M300 Smart Secure
Operating instructions
Content
Page
General system description ............................................................................... 2
Safety precautions, care and maintenance, technical specifications .................. 3
System components / Package contents, dimensions ........................................ 4
Getting started / Installation, Changing Batteries ................................................ 5
Check for correct working order .......................................................................... 6
Information about installation, Dismantling the M300 ......................................... 7
Light signals and other signals ............................................................................ 8
Explanation of icons and functions ................................................................ 9-10
Programming of furniture locks .................................................................... 11-14
Opening and closing of furniture locks .............................................................. 15
Further operating instructions can be found on our internet page as a download.
Advertisement
Table of Contents
Related Manuals for LEHMANN M300
Summary of Contents for LEHMANN M300
-
Page 1: Table Of Contents
System components / Package contents, dimensions ........4 Getting started / Installation, Changing Batteries ..........5 Check for correct working order ................6 Information about installation, Dismantling the M300 ......... 7 Light signals and other signals ................8 Explanation of icons and functions ..............9-10 Programming of furniture locks .............. -
Page 2: General System Description
GENERAL SYSTEM DESCRIPTION The electronic lock M300 Smart Secure can be opened and closed with a smartphone/tablet and an app using the latest Bluetooth low energy technology. It is designed for use inside buildings and is not suitable for wet rooms. You can operate the lock with its basic functions with the free Basis App. Depending on requirements, additional functions can be uploaded subject to a charge. -
Page 3: Safety Precautions, Care And Maintenance, Technical Specifications
SAFETY PRECAUTIONS When replacing the batteries, observe correct battery polarity and position! Dispose of used batteries properly! Do not heat batteries, take them apart or short-circuit them! Never throw batteries into open fire! The batteries must not be charged! Keep the batteries away from children! Any persons swallowing batteries must seek immediate medical advice! Damaged and/or leaking batteries may cause acid burns and/or poisoning! CARE AND MAINTENANCE... -
Page 4: System Components / Package Contents, Dimensions
System components / Package contents, dimensions ........4 Getting started / Installation, Changing Batteries ..........5 Check for correct working order ................6 Information about installation, Dismantling the M300 ......... 7 Light signals and other signals ................8 Explanation of icons and functions ..............9-10 Programming of furniture locks .............. -
Page 5: Getting Started / Installation, Changing Batteries
GETTING STARTED / INSTALLATION The motor unit, electronics and optical unit are not connected on delivery. Please perform steps 1 to 3 (see below) one after the other to get a functional unit. Once the functional check was successful, disconnect the display unit from the system again (figure 2), so that the system can be properly installed in the furni- ture. -
Page 6: Check For Correct Working Order
CHECK FOR CORRECT WORKING ORDER Check open and close function before installing. Press Bolt Open button retracts Optical display LED colour: GREEN Pause approx. 1 sec. Press Bolt Close button extends Optical display LED colour: Pause approx. 1 sec. A detailed overview of all optical signals can be found on page 8. -
Page 7: Information About Installation, Dismantling The M300
INFORMATION ABOUT INSTALLATION This M300 is a motor lock with 3-point locking. This means that three bolts will extend from the housing at the same time. Push rods are usually attached to the two lateral lock bolts. This enables a unit to be locked at 3 different points for greater security. -
Page 8: Light Signals And Other Signals
(emergency power supply). DOWNLOAD THE APP Please search in the Apple App Store or in Google Play Store for LEHMANN Smart Secure. Please consider the recommendations for mobile devices that have been tested on www.lehmann-locks.com. -
Page 9: Explanation Of Icons And Functions
Groups Under this menu item you can manage the grouping of locks. Help Quick guide and help topics. Online documentation: www.lehmann-locks.com Legal Notice Manufacturer specifications, licensing information. Functions Under this menu item you can enable additional functions that... - Page 10 EXPLANATION OF ICONS AND FUNCTIONS Customised name of the selected furniture lock. Shows which group this lock is assigned to. Shows the last known locking status. locked, open. Indicates the operating mode. Here you can switch the locking type for the selected lock from manual (locking process only on command) to automatic locking following a lost connection.
-
Page 11: Programming Of Furniture Locks
PROGRAMMING OF FURNITURE LOCKS Display / Menu Description Action Select the Smart Secure App to start the program. The “Help page” is displayed the first time you start and when the list of locks is empty. Select the “Menu” icon. Select the item “New Lock”... - Page 12 PROGRAMMING OF FURNITURE LOCKS Display / Menu Description Action Briefly press the programming stick for the lock you want to pair. “Learn” button. The selected lock is displayed as “bondable” after a short period of time. Use the “add” function. If the lock is paired for the first time, a “pairing request”...
- Page 13 PROGRAMMING OF FURNITURE LOCKS Display / Menu Description Action The following screen is shown automatically. Give the lock a unique name of your choice and then confirm with the “Add” button. The connection is established in the background. Once the name has been assigned, the lock is displayed as a known lock.
- Page 14 PROGRAMMING OF FURNITURE LOCKS Display / Menu Description Action Select the following option from the menu: “Visible Locks”. Shows all known locks in signal range as well as currently connecting locks and locks which are successfully connected to your smartphone / tablet You can now open and close the locks.
-
Page 15: Opening And Closing Of Furniture Locks
OPENING AND CLOSING OF FURNITURE LOCKS Display / Menu Description Action Switch to the display: “Visible Locks”. The locking status of the locks is shown. You can change the locking status by tapping on the lock icon of the respective lock. - Page 16 LEHMANN Vertriebsgesellschaft mbH & Co. KG Postfach 26 20 • D-32383 Minden Fon +49 571 / 50 599-0 • Fax +49 571 / 50 599-822 info@lehmann-locks.com • www.lehmann-locks.com DIN EN ISO 9001:2008 certified...
