- Page 1 Standard Bilge Pump INSTRUCTION MANUAL...
- Page 2 This pump is designed for use with fresh wa- WARNING ter and salt water ONLY. Use with any other hazardous, caustic, or corrosive material could result in damage to the pump and the surrounding environment, possible exposure to hazardous substances and injury.
- Page 3 STOP...
- Page 4 CE Logo When this product carries a CE mark, it conforms to one or more of the following standards: EN 61000-6-1:2001 EN 61000-6-3:2007 Following the Provisions of the Electromagnetic Compatibility Directive 2004/108/EC ISO 8846 / Electrical Devices Protection Against Ignition of Surrounding Flammable Gases ISO 8849:2003 / Electrically Operated Bilge Pumps ISO 10133 / Electrical Systems - Extra Low Voltage D.C.
- Page 5 Disconnect power from the system before working on the unit to avoid personal injury, damage to the surrounding environment and/ or damage to the unit.
- Page 9 Rated Open Flow Open Flow Open Flow Flow Output @ 0ft/0m Output @ 3.35ft/1m Output @ 6.7ft/2m (0 kPa) GPH (LPH) (10 kPa) GPH (LPH) (20 kPa) GPH (LPH) 360 (1362) 265 (1003) 190 (719) 500 (1892) 360 (1362) 260 (984) 700 (2649) 562 (2127) 330 (1249)
- Page 10 Pump Performance - Large RULE Pumps Pump Performance - Large RULE Pumps (22712) (30283) (15141) Pump Performance - Small RULE Pumps Pump Performance - Small RULE Pumps 3785...
- Page 12 +12" (+30cm)
- Page 13 Vented Loop +12" (+30cm) -12" (-30cm)
- Page 17 Keep all wire connections above the highest water level. Wires must be joined with butt connectors and a marine grade sealant to prevent wire corrosion.
- Page 18 – –...
- Page 19 GPH (LPH) Volts Model Amps (Volts) Amps (Volts) Fuse Size 8000(30280) 174D 12DC 15.5 (2ea) 20.0 (2ea) 25(2ea) 4000(15140 12DC 15.5 (12v) 20.0 (13.6v) 4000(15140) 56D-24 24DC 6.9 (24v) 10.0 (27.2v) 4000(15140) 56D-32 32DC 5.0 (32v) 7.5 (36.3v) 3700(14010) 12DC 15.5 (12v)
- Page 20 1500(5678) 24DC 2.3 (24v) 3.5 (27.2v) 1500(5678) 12DC 4.8 (12v) 7.0 (13.36) 1100(4164) 12DC 3.3 (12v) 5.0 (13.6v) 1100(4164) 27D-6 12DC 3.3 (12v) 5.0 (13.6v) 1100(4164) 24DC 1.3 (24v) 2.0 (27.2v) 1100(4164) 27DC 12DC 3.3 (12v) 5.0 (13.6v) 1000(3785) 12DC 2.9 (12v) 4.0 (13.6v) 800(3028)
- Page 21 Always install proper fuse size to prevent damage to product should a short occur. Failure to install proper fuse could increase risk of pump malfunction potentially resulting in personal injury and/or fire hazard.
