Rule 403C Instruction Manual

Tournament Series
Livewell/Baitwell Pumps
Description
Powerful and long lasting, Rule Tournament Series Cartridge
Pumps offer outstanding performance as well as the versatility of
replacing the motor cartridge if the motor expires. The cartridge
feature also allows complete access to the impeller for easy
cleaning and maintenance. Replacing the motor cartridge only
allows the fittings and hose to remain totally intact.
To Change Motor Cartridge
1. Block off the thru-hull before removing the motor cartridge
2. Disconnect wiring
3. Press cartridge button, twist counterclockwise and pull
motor cartridge straight up
4. Reconnect wire to new motor cartridge
5. Align the arrows and press the new motor cartridge down
firmly. Twist motor housing clockwise until cartridge locks
in place
c
b
Models
Model # Description
401 C 500 GPH Livewell Pump with Angled Pickup Tube
403 C 800 GPH Livewell Pump with Angled Pickup Tube
405 C 1000 GPH Livewell Pump with Angled Pickup Tube
401STC 500 GPH Livewell Pump with Straight Pickup Tube
403STC 800 GPH Livewell Pump with Straight Pickup Tube
405STC 1100 GPH Livewell Pump with Straight Pickup Tube
401 FC 500 GPH Livewell Pump with 1" Straight Pickup Tube
403 FC 800 GPH Livewell Pump with 1" Straight Pickup Tube
405 FC 1100 GPH Livewell Pump with 1" Straight Pickup Tube
Replacement Motors
45DR 500 GPH Replacement Motor
46DR 800 GPH Replacement Motor
47DR 1000 GPH Replacement Motor
To remove motor cartridge:
a. Press Cartridge
Release Button
b. Twist Cartridge
a
Counterclockwise
c. Pull Cartridge
Straight Up
Models 401C, 403C, 405C, 401STC,
403STC, 405STC, 401FC, 403FC, 405FC
Replacement motors 45DR, 46DR,47DR
Dimensions
in inches (mm)
Models
2.76 (70)
401 FC
403 FC
405 FC
2.76
(70)
D
C
C
E
A
E
Model A B
401C 4.0 (102) 5.87 (149)
403C 4.0 (102) 5.87 (149)
405C 4.0 (102) 5.87 (149)
401STC 4.33 (110) 5.84 (148)
403STC 4.33 (110) 5.84 (148)
405STC 4.33 (110) 5.84 (148)
401FC 5.87 (149)
403FC 5.87 (149)
405FC 5.87 (149)
WARNING
water. Use with any other medium, including
particularly hazardous,
substance, could result in damage to the pump, the
surrounding environment and injury to persons or
property, including possible exposure to hazardous
substances. This pump is for water applications only.
Required
Fuse Size (A)
2.5
5
6
2.5
5
6
2.5
5
6
2.5
5
6
Instruction Guide
Models Models
401 C 401 STC
403 C 403 STC
405 C 405 STC
2.76 (70)
C
B
D
E
C D
3/4-14NPSM 1/2-14NPT 3/4-14NPSM
3/4-14NPSM 1/2-14NPT 3/4-14NPSM
1-11.5NPSM 1/2-14NPT 3/4-14NPSM
3/4-14NPSM 1/2-14NPT 3/4-14NPSM
3/4-14NPSM 1/2-14NPT 3/4-14NPSM
1-11.5NPSM 1/2-14NPT 3/4-14NPSM
3/4-14NPSM 1/2-14NPT 3/4-14NPT
3/4-14NPSM 1/2-14NPT 3/4-14NPT
1-11.5NPSM 1/2-14NPT 3/4-14NPT
This pump is designed for
use with fresh and salt
caustic or corrosive
GPH at GPH at
Open Flow 3.35 ft.
500
800
1000
500
800
1100
500
800
1100
500
800
1100
2.76
(70)
B
D
A
E
340
490
710
340
490
790
340
490
790
340
490
790
