal interface for configuration and firmware upload.
SMA; 3.3 V LNA bias voltage output.
50 ohm SMA w/ 2.85V bias (on TAGFNG models only)
7-15 Vdc; 22W with two input alternatives:
-- 6mm DC power jack with 2mm center pin positive
-- 5.08mm (0.200") terminal block header (accepts screw clamp
and crimp connector type terminal blocks)
Description
Performs all BORSCHT functions:
Battery supply to subscriber line
Overvoltage protection
Ringing current supply
Supervision of subscriber terminal
Coder and decoder
Hybrid, 2 wire to 4 wire conversion
Testing
DTMF encoding and decoding
REN=5 at 100 ft. (30m)
VoLTE (4G) and Voice over cellular (3G fallback)
4G (LTE) bands 2, 4, 5, 12, 13, 14, 66 and 71. Plus 3G (fallback) bands 2, 4 and 5.
Micro (3FF size) SIM Card
MODE, RESET
Power, Status, Cellular Link, GPS and Signal Strength
6.0 in (152mm) x 5.2 in (132mm) x 1.2 in (30mm)
13 oz (365 g)
Integrated mounting brackets
Description
-40° C to +60° C (-40° F to 140° F)
5% to 95% (non-condensing)
LTE910PS v1.00 User Manual JA16-UM
© Copyright 2019 Janus Remote Communications
All Rights Reserved See website for latest revision.
Page 15 Rev: 00 Date: 07/24/19
Specifications subject to change without notice
Not intended for life support applications.
