Installation Requirements

TOOLS AND PARTS
Gather the required tools and parts before starting installation.
TOOLS NEEDED
• Flat-blade Screwdriver
• Phillips Screwdriver
PARTS SUPPLIED
2 for top window
brackets
1 for security bracket
4 for main
window panel
49-5000135
Main Window
Panel
Pointed Screws (7)
Top Window
Bracket (2)
Window
Bracket (2)
Use for Vinyl
Windows
Use for Vinyl
Windows
Top Foam
Seal
(10 mm x 10
mm x 102 cm
Extension
Panels (2)
Exhaust Hose
Exhaust
Nozzle
Bottom Security
Bracket
Stuffer Seal
Bottom
Strip (15 mm x 33
Foam Seal
mm x 1200 mm)
(3 mm x 10
mm x 102 cm
Flat Screws (6)
4 for extension
panels
2 for nozzles
7
